Sony STR-DE197 - Main Board Components (Connectors, Jacks, Coils, Transistors, Resistors)

29
STR-DE197
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
C931 1-164-159-11 CERAMIC 0.1uF 50V
C940 1-126-947-11 ELECT 47uF 20% 35V
(AEP)
C941 1-164-159-11 CERAMIC 0.1uF 50V
(AEP)
C942 1-164-159-11 CERAMIC 0.1uF 50V
CC401 1-128-809-11 CERAMIC 100PF 5% 50V
(AEP)
CC403 1-128-809-11 CERAMIC 100PF 5% 50V
(AEP)
CC405 1-128-809-11 CERAMIC 100PF 5% 50V
(AEP)
CC407 1-128-809-11 CERAMIC 100PF 5% 50V
(AEP)
CC409 1-128-809-11 CERAMIC 100PF 5% 50V
(AEP)
CC411 1-128-809-11 CERAMIC 100PF 5% 50V
(AEP)
CC451 1-128-809-11 CERAMIC 100PF 5% 50V
(AEP)
CC453 1-128-809-11 CERAMIC 100PF 5% 50V
(AEP)
CC455 1-128-809-11 CERAMIC 100PF 5% 50V
(AEP)
CC457 1-128-809-11 CERAMIC 100PF 5% 50V
(AEP)
CC459 1-128-809-11 CERAMIC 100PF 5% 50V
(AEP)
CC461 1-128-809-11 CERAMIC 100PF 5% 50V
(AEP)
CC701 1-127-876-11 CERAMIC 0.01uF 10% 50V
(AEP)
CC702 1-127-876-11 CERAMIC 0.01uF 10% 50V
(AEP)
CC751 1-127-876-11 CERAMIC 0.01uF 10% 50V
(AEP)
CC752 1-127-876-11 CERAMIC 0.01uF 10% 50V
(AEP)
< CONNECTOR >
CNP901 1-564-321-00 PIN, CONNECTOR (3.96mm PITCH) 2P
* CNP902 1-565-792-11 PIN, CONNECTOR (3.96mm PITCH) 2P
* CNP903 1-564-242-00 PIN, CONNECTOR (3.96mm PITCH) 5P
CNP904 1-691-767-11 PLUG (MICRO CONNECTOR) 5P
CNS1 1-568-830-11 CONNECTOR, FFC 11P (US,CND)
CNS1 1-784-776-11 CONNECTOR, FFC 15P (AEP)
CNS2 1-784-776-11 CONNECTOR, FFC 15P (US,CND)
CNS2 1-784-778-11 CONNECTOR, FFC 17P (AEP)
CNS3 1-784-776-11 CONNECTOR, FFC 15P
< DIODE >
D701 8-719-991-33 DIODE 1SS133T-77
D751 8-719-991-33 DIODE 1SS133T-77
D781 8-719-991-33 DIODE 1SS133T-77
D782 8-719-991-33 DIODE 1SS133T-77
D783 8-719-991-33 DIODE 1SS133T-77
D784 8-719-991-33 DIODE 1SS133T-77
D785 8-719-991-33 DIODE 1SS133T-77
D786 8-719-991-33 DIODE 1SS133T-77
D787 8-719-991-33 DIODE 1SS133T-77
D788 8-719-991-33 DIODE 1SS133T-77
D789 8-719-991-33 DIODE 1SS133T-77
D901 6-500-522-11 DIODE 10EDB40-TA2B5
D902 6-500-522-11 DIODE 10EDB40-TA2B5
D903 6-500-522-11 DIODE 10EDB40-TA2B5
D904 6-500-522-11 DIODE 10EDB40-TA2B5
D905 8-719-991-33 DIODE 1SS133T-77
D906 8-719-991-33 DIODE 1SS133T-77
D907 8-719-072-05 DIODE RBV-602LF-A
D908 6-500-522-11 DIODE 10EDB40-TA2B5
D909 6-500-522-11 DIODE 10EDB40-TA2B5
D910 6-500-522-11 DIODE 10EDB40-TA2B5
D911 6-500-522-11 DIODE 10EDB40-TA2B5
D912 8-719-986-54 DIODE HZS24-1LTA
D913 8-719-109-89 DIODE RD5.6ESB2
D914 6-500-522-11 DIODE 10EDB40-TA2B5
D915 8-719-109-89 DIODE RD5.6ESB2 (AEP)
D981 8-719-991-33 DIODE 1SS133T-77
D982 8-719-991-33 DIODE 1SS133T-77
< EARTH TERMINAL >
* EP901 1-537-738-21 TERMINAL, EARTH
< IC >
IC401 6-700-261-01 IC BD3861FS
IC402 8-759-534-63 IC TC9299P
IC403 8-759-167-88 IC NJM4565D
IC404 8-759-932-33 IC BU4066BC
IC601 6-705-630-01 IC STK350-430
IC901 8-759-333-83 IC NJM2103D
IC902 8-759-231-53 IC TA7805S
IC903 8-759-231-57 IC TA7810S
IC904 6-702-771-01 IC TA78033LS
IC905 8-759-167-88 IC NJM4565D (AEP)
IC906 8-759-243-51 IC TC74ACT08P
IC907 8-759-245-84 IC TA79010S (AEP)
< JACK >
J801 1-774-411-11 JACK, PIN 6P (CD IN,MD/TAPE OUT,
MD/TAPE IN)
J802 1-774-411-11 JACK, PIN 6P (VIDEO 2 AUDIO IN,
VIDEO 1 AUDIO OUT/AUDIO IN)
< COIL >
L701 1-420-872-52 COIL, AIR-CORE
L751 1-420-872-52 COIL, AIR-CORE
< TRANSISTOR >
Q424 8-729-029-86 TRANSISTOR DTC124ESA
Q474 8-729-029-86 TRANSISTOR DTC124ESA
Q701 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q702 8-729-141-30 TRANSISTOR 2SC3623A-LK
Q705 8-729-042-09 TRANSISTOR 2SA1038S-RSE-TP
Q706 8-729-042-09 TRANSISTOR 2SA1038S-RSE-TP
Q751 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q752 8-729-141-30 TRANSISTOR 2SC3623A-LK
Q755 8-729-042-09 TRANSISTOR 2SA1038S-RSE-TP
Q756 8-729-042-09 TRANSISTOR 2SA1038S-RSE-TP
MAIN
Ver 1.1
