6. ELECTRICAL PARTS LIST
NOTE:
• Due to standardization, replacements in
the parts list may be different from the
parts specified in the diagrams or the
components used on the set.
• -XX and -X mean standardized parts, so
they may have some difference from the
original one.
• RESISTORS
All resistors are in ohms.
METAL:Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F:nonflammable
• Items marked “*” are not stocked since
they are seldom required for routine service.
Some delay should be anticipated
when ordering these items.
• SEMICONDUCTORS
In each case, u : µ, for example:
uA.. : µA.. uPA.. : µPA..
uPB.. : µPB.. uPC.. : µPC.. uPD.. : µPD..
• CAPACITORS
uF : µF
• COILS
uH : µH
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
AC OUTLET BOARD
****************
< AC OUTLET >
0 CNJ901 1-785-285-11 OUTLET, AC (1P) (AC OUTLET) (AEP)
0 CNJ901 1-785-834-11 OUTLET, AC (1P) (AC OUTLET) (US,CND)
< CONNECTOR >
CNP905 1-564-321-00 PIN, CONNECTOR (3.96mm PITCH) 2P
*************************************************************
A-1212-649-A DISPLAY BOARD, COMPLETE (US,CND)
A-1212-658-A DISPLAY BOARD, COMPLETE (AEP)
************************
2-887-959-01 HOLDER, FL
< CAPACITOR >
C202 1-104-905-11 DOUBLE LAYERS 0.22F 5.5V
C203 1-164-159-11 CERAMIC 0.1uF 50V
C204 1-128-821-11 CERAMIC 0.001uF 5% 50V
C205 1-127-876-11 CERAMIC 0.01uF 10% 50V
(AEP)
C206 1-127-876-11 CERAMIC 0.01uF 10% 50V
C207 1-128-821-11 CERAMIC 0.001uF 5% 50V
C208 1-128-821-11 CERAMIC 0.001uF 5% 50V
C209 1-128-821-11 CERAMIC 0.001uF 5% 50V
C210 1-128-821-11 CERAMIC 0.001uF 5% 50V
C211 1-127-876-11 CERAMIC 0.01uF 10% 50V
C212 1-127-876-11 CERAMIC 0.01uF 10% 50V
C213 1-127-876-11 CERAMIC 0.01uF 10% 50V
C215 1-126-947-11 ELECT 47uF 20% 35V
C216 1-126-795-11 ELECT 10uF 20% 50V
C217 1-128-821-11 CERAMIC 0.001uF 5% 50V
C218 1-128-821-11 CERAMIC 0.001uF 5% 50V
C219 1-126-794-11 ELECT 4.7uF 20% 50V
C221 1-128-821-11 CERAMIC 0.001uF 5% 50V
C222 1-128-821-11 CERAMIC 0.001uF 5% 50V
C225 1-164-159-11 CERAMIC 0.1uF 50V
C226 1-164-159-11 CERAMIC 0.1uF 50V
< CONNECTOR >
CNP202 1-750-186-11 CONNECTOR, BOARD TO BOARD 6P
CNS4 1-784-776-11 CONNECTOR, FFC 15P (US,CND)
CNS4 1-784-778-11 CONNECTOR, FFC 17P (AEP)
CNS5 1-784-776-11 CONNECTOR, FFC 15P
< DIODE >
D201 8-719-991-33 DIODE 1SS133T-77
D202 8-719-991-33 DIODE 1SS133T-77
D203 8-719-061-96 LED SLR-325DCT31 (BASS BOOST)
D204 8-719-991-33 DIODE 1SS133T-77
< VACUUM FLUORESCENT DISPLAY >
FL201 1-519-923-11 VACUUM FLUORESCENT DISPLAY
< IC >
IC201 6-806-993-01 IC uPD78045FGF-148-3B9-A
IC202 8-759-827-70 IC NJL64H400A-1 (IR)
< COIL >
L201 1-410-509-11 INDUCTOR 10uH
< TRANSISTOR >
Q201 8-729-029-40 TRANSISTOR DTA124ESA
Q202 8-729-029-86 TRANSISTOR DTC124ESA
Q206 8-729-029-86 TRANSISTOR DTC124ESA
< RESISTOR >
R202 1-249-439-11 CARBON 68K 5% 1/4W
R203 1-249-439-11 CARBON 68K 5% 1/4W
R204 1-249-439-11 CARBON 68K 5% 1/4W
R205 1-249-439-11 CARBON 68K 5% 1/4W
R206 1-249-439-11 CARBON 68K 5% 1/4W
R207 1-249-439-11 CARBON 68K 5% 1/4W
R208 1-249-439-11 CARBON 68K 5% 1/4W
R209 1-249-439-11 CARBON 68K 5% 1/4W
R210 1-249-439-11 CARBON 68K 5% 1/4W
R211 1-249-439-11 CARBON 68K 5% 1/4W
R212 1-249-439-11 CARBON 68K 5% 1/4W
R213 1-249-439-11 CARBON 68K 5% 1/4W
R214 1-249-439-11 CARBON 68K 5% 1/4W
R215 1-249-439-11 CARBON 68K 5% 1/4W
R216 1-249-439-11 CARBON 68K 5% 1/4W
R217 1-249-439-11 CARBON 68K 5% 1/4W
R218 1-249-439-11 CARBON 68K 5% 1/4W
R219 1-249-439-11 CARBON 68K 5% 1/4W
R220 1-249-439-11 CARBON 68K 5% 1/4W
R221 1-249-439-11 CARBON 68K 5% 1/4W
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Les composants identifiés par une
marque 0 sont critiques pour
la sécurité.
Ne les remplacer que par une piéce
portant le numéro spécifié.
When indicating parts by reference
number, please include the board.
•Abbreviation
CND : Canadian model
DISPLAYAC OUTLET
