15
STR-DE197
Ref. No. Part No. Description Remark
VOLUME BOARD
**************
< CONNECTOR >
CN202 1-750-195-11 CONNECTOR, BOARD TO BOARD 6P
< RESISTOR >
R265 1-247-831-11 CARBON 1K 5% 1/4W
R266 1-249-421-11 CARBON 2.2K 5% 1/4W
R267 1-249-421-11 CARBON 2.2K 5% 1/4W
R268 1-247-847-11 CARBON 4.7K 5% 1/4W
R269 1-249-429-11 CARBON 10K 5% 1/4W
R270 1-247-863-11 CARBON 22K 5% 1/4W
< ROTARY ENCODER >
RV201 1-418-725-41 ENCODER, ROTARY (12 TYPE)
(MASTER VOLUME)
< SWITCH >
S224 1-771-410-21 SWITCH, TACTILE (BALANCE R)
S225 1-771-410-21 SWITCH, TACTILE (TREBLE +)
S226 1-771-410-21 SWITCH, TACTILE (BASS +)
S227 1-771-410-21 SWITCH, TACTILE (BALANCE L)
S228 1-771-410-21 SWITCH, TACTILE (TREBLE –)
S229 1-771-410-21 SWITCH, TACTILE (BASS –)
VOLUME
