Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
— 32 —
R270 1-247-807-31 CARBON 100 5% 1/4W
R280 1-249-419-11 CARBON 1.5K 5% 1/4W F
(DE325:AEP,G,EE)
R281 1-249-421-11 CARBON 2.2K 5% 1/4W F
(DE225:AEP,G,EE,UK)
R282 1-247-843-11 CARBON 3.3K 5% 1/4W
(DE225:AEP,G,EE,UK)
R283 1-249-427-11 CARBON 6.8K 5% 1/4W F
R284 1-249-427-11 CARBON 6.8K 5% 1/4W F
R286 1-249-437-11 CARBON 47K 5% 1/4W
RD01 1-249-439-11 CARBON 68K 5% 1/4W
(DE225:CND/DE325:EXCEPT AEP,G,EE)
RD02 1-249-439-11 CARBON 68K 5% 1/4W
(DE225:CND/DE325:EXCEPT AEP,G,EE)
RD03 1-249-439-11 CARBON 68K 5% 1/4W
(DE225:CND/DE325:EXCEPT AEP,G,EE)
RD04 1-249-439-11 CARBON 68K 5% 1/4W
(DE225:CND/DE325:EXCEPT AEP,G,EE)
RD05 1-249-439-11 CARBON 68K 5% 1/4W
(DE225:CND/DE325:EXCEPT AEP,G,EE)
RD06 1-249-439-11 CARBON 68K 5% 1/4W
(DE225:CND/DE325:EXCEPT AEP,G,EE)
RD07 1-249-439-11 CARBON 68K 5% 1/4W
(DE225:CND/DE325:EXCEPT AEP,G,EE)
RD08 1-249-439-11 CARBON 68K 5% 1/4W
(DE225:CND/DE325:EXCEPT AEP,G,EE)
RD09 1-249-439-11 CARBON 68K 5% 1/4W
(DE225:CND/DE325:EXCEPT AEP,G,EE)
RD10 1-249-439-11 CARBON 68K 5% 1/4W
(DE225:CND/DE325:EXCEPT AEP,G,EE)
RD11 1-249-439-11 CARBON 68K 5% 1/4W
(DE225:CND/DE325:EXCEPT AEP,G,EE)
RD12 1-249-439-11 CARBON 68K 5% 1/4W
(DE225:CND/DE325:EXCEPT AEP,G,EE)
RD13 1-249-439-11 CARBON 68K 5% 1/4W
(DE225:CND/DE325:EXCEPT AEP,G,EE)
RD14 1-249-439-11 CARBON 68K 5% 1/4W
(DE225:CND/DE325:EXCEPT AEP,G,EE)
RD15 1-249-439-11 CARBON 68K 5% 1/4W
(DE225:CND/DE325:EXCEPT AEP,G,EE)
RD16 1-249-439-11 CARBON 68K 5% 1/4W
(DE225:CND/DE325:EXCEPT AEP,G,EE)
RD17 1-249-439-11 CARBON 68K 5% 1/4W
(DE225:CND/DE325:EXCEPT AEP,G,EE)
RD18 1-249-439-11 CARBON 68K 5% 1/4W
(DE225:CND/DE325:EXCEPT AEP,G,EE)
RD19 1-249-439-11 CARBON 68K 5% 1/4W
(DE225:CND/DE325:EXCEPT AEP,G,EE)
RD20 1-249-439-11 CARBON 68K 5% 1/4W
(DE225:CND/DE325:EXCEPT AEP,G,EE)
RD21 1-249-439-11 CARBON 68K 5% 1/4W
(DE225:CND/DE325:EXCEPT AEP,G,EE)
RD22 1-249-439-11 CARBON 68K 5% 1/4W
(DE225:CND/DE325:EXCEPT AEP,G,EE)
RD23 1-249-439-11 CARBON 68K 5% 1/4W
(DE225:CND/DE325:EXCEPT AEP,G,EE)
RD24 1-249-439-11 CARBON 68K 5% 1/4W
(DE225:CND/DE325:EXCEPT AEP,G,EE)
RD25 1-249-439-11 CARBON 68K 5% 1/4W
(DE225:CND/DE325:EXCEPT AEP,G,EE)
< SWITCH >
S200 1-762-751-11 SWITCH, TACTILE (POEWR)
S201 1-762-751-11 SWITCH, TACTILE (CENTER LEVEL -)
S202 1-762-751-11 SWITCH, TACTILE (CENTER LEVEL +)
S203 1-762-751-11 SWITCH, TACTILE (REAR LEVEL -)
S204 1-762-751-11 SWITCH, TACTILE (REAR LEVEL +)
S205 1-762-751-11 SWITCH, TACTILE (PTY)
(DE225:AEP,G,EE,UK/DE325:AEP,G,EE)
S206 1-762-751-11 SWITCH, TACTILE (EON)
(DE225:AEP,G,EE,UK/DE325:AEP,G,EE)
S207 1-762-751-11 SWITCH, TACTILE (CHARACTER)
(DE225:AEP,G,EE,UK/DE325:AEP,G,EE)
S208 1-762-751-11 SWITCH, TACTILE (DISPLAY)
(DE225:AEP,G,EE,UK/DE325:AEP,G,EE)
S209 1-762-751-11 SWITCH, TACTILE (TUNING PTY SELECT-)
S210 1-762-751-11 SWITCH, TACTILE (TUNING PTY SELECT+)
S211 1-762-751-11 SWITCH, TACTILE (PRESET CHARACTER-)
S212 1-762-751-11 SWITCH, TACTILE (PRESET CHARACTER+)
S213 1-762-751-11 SWITCH, TACTILE (SLEEP)
S214 1-762-751-11 SWITCH, TACTILE (FM MODE)
S215 1-762-751-11 SWITCH, TACTILE (FM/AM)
S216 1-762-751-11 SWITCH, TACTILE (MEMORY)
< VIBRATOR >
X201 1-577-101-11 VIBRATOR, CERAMIC 4.19MHz
************************************************************
* A-4407-425-A MAIN BOARD, COMPLETE (DE225:CND)
********************
* A-4407-448-A MAIN BOARD, COMPLETE (DE325:US)
********************
* A-4407-512-A MAIN BOARD, COMPLETE
********************
(DE225:AEP,G,EE,UK)
* A-4407-514-A MAIN BOARD, COMPLETE (DE325:CND)
********************
* A-4407-517-A MAIN BOARD, COMPLETE
********************
(DE325:E,EA,CH,AUS,SP,MY)
* A-4407-529-A MAIN BOARD, COMPLETE (DE325:AEP,G,EE)
********************
7-685-646-79 SCREW +BVTP 3X8 TYPE2 IT-3
3-905-609-01 SCREW (TRANSISTOR)
4-812-134-00 RIVET (DIA. 3.5), NYLON
7-685-872-09 SCREW +BVTT 3X8 (S)
< CAPACITOR >
C3 1-162-286-21 CERAMIC 220PF 10% 50V
(DE225:AEP,G,EE,UK/DE325:AEP,G,EE)
C4 1-126-961-11 ELECT 2.2uF 20% 50V
(DE225:AEP,G,EE,UK/DE325:AEP,G,EE)
C5 1-162-306-11 CERAMIC 0.01uF 20% 16V
(DE225:AEP,G,EE,UK/DE325:AEP,G,EE)
C6 1-162-291-31 CERAMIC 560PF 10% 50V
(DE225:AEP,G,EE,UK/DE325:AEP,G,EE)
C7 1-102-527-11 CERAMIC 82PF 5% 50V
(DE225:AEP,G,EE,UK/DE325:AEP,G,EE)
C8 1-102-852-91 CERAMIC 47PF 5% 50V
(DE225:AEP,G,EE,UK/DE325:AEP,G,EE)
DISPLAY MAIN
