NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX, -X mean standardized parts, so they may
have some difference from the original one.
• Items marked “*” are not stocked since they
are seldom required for routine service. Some
delay should be anticipated when ordering these
items.
• CAPACITORS:
uF: µF
• RESISTORS
All resistors are in ohms.
METAL: metal-film resistor
METAL OXIDE: Metal Oxide-film resistor
F: nonflammable
• COILS
uH: µH
• SEMICONDUCTORS
In each case, u: µ, for example:
uA...: µA... , uPA... , µPA... ,
uPB... , µPB... , uPC... , µPC... ,
uPD..., µPD...
• Abbreviation
CND : Canadian G : German
EE : East European MY : Malaysia
AUS : Australian SP : Singapore
CH : Chinese EA : Saudi Arabia
When indicating parts by reference number,
please include the board name.
The components identified by mark ! or
dotted line with mark ! are critical for safety.
Replace only with part number specified.
Les composants identifiés par une marque
! sont critiques pour la sécurité.
Ne les remplacer que par une pièce portant
le numéro spécifié.
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
— 31 —
SECTION 5
ELECTRICAL PARTS LIST
* A-4407-424-A DISPLAY BOARD,COMPLETE (DE325:SP,MY)
**********************
* A-4407-434-A DISPLAY BOARD,COMPLETE
**********************
(DE225:CND/DE325:US,CND)
* A-4407-510-A DISPLAY BOARD,COMPLETE
**********************
(DE225:AEP,G,EE,UK)
* A-4407-515-A DISPLAY BOARD,COMPLETE (DE325:AUS)
**********************
* A-4407-518-A DISPLAY BOARD,COMPLETE (DE325:E,EA,CH)
**********************
* A-4407-521-A DISPLAY BOARD,COMPLETE (DE325:AEP,G,EE)
**********************
* 4-921-941-01 CUSHION (FL)
* 4-943-107-11 HOLDER (FL TUBE)
< CAPACITOR >
C201 1-104-905-11 CAPACITOR 0.22F 5.5V
C202 1-164-159-11 CERAMIC 0.1uF 50V
C203 1-124-465-00 ELECT 0.47uF 20% 50V
C204 1-164-159-11 CERAMIC 0.1uF 50V
C205 1-162-294-31 CERAMIC 0.001uF 10% 50V
C206 1-164-159-11 CERAMIC 0.1uF 50V
C207 1-126-096-11 ELECT 10uF 20% 35V
C208 1-126-096-11 ELECT 10uF 20% 35V
< CONNECTOR >
CNP205 1-779-366-11 CONNECTOR, BOARD TO BOARD 4P
CNS201 1-568-742-11 SOCKET, CONNECTOR 23P
CNS202 1-770-400-11 HOUSING, CONNECTOR(PC BOARD)7P
< DIODE >
D201 8-719-911-19 DIODE 1SS119
D202 8-719-911-19 DIODE 1SS119
D203 8-719-911-19 DIODE 1SS119
D204 8-719-911-19 DIODE 1SS119
D211 8-719-911-19 DIODE 1SS119
D212 8-719-911-19 DIODE 1SS119
D213 8-719-991-33 DIODE 1SS133T-77
(DE225:AEP,G,EE,UK/DE325:AEP,G,EE)
D214 8-719-991-33 DIODE 1SS133T-77
(DE225:AEP,G,EE,UK/DE325:AEP,G,EE)
D215 8-719-911-19 DIODE 1SS119
D216 8-719-911-19 DIODE 1SS119
D217 8-719-911-19 DIODE 1SS119
D218 8-719-911-19 DIODE 1SS119
D221 8-719-991-33 DIODE 1SS133T-77 (DE325:EE)
D221 8-719-911-19 DIODE 1SS119 (DE325:SP,MY)
D222 8-719-911-19 DIODE 1SS119 (DE325:E,EA,CH,AUS,SP,MY)
D223 8-719-991-33 DIODE 1SS133T-77
(DE225:AEP,G,EE,UK/DE325:AEP,G,EE)
D223 8-719-911-19 DIODE 1SS119 (DE325:AUS)
D225 8-719-991-33 DIODE 1SS133T-77 (DE225:AEP,G,EE,UK)
D231 8-719-911-19 DIODE 1SS119
D235 8-719-046-39 DIODE SEL5821A-TH15 (HALL)
D236 8-719-046-39 DIODE SEL5821A-TH15 (C.STUDIO)
D237 8-719-046-39 DIODE SEL5821A-TH15 (PRO LOGIC)
D239 8-719-046-39 DIODE SEL5821A-TH15 (BASS BOOST)
< FLUORESCENT >
FL201 1-517-662-11 INDICATOR TUBE, FLUORESCENT
< IC >
IC201 8-759-526-68 IC uPD78044FGF-112-3B9
IC202 8-759-962-08 IC BA6208
IC203 8-759-332-18 IC GP1U27XB
< COIL >
L401 1-410-509-11 INDUCTOR 10uH
< TRANSISTOR >
Q201 8-729-900-63 TRANSISTOR DTA124ES
Q202 8-729-900-36 TRANSISTOR DTC124ES
Q231 8-729-900-36 TRANSISTOR DTC124ES
< RESISTOR >
R200 1-249-433-11 CARBON 22K 5% 1/4W
R201 1-247-903-00 CARBON 1M 5% 1/4W
R202 1-249-429-11 CARBON 10K 5% 1/4W
R203 1-249-429-11 CARBON 10K 5% 1/4W
R204 1-249-425-11 CARBON 4.7K 5% 1/4W F
R205 1-249-441-11 CARBON 100K 5% 1/4W
R207 1-249-429-11 CARBON 10K 5% 1/4W
(DE325:AEP,G,EE)
R211 1-249-433-11 CARBON 22K 5% 1/4W
R212 1-249-433-11 CARBON 22K 5% 1/4W
R216 1-249-433-11 CARBON 22K 5% 1/4W
R221 1-247-807-31 CARBON 100 5% 1/4W
R222 1-247-807-31 CARBON 100 5% 1/4W
R223 1-247-807-31 CARBON 100 5% 1/4W
R224 1-247-807-31 CARBON 100 5% 1/4W
R225 1-247-807-31 CARBON 100 5% 1/4W
R226 1-249-441-11 CARBON 100K 5% 1/4W
R227 1-249-441-11 CARBON 100K 5% 1/4W
R228 1-249-406-11 CARBON 120 5% 1/4W F
R230 1-249-406-11 CARBON 120 5% 1/4W F
R231 1-249-427-11 CARBON 6.8K 5% 1/4W F
