Sony STR-DE400 - Video, Tuning, Power, and Standby Board Components

50
STR-DE400
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
CNP903 1-564-506-11 PLUG, CONNECTOR 3P
CNP904 1-794-577-21 PIN, CONNECTOR (POWER)
CNP906 1-766-203-11 PLUG, CONNECTOR PIN (PC BOARD) 5P
< DIODE >
D901 8-719-991-33 DIODE 1SS133T-72
D910 6-500-522-11 DIODE 10EDB40-TA2B5
D911 6-500-522-11 DIODE 10EDB40-TA2B5
D912 6-500-522-11 DIODE 10EDB40-TA2B5
D913 6-500-522-11 DIODE 10EDB40-TA2B5
D914 8-719-991-33 DIODE 1SS133T-72
D915 8-719-991-33 DIODE 1SS133T-72
D920 6-500-522-11 DIODE 10EDB40-TA2B5
D921 6-500-522-11 DIODE 10EDB40-TA2B5
D922 6-500-522-11 DIODE 10EDB40-TA2B5
D923 6-500-522-11 DIODE 10EDB40-TA2B5
< FUSE HOLDER >
FH902 1-533-217-41 HOLDER, FUSE
FH952 1-533-217-41 HOLDER, FUSE
< TRANSISTOR >
Q901 8-729-119-78 TRANSISTOR 2SC1740S-QRT
Q911 8-729-119-78 TRANSISTOR 2SC1740S-QRT
< RESISTOR >
0 R810 1-243-634-91 FUSIBLE 0.22 5% 1/2W
0 R812 1-243-634-91 FUSIBLE 0.22 5% 1/2W
R903 1-247-871-91 CARBON 47K 5% 1/4W
R904 1-247-847-91 CARBON 4.7K 5% 1/4W
0 R905 1-249-381-11 CARBON 1 5% 1/4W
R911 1-247-871-91 CARBON 47K 5% 1/4W
R912 1-249-435-11 CARBON 33K 5% 1/4W
R913 1-249-429-11 CARBON 10K 5% 1/4W
< RELAY >
0 RY901 1-755-439-11 RELAY
< POWER TRANSFORMER >
0 TP900 1-443-517-11 POWER TRANSFORMER (EXCEPT TW)
0 TP900 1-443-519-11 POWER TRANSFORMER (TW)
*************************************************************
TUNING BOARD
*************
< RESISTOR >
R132 1-249-409-11 CARBON 220 5% 1/4W
R133 1-249-411-11 CARBON 330 5% 1/4W
R134 1-249-413-11 CARBON 470 5% 1/4W
R135 1-249-415-11 CARBON 680 5% 1/4W
R136 1-247-831-91 CARBON 1K 5% 1/4W
< SWITCH >
S131 1-771-410-21 SWITCH, TACTILE (–/TUNING)
S132 1-771-410-21 SWITCH, TACTILE (FM MODE)
S133 1-771-410-21 SWITCH, TACTILE (MEMORY)
S134 1-771-410-21 SWITCH, TACTILE (–/PRESET TUNING)
S135 1-771-410-21 SWITCH, TACTILE (+/PRESET TUNING)
S136 1-771-410-21 SWITCH, TACTILE (+/TUNING)
*************************************************************
VIDEO BOARD
************
< CAPACITOR >
C200 1-128-805-11 CERAMIC 47PF 5% 50V
C201 1-128-805-11 CERAMIC 47PF 5% 50V
C206 1-126-964-11 ELECT 10uF 20% 50V
C207 1-126-964-11 ELECT 10uF 20% 50V
C208 1-126-964-11 ELECT 10uF 20% 50V
C210 1-126-964-11 ELECT 10uF 20% 50V
C213 1-126-934-11 ELECT 220uF 20% 16V
C214 1-164-159-11 CERAMIC 0.1uF 50V
C215 1-164-159-11 CERAMIC 0.1uF 50V
C248 1-128-825-11 CERAMIC 2200PF 5% 50V
C250 1-128-825-11 CERAMIC 2200PF 5% 50V
C251 1-126-964-11 ELECT 10uF 20% 50V
C252 1-126-964-11 ELECT 10uF 20% 50V
C253 1-126-964-11 ELECT 10uF 20% 50V
C254 1-126-964-11 ELECT 10uF 20% 50V
C255 1-126-964-11 ELECT 10uF 20% 50V
C256 1-126-964-11 ELECT 10uF 20% 50V
C257 1-127-888-11 CERAMIC 0.1uF 10% 50V
C258 1-126-947-11 ELECT 47uF 20% 35V
C259 1-127-888-11 CERAMIC 0.1uF 10% 50V
C260 1-126-947-11 ELECT 47uF 20% 35V
C809 1-126-934-11 ELECT 220uF 20% 16V
C825 1-164-159-11 CERAMIC 0.1uF 50V
C826 1-164-159-11 CERAMIC 0.1uF 50V
< CONNECTOR >
CNP156 1-691-765-11 PLUG (MICRO CONNECTOR) 3P
CNS250 1-784-766-11 CONNECTOR, FFC 5P
< IC >
IC203 8-759-333-84 IC NJM2279D
IC251 6-707-363-01 IC NJM2586AL
IC804 8-759-245-79 IC TA79005S
IC807 8-759-231-53 IC TA7805S
< JACK >
J201 1-815-043-11 JACK, PIN 2P
(VIDEO IN/VIDEO 1//VIDEO OUT/MONITOR)
J202 1-794-978-11 JACK, PIN 3P
(VIDEO IN/DVD//VIDEO IN/VIDEO 2//VIDEO OUT/VIDEO 1)
J251 1-816-592-11 JACK, PIN 9P
(MONITOR OUT/VIDEO 2 IN/DVD IN//COMPONENT VIDEO)
< RESISTOR >
R200 1-247-804-11 CARBON 75 5% 1/4W
R201 1-247-804-11 CARBON 75 5% 1/4W
R218 1-247-804-11 CARBON 75 5% 1/4W
R220 1-247-804-11 CARBON 75 5% 1/4W
R221 1-247-804-11 CARBON 75 5% 1/4W
R250 1-247-804-11 CARBON 75 5% 1/4W
R251 1-247-804-11 CARBON 75 5% 1/4W
STANDBY TUNING VIDEO
Ver. 1.2
