Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
37
STR-DE675
R146 1-249-421-11 CARBON 2.2K 5% 1/4W F
R147 1-249-409-11 CARBON 220 5% 1/4W F
R148 1-249-421-11 CARBON 2.2K 5% 1/4W F
R149 1-249-409-11 CARBON 220 5% 1/4W F
R150 1-249-409-11 CARBON 220 5% 1/4W F
R151 1-249-409-11 CARBON 220 5% 1/4W F
R152 1-249-409-11 CARBON 220 5% 1/4W F
R153 1-247-807-31 CARBON 100 5% 1/4W
R158 1-249-440-11 CARBON 82K 5% 1/4W
0R198 1-249-381-11 CARBON 1 5% 1/4W F
0R199 1-249-381-11 CARBON 1 5% 1/4W F
< VARIABLE RESISTOR >
RV102 1-418-773-11 ENCODER, ROTARY (MASTER VOLUME)
< SWITCH >
S100 1-762-875-21 SWITCH, TACTILE (MUTING)
S101 1-762-875-21 SWITCH, TACTILE (MODE)
S102 1-762-875-21 SWITCH, TACTILE (MULTI CH IN)
S103 1-762-875-21 SWITCH, TACTILE (INPUT MODE)
S104 1-762-875-21 SWITCH, TACTILE (TV/SAT)
S105 1-762-875-21 SWITCH, TACTILE (CD)
S106 1-762-875-21 SWITCH, TACTILE (TUNER)
S107 1-762-875-21 SWITCH, TACTILE (VIDEO2)
S108 1-762-875-21 SWITCH, TACTILE (TUNING -)
S109 1-762-875-21 SWITCH, TACTILE (PRESET TUNING -)
S110 1-762-875-21 SWITCH, TACTILE (SET UP)
S111 1-762-875-21 SWITCH, TACTILE (NAME)
S112 1-762-875-21 SWITCH, TACTILE (ENTER)
S113 1-762-875-21 SWITCH, TACTILE (LEVEL)
S114 1-762-875-21 SWITCH, TACTILE (SUR)
S115 1-762-875-21 SWITCH, TACTILE (DVD/LD)
S116 1-762-875-21 SWITCH, TACTILE (VIDEO1)
S117 1-762-875-21 SWITCH, TACTILE (MD/TAPE)
S118 1-762-875-21 SWITCH, TACTILE (AM)
S119 1-762-875-21 SWITCH, TACTILE (FM)
S120 1-762-875-21 SWITCH, TACTILE (<)
S121 1-762-875-21 SWITCH, TACTILE (>)
S122 1-762-875-21 SWITCH, TACTILE (SHIFT)
S123 1-762-875-21 SWITCH, TACTILE (TUNING +)
S124 1-762-875-21 SWITCH, TACTILE (PRESET TUNING +)
S125 1-762-875-21 SWITCH, TACTILE (MEMORY)
S126 1-762-875-21 SWITCH, TACTILE (FM MODE)(AEP,UK,AR)
S128 1-762-875-21 SWITCH, TACTILE (AUX)
S129 1-762-875-21 SWITCH, TACTILE (CINEMA STUDIO EX C)
S130 1-762-875-21 SWITCH, TACTILE (CINEMA STUDIO EX B)
S131 1-762-875-21 SWITCH, TACTILE (CINEMA STUDIO EX A)
S132 1-762-875-21 SWITCH, TACTILE (EQ)
S133 1-762-875-21 SWITCH, TACTILE (EQUALIZER)
S134 1-762-875-21 SWITCH, TACTILE (A.F.D.)
S135 1-762-875-21 SWITCH, TACTILE (2CH)
************************************************************
1-680-529-11 HEADPHONE BOARD
****************
< CAPACITOR >
C790 1-128-809-11 CERAMIC 100PF 5% 50V
< CONNECTOR >
CNP791 1-691-766-11 PLUG (MICRO CONNECTOR) 4P
< DIODE >
D790 8-719-210-21 DIODE 11EQS04-NTA2B
< JACK >
J791 1-815-314-21 JACK (PHONES)(US,CND,AEP,UK,E,MX,AR,AUS)
J791 1-815-313-21 JACK (PHONES)(MY,SP,TW,KR,CH)
************************************************************
1-680-531-11 IMPEDANCE SELECT BOARD (US,CND)
***********************
< CONNECTOR >
* CNP803 1-564-242-00 PIN, CONNECTOR 5P (US,CND)
< DIODE >
D810 8-719-024-99 DIODE 11ES2-NTA2B (US,CND)
D811 8-719-024-99 DIODE 11ES2-NTA2B (US,CND)
< FUSIBLE RESISTOR >
0RF801 1-240-877-11 RES, NONFLAMMABE FUSE 0.15 5%
1/2W
< SWITCH >
S902 1-786-107-11 SLIDE SWITCH (IMPEDANCE SELECTOR)
(US,CND)
************************************************************
1-680-532-11 JOG BOARD
**********
< CONNECTOR >
* CN101 1-564-719-11 PIN, CONNECTOR (SMALL TYPE) 3P
< VARIABLE RESISTOR >
RV101 1-418-817-11 ENCODER, ROTARY (JOG DIAL)
************************************************************
A-4475-797-A MAIN BOARD, COMPLETE (US)
*********************
A-4475-874-A MAIN BOARD, COMPLETE (CND)
*********************
A-4475-886-A MAIN BOARD, COMPLETE
*********************
(AEP,UK,E,MY,SP,TW,KR,MX,AR,CH,AUS)
7-685-646-79 SCREW +BVTP 3X8 TYPE2 IT-3
< CAPACITOR >
C371 1-128-809-11 CERAMIC 100PF 5% 50V
C372 1-128-809-11 CERAMIC 100PF 5% 50V
C373 1-128-809-11 CERAMIC 100PF 5% 50V
C374 1-128-809-11 CERAMIC 100PF 5% 50V
C375 1-128-809-11 CERAMIC 100PF 5% 50V
C376 1-128-809-11 CERAMIC 100PF 5% 50V
C400 1-162-302-11 CERAMIC 0.0022uF 20.00% 16V
DISPLAY HEADPHONE
IMPEDANCE SELECT JOG MAIN
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Les composants identifiés par
une marque 0 sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
