Sony STR-DE835 - Page 61

Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
— 83 —
RR67 1-216-029-00 METAL CHIP 150 5% 1/10W
RR68 1-216-025-91 RES,CHIP 100 5% 1/10W
(DE935)
RR69 1-216-029-00 METAL CHIP 150 5% 1/10W
(DE935)
RR70 1-216-025-91 RES,CHIP 100 5% 1/10W
RR71 1-216-029-00 METAL CHIP 150 5% 1/10W
RR72 1-216-025-91 RES,CHIP 100 5% 1/10W
RR73 1-216-029-00 METAL CHIP 150 5% 1/10W
RR74 1-216-037-00 METAL CHIP 330 5% 1/10W
RR75 1-216-037-00 METAL CHIP 330 5% 1/10W
< SWITCH >
S101 1-771-349-21 SWITCH, KEYBOARD (1)
S102 1-771-349-21 SWITCH, KEYBOARD (2)
S103 1-771-349-21 SWITCH, KEYBOARD (3)
S104 1-771-349-21 SWITCH, KEYBOARD (4)
S105 1-771-349-21 SWITCH, KEYBOARD (5)
S106 1-771-349-21 SWITCH, KEYBOARD (6)
S107 1-771-349-21 SWITCH, KEYBOARD (7)
S108 1-771-349-21 SWITCH, KEYBOARD (8)
S109 1-771-349-21 SWITCH, KEYBOARD (9)
S110 1-771-349-21 SWITCH, KEYBOARD (0)
S111 1-771-349-21 SWITCH, KEYBOARD (MEMORY)
S112 1-771-349-21 SWITCH, KEYBOARD (DIRECT)
S113 1-771-349-21 SWITCH, KEYBOARD (PRESET +)
S114 1-771-349-21 SWITCH, KEYBOARD (SUR)
S115 1-771-349-21 SWITCH, KEYBOARD (FM MODE)
S116 1-771-349-21 SWITCH, KEYBOARD (AM)
S117 1-771-349-21 SWITCH, KEYBOARD (FM)
S118 1-771-349-21 SWITCH, KEYBOARD (A.F.D.)
S119 1-771-349-21 SWITCH, KEYBOARD (SET UP)
S120 1-771-349-21 SWITCH, KEYBOARD (MD/TAPE)
S121 1-771-349-21 SWITCH, KEYBOARD (VIDEO1)
S122 1-771-349-21 SWITCH, KEYBOARD (VIDEO2)
S123 1-771-349-21 SWITCH, KEYBOARD (CD)
S124 1-771-349-21 SWITCH, KEYBOARD (VIDEO3)(DE935)
S125 1-771-349-21 SWITCH, KEYBOARD (2ND AUDIO)(DE935)
S126 1-771-349-21 SWITCH, KEYBOARD (TAPE)(DE935)
S127 1-771-349-21 SWITCH, KEYBOARD (TUNER)
S128 1-771-349-21 SWITCH, KEYBOARD (TV/SAT)
S129 1-771-349-21 SWITCH, KEYBOARD (DVD/LD)
S130 1-771-349-21 SWITCH, KEYBOARD (PHONO)
S131 1-771-349-21 SWITCH, KEYBOARD (INPUT MODE)
S132 1-771-349-21 SWITCH, KEYBOARD (5.1CH INPUT)
S133 1-771-349-21 SWITCH, KEYBOARD (EQ)
S134 1-771-349-21 SWITCH, KEYBOARD (MODE)
S135 1-771-349-21 SWITCH, KEYBOARD (2CH)
S136 1-771-349-21 SWITCH, KEYBOARD (<)
S137 1-771-349-21 SWITCH, KEYBOARD (>)
S138 1-771-349-21 SWITCH, KEYBOARD (NAME)
S139 1-771-349-21 SWITCH, KEYBOARD (ENTER)
S140 1-771-349-21 SWITCH, KEYBOARD (SHIFT)
S141 1-771-349-21 SWITCH, KEYBOARD (TUNING -)
S142 1-771-349-21 SWITCH, KEYBOARD (TUNING +)
S143 1-771-349-21 SWITCH, KEYBOARD (PRESET -)
S144 1-771-349-21 SWITCH, KEYBOARD (LEVEL)
************************************************************
* 1-673-358-11 TUNER BOARD
************
< CAPACITOR >
C381 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C382 1-163-037-11 CERAMIC CHIP 0.022uF 10% 25V
C399 1-126-964-11 ELECT 10uF 20% 50V
< CONNECTOR >
* CNS303 1-569-306-11 SOCKET, CONNECTOR (L TYRE) 15P
CNS305 1-774-289-11 PIN, CONNECTOR (PC BOARD) 15P
< IC >
IC399 8-759-708-12 IC NJM78L12A-T3
************************************************************
1-673-352-11 V.SWITCH BOARD (DE835:E,PX)
**************
1-533-217- HOLDER,FUSE
< CONNECTOR >
CNV903 1-568-106-11 PIN, CONNECTOR 4P
< DIODE >
D114 8-719-016-74 DIODE 1SS352-TPH3
< FUSE >
! F904 1-532-504-51 FUSE TIME LAG 4A/250V (E,PX)
< SWITCH >
! VS901 1-571-437-11 SWITCH, POWER VOLTAGE CHANGE
************************************************************
* 1-673-356-11 VIDEO BOARD
***********
< CAPACITOR >
C201 1-126-964-11 ELECT 10uF 20% 50V
C202 1-126-964-11 ELECT 10uF 20% 50V
C203 1-126-964-11 ELECT 10uF 20% 50V
C204 1-126-964-11 ELECT 10uF 20% 50V
C205 1-163-243-11 CERAMIC CHIP 47PF 5% 50V
C206 1-163-243-11 CERAMIC CHIP 47PF 5% 50V
C207 1-163-243-11 CERAMIC CHIP 47PF 5% 50V
C208 1-126-964-11 ELECT 10uF 20% 50V
C209 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C210 1-165-319-11 CERAMIC CHIP 0.1uF 50V
VIDEOTUNER V.SWITCHSW
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
Les composants identifiés par
une marque ! sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
