Sony STR-DG710 - Integrated Circuit Block Diagrams (Continued); DCDC Board IC Block Diagrams

54
STR-DG710
IC4001 SI-8050S-LF1101 (DCDC Board)
OVER
CURRENT
PROTECTOR
LATCH
&
DRIVER
OVER HEAT
PROTECTOR
REGULATOR
+
–
+
–
RESET
VREF
COMPARATOR
ERROR AMP
OSC
1
VIN
2
SW OUT
3
GND
4
VOS
5
S.S
IC4100 SI-8033S (DCDC Board)
OVER
CURRENT
PROTECTOR
LATCH
&
DRIVER
OVER HEAT
PROTECTOR
REGULATOR
ON/OFF
SOFT
START
+
–
+
–
RESET
VREF
COMPARATOR
ERROR AMP
OSC
1
VIN
2
SW OUT
3
GND
4
VOS
5
ON/OFF
