Sony STR-DG710 - IC Pin Descriptions (System Control Continued); IC1907 Pinout Details (49-99)

58
STR-DG710
Pin No . Pin Name I/O Pin Descr iption
49 DIR ERROR I Digital audio interface receiver error signal input
50 DIR XSTATE I Digital audio interface receiver state signal input
51 NMI I Non Maskable interrupt input
52 MD2 I Operation mode setting pin 2
53 MD1 I Operation mode setting pin 1 (Connect to GND.)
54 MD0 I Operation mode setting pin 0 (Connect to GND.)
55 INIT I External reset signal input
56 VCC I Power supply pin (+3.3 V)
57 X1 O High speed clock output (12.5 MHz) (Main clock)
58 X0 I High speed clock input (12.5 MHz) (Main clock)
59 VSS — Ground pin
60 X0A I Low speed clock input (Sub clock) Not used in this set. (Connect to GND.)
61 X1A O Low speed clock output (Sub clock) Not used in this set. (Open)
62 RST TRG I Reset trigger signal input
63 DIR DATA0 I Digital audio interface receiver serial data signal input
64 BST SEL O Burst select signal output
65 GP9 I GP9 address strobe signal input
66 BST O Burst signal output
67 HCS O HCS signal output
68 HACN I HACN signal output
69 DSP RESET O Digital signal processor reset signal output
70 FL CLK O Fluorescent display serial clock signal output
71 FL DATA O Fluorescent display serial data signal output
72 PCM1609 ML O ML signal output
73 PM O PM signal output
74 GP12 O GP12 address strobe signal output
75 PCM1609 MDO I MD signal input
76 VSS — Ground pin
77 VCC I Power supply pin (+3.3 V)
78 FL LAT O Fluorescent display serial latch signal output
79 TUNER CLK O Tuner serial clock signal output
80 TUNER DATA O Tuner serial data signal output
81 STOP I Stop signal input
82 SIRCS IN I Remote control signal input
83 ERROR SEL I Error select signal input
84 RDS CLK/XMDBPOWER I/O XMDB power control signal output
85 POWER KEY I Power key signal input
86 RDS DATA/XM COM I XM command signal input
87 DCAC DSP IN I DCAC display in signal input
88 HDMI CEC IN/HDMI OED I HDMI OED signal input
89 HDMI UART IN/HDMI S1 I HDMI select signal input
90 HDMI UART OUT/HDMI S2 O HDMI select signal output
91 HDMI CEC OUT O HDMI CEC signal output
92 XM MIXMO I XM MIXMO signal input
93 XM MOXMI O XM MOXMI signal output
94 HDMI REG CTRL O HDMI REG control signal output
95 VCC I Power supply pin (+3.3 V)
96 VSS — Ground pin
97 EEPROM DATA I/O EEPROM serial data signal input/output
98 EEPROM CLK O EEPROM serial clock signal output
99 HD OUT I HD signal input from digital signal processor
