Sony STR-DN1010 - HDMI TRANSMITTER IC Pin Functions

STR-DN1010
63
Pin No. Pin Name I/O Description
57 I2S_SPDIF_IN_DATA - Not used
58
I2S_IN_WCLK/
GPIO50
- Not used
59
I2S_IN_BCLK/
GPIO51
- Not used
60
I2S0_SPDIF_OUT_
DATA
- Not used
61
I2S_OUT_WCLK/
GPIO52
- Not used
62
I2S_OUT_BCLK/
GPIO53
- Not used
63 I2S1_OUT_DATA - Not used
64 AUD_CLKOUT - Not used
65 CVDD_18 - Power supply terminal (+1.8V)
66 CRVSS - Ground terminal
67 DEN/VOP_FLD O Data enable signal output to the HDMI transmitter and D/A converter
68 DHS/VOP_HS O Horizontal sync signal output to the HDMI transmitter and D/A converter
69 DHS/VOP_VS O Vertical sync signal output to the HDMI transmitter and D/A converter
70 DCLK/VOP_CLK O Output data clock signal output to the HSYNC select, HDMI transmitter and D/A converter
71 PBIAS - Not used
72 PPWR - Not used
73 AVSS_LV - Ground terminal
74 AVDD_LV_33 - Power supply terminal (+3.3V)
75 to 84
CH3P_LV_E/R0,
CH3N_LV_E/R1,
CHKP_LV_E/R2,
CHKN_LV_E/R3,
CH2P_LV_E/R4,
CH2N_LV_E/R5,
CH1P_LV_E/R6,
CH1N_LV_E/R7,
CH0P_LV_E/G0,
CH0N_LV_E/G1
O Serial data output to the HDMI transmitter and D/A converter
85 AVSS_OUT_LV - Ground terminal
86 AVDD_OUT_LV_33 - Power supply terminal (+3.3V)
87 to 96
CH3P_LV_O/G2,
CH3NLV_O/G3,
CHKP_LV_O/G4,
CHKN_LV_O/G5,
CH2P_LV_O/G6,
CH2N_LV_O/G7,
CH1P_LV_O/B0,
CH1N_LV_O/B1,
CH0P_LV_O/B2,
CH0N_LV_O/B3
O Serial data output to the HDMI transmitter and D/A converter
97 AVSS_OUT_LV - Ground terminal
98 AVDD_OUT_LV_33 - Power supply terminal (+3.3V)
99 to 102
PD20/B4/GPIO45 to
PD23/B7/GPIO48
O Serial data output to the HDMI transmitter and D/A converter
103 CVDD_18 - Power supply terminal (+1.8V)
104 CRVSS - Ground terminal
105 GPIO49/A18 - Not used
106
ROM_SCSn/
ROM_CSn
O Serial data input from the serial fl ash
107 ROM_SCLK/A17 O Serial clock signal output to the serial fl ash
108
ROM_SDO/A16/
OPM2
O Serial data output to the serial fl ash
109 ROM_SDI/ROM_WEn I Serial data output to the serial fl ash
110 RVDD_33 - Power supply terminal (+3.3V)
111 CRVSS - Ground terminal
112
EXT_ADC_CLAMP/
A15/OPM1
- Not used
113
XOSD_CLK/A14/
OPM0
- Not used
114 XOSD_HS/A13/FS1 - Not used
