Sony STR-DN1010 - Page 64

STR-DN1010
64
Pin No. Pin Name I/O Description
115 XOSD_VS/A12/FS0 - Not used
116 XOSD_FLD/A11/FT1 - Not used
117 VBI_DATA_7/A10/FT0 - Not used
118, 119
VBI_DATA_6/A9/BT2,
VBI_DATA_5/A8/BT1
- Not used
120
VBI_DATA_4/A7/
GPO23/BT0
- Not used
121
VBI_DATA_3/A6/
GPO22/OSC_SEL
- Not used
122 to
124
VBI_DATA_2/A5/
GPIO21 to
VBI_DATA_0/A3/
GPIO19
- Not used
125
VBI_VALID/A2/
GPIO18
- Not used
126 VBI_CLK/A1/GPIO17 - Not used
127
VID_DATA_IN_16/D0/
VID2_0
- Not used
128 RVDD_33 - Power supply terminal (+3.3V)
129 CRVSS - Ground terminal
130
VID_DATA_IN_17/D1/
VID2_1
- Not used
131 CVDD_18 - Power supply terminal (+1.8V)
132 CRVSS - Ground terminal
133
VID_DATA_IN_18/D2/
VID2_2
- Not used
134 CVDD_18 - Power supply terminal (+1.8V)
135 CRVSS - Ground terminal
136 to
140
VID_DATA_IN_19/
D3/VID2_3 to
VID_DATA_IN_23/D7/
VID2_7
- Not used
141, 142
VID_DATA_IN_0,
VID_DATA_IN_1
- Not used
143 CVDD_18 - Power supply terminal (+1.8V)
144 CRVSS - Ground terminal
145 to
150
VID_DATA_IN_2 to
VID_DATA_IN_7
- Not used
151 VID_CLK1 - Not used
152 RVDD_33 - Power supply terminal (+3.3V)
153 CRVSS - Ground terminal
154 GPIO36/JTAG_TDO - Not used
155 GPIO35/JTAG_TDI - Not used
156 GPIO34 I External receipt bus open signal input from the system controller
157 GPIO33 - Not used
158 CVDD_18 - Power supply terminal (+1.8V)
159 CRVSS - Ground terminal
160, 161 GPIO24, GPIO25 - Not used
162, 163
VID_DATA_IN_8/
GPIO54,
VID_DATA_IN_9/
GPIO55
- Not used
164 GPIO26 - Not used
165, 166
VID_DATA_IN_10,
VID_DATA_IN_11
- Not used
167 to
169
GPIO27 to GPIO29 - Not used
170, 171
VID_DATA_IN_12,
VID_DATA_IN_13
- Not used
172 RVDD_33 - Power supply terminal (+3.3V)
173, 174
VID_DATA_IN_14,
VID_DATA_IN_15
- Not used
175 RVSS - Not used
