Sony STR-DN1010 - Page 65

STR-DN1010
65
Pin No. Pin Name I/O Description
176 to
178
GPIO30 to GPIO32 - Not used
179 VDD_HP_33 - Power supply terminal (+3.3V)
180 AUD_HP_OUT_L - Not used
181 AUD_HP_OUT_R - Not used
182 GND_HP - Ground terminal
183 AUD_OUT2_L - Not used
184 AUD_OUT2_R - Not used
185 AUD_OUT1_L - Not used
186 AUD_OUT1_R - Not used
187 VDD_AUD1_33 - Power supply terminal (+3.3V)
188 LS_OUT_L - Not used
189 LS_OUT_R - Not used
190 LS_OUT_SW - Not used
191 GND_AUD1 - Ground terminal
192 VREFN - Ground terminal
193 VREFM - Not used
194 VREFP - Not used
195 VDD_AUD2_33 - Power supply terminal (+3.3V)
196 AUD_IN_L4 - Not used
197 AUD_IN_R4 - Not used
198 AUD_IN_L3 - Not used
199 AUD_IN_R3 - Not used
200 AUD_IN_L2 - Not used
201 AUD_IN_R2 - Not used
202 AUD_IN_L1 - Not used
203 AUD_IN_R1 - Not used
204 AUD_MONO_IN - Not used
205 GND_AUD2 - Not used
206 VDD_AUD_18 - Power supply terminal (+1.8V)
207 GND_AUD_18 - Ground terminal
208 VDD18_ABC_SC - Power supply terminal (+1.8V)
209 GND18_ABC_SC - Ground terminal
210 VDDA - Power supply terminal (+3.3V)
211 SIF_IN2 - Not used
212 GNDA - Ground terminal
213 SIF_RTN - Not used
214 GNDA - Ground terminal
215 SIF_IN1 - Not used
216 VDDA - Power supply terminal (+3.3V)
217 SV1P - Not used
218 VDDA - Power supply terminal (+3.3V)
219 A1P I Component video signal input from the video amplifi er
220 GNDA - Ground terminal
221 B1P I Component video signal input from the video amplifi er
222 GNDA - Ground terminal
223 C1P I Component video signal input from the video amplifi er
224 GNDA - Ground terminal
225 AN - Not used
226 GNDA - Ground terminal
227 SV2P - Not used
228 VDDA - Power supply terminal (+3.3V)
229 A2P - Not used
230 VDDA - Power supply terminal (+3.3V)
231 B2P - Not used
232 GNDA - Ground terminal
233 C2P - Not used
234 GNDA - Ground terminal
235 BN - Not used
236 GNDA - Ground terminal
