STR-DN1010
66
Pin No. Pin Name I/O Description
237 SV3P - Not used
238 VDDA - Power supply terminal (+3.3V)
239 A3P - Not used
240 VDDA - Power supply terminal (+3.3V)
241 B3P - Not used
242 GNDA - Ground terminal
243 C3P - Not used
244 GNDA - Ground terminal
245 CN - Not used
246 GNDA - Ground terminal
247 SV4P I Composite video signal input from the video amplifi er
248 GNDA - Ground terminal
249 A4P - Not used
250 GNDA - Ground terminal
251 B4P - Not used
252 GNDA - Ground terminal
253 C4P - Not used
254 VDDA - Power supply terminal (+3.3V)
255 SVN - Not used
256 VOUT2 - Not used
