STR-DN1010
67
DIGITAL VIDEO BOARD (4/5) IC3202 ABT1015LQ128 (VIDEO DEINTERLACING)
Pin No. Pin Name I/O Description
1 RED[0] O Output red video data, not used
2 RED[1] O Output red video data, not used
3 RED[2] O Output red video data, not used
4 RED[3] O Output red video data, not used
5 PPL_VSS - PLL ground
6 PPL-VDD - PLL power supply (+1.8V)
7 SYSCLK I System clock input - 27MHz
8 IO_VDD - I/O Power supply (+3.3V)
9 IO_VSS - I/O ground
10 RED[9] O Output red video data, not used
11 RED[10] O Output red video data, not used
12 Core_VDD - Core power supply (+1.8V)
13 Core_VSS - Core ground
14 RED[11] O Output red video data, not used
15 BLUE[0] O Output blue video data, not used
16 BLUE[1] O Output blue video data, not used
17 BLUE[2] O Output blue video data, not used
18 BLUE[3] O Output blue video data, not used
19 BLUE[4] O Output blue video data, C[0]
20 BLUE[5] O Output blue video data, C[1]
21 BLUE[6] O Output blue video data, C[2]
22 BLUE[7] O Output blue video data, C[3]
23 BLUE[8] O Output blue video data, C[4]
24 BLUE[9] O Output blue video data, C[5]
25 BLUE[10] O Output blue video data, C[6]
26 BLUE[11] O Output blue video data, C[7]
27 Core_VDD - Core power supply (+1.8V)
28 Core_VSS - Core ground
29 IO_VDD - I/O Power supply (+3.3V)
30 IO_VSS - I/O ground
31 HSN I/O
Output Hsync/also CSyncN. The state of this pin is latched during hardware reset-
Pull-Down - I2c device addr is 0x30
Pull-up - I2C device addr is 0x32
Input only used during reset
32 VSN I/O
Output Vsync.
The state of this pin is latched during hardware reset-
Pull-down - Use ABT1015’s internal PLL
Pull-up - Use external PLL to drive video output clock
Input only used during reset, function reserved
33 IO_VDD - I/O Power supply (+3.3V)
34 IO_VSS - I/O ground
35 DE I/O
Output Data Enable.
The state of this pin is latched during hardware reset-
- scaler VTG will start immediately after hardware reset
Pull-up - scaler VTG will be held in reset until released by software {reg. 0x848)
Input only used during reset.
36 GREEN[0] O Output green video data, not used
37 GREEN[1] O Output green video data, not used
38 GREEN[2] O Output green video data, not used
39 GREEN[3] O Output green video data, not used
40 GREEN[4] O Output green video data, Y[0]
41 Core_VDD - Core power supply (+1.8V)
42 Core_VSS - Core ground
43 GREEN[5] O Output green video data, Y[1]
44 IO_VDD - I/O Power supply (+3.3V)
45 IO_VSS - I/O ground
46 GREEN[6] O Output green video data, Y[2]
47 GREEN[7] O Output green video data, Y[3]
To Next Page
