Pin No. Pin Name I/O Description
48 GREEN[8] O Output green video data, Y[4]
49 GREEN[9] O Output green video data, Y[5]
50 GREEN[10] O Output green video data, Y[6]
51 GREEN[11] O Output green video data, Y[7]
52 INVOUTCLK I
Reference clock for the video output clock.
Pull-up or pull-down if not used
53 Core_VDD - Core power supply (+1.8V)
54 Core_VSS - Core ground
55 VOUTCLK O Output video clock
56 PLL_VSS - PLL ground
57 PLL_VDD - PLL power supply (+1.8V)
58 IO_VDD - I/O Power supply (+3.3V)
59 IO_VSS - I/O ground
60 INPUTVCLK I Input video clock
61 SDA I/O Serial data. Output is open drain
62 SCL I Serial clock
63 RESETN I Chip reset
64 Core_VDD - Core power supply (+1.8V)
65 Core_VSS - Core ground
66 INPUTDE I Input data enable
67 INPUTHSN I Input horizontal sync
68 INPUTVSN I Input vertical sync
69 Core_VDD - Core power supply (+1.8V)
70 Core_VSS - Core ground
71 INPUTCB[0] I Cb video input data, not used
72 INOUTCB[1] I Cb video input data, not used
73 IO_VDD - I/O Power supply (+3.3V)
74 IO_VSS - I/O ground
75 INPUTCB[2] I Cb video input data, not used
76 INPUTCB[3] I Cb video input data, not used
77 INPUTCB[4] I Cb video input data, CB[0]
78 INPUTCB[5] I Cb video input data, CB[1]
79 INOUTCB[6] I Cb video input data, CB[2]
80 INOUTCB[7] I Cb video input data, CB[3]
81 INPUTCB[8] I Cb video input data, CB[4]
82 INPUTCB[9] I Cb video input data, CB[5]
83 INOUTCB[10] I Cb video input data, CB[6]
84 INPUTCB[11] I Cb video input data, CB[7]
85 INOUTY[0] I Luma video input data, not used
86 INDUTY[1] I Luma video input data, not used
87 INPUTY[2] I Luma video input data, not used
88 INPUTY[3] I Luma video input data, not used
89 INPUTY[4] I Luma video input data, Y[0]
90 IO_VDD - I/O Power supply (+3.3V)
91 IO_VSS - I/O ground
92 INPUTY[5] I Luma video input data, Y[1]
93 INPUTY[6] I Luma video input data, Y[2]
94 INPUTY[7] I Luma video input data, Y[3]
95 Core_VDD - Core power supply (+1.8V)
96 Core_VSS - Core ground
97 INPUTY[8] I Luma video input data, Y[4]
98 INPUTY[9] I Luma video input data, Y[5]
99 INPUTY[10] I Luma video input data, Y[6]
100 INPUTY[11] I Luma video input data, Y[7]
101 IO_VSS - I/O ground
102 IO_VDD - I/O Power supply (+3.3V)
