STR-DN1010
69
Pin No. Pin Name I/O Description
103 INPUTCR[0] I Cr video input data, not used
104 INPUTCR[1] I Cr video input data, not used
105 INPUTCR[2] I Cr video input data, not used
106 INPUTCR[3] I Cr video input data, not used
107 INPUTCR[4] I Cr video input data, CR[0]
108 INPUTCR[5] I Cr video input data, CR[1]
109 INPUTCR[6] I Cr video input data, CR[2]
110 INPUTCR[7] I Cr video input data, CR[3]
111 INPUTCR[8] I Cr video input data, CR[4]
112 INPUTCR[9] I Cr video input data, CR[5]
113 INPUTCR[10] I Cr video input data, CR[6]
114 INPUTCR[11] I Cr video input data, CR[7]
115 IRQ_N O Reserved. Leave as no-connect
116 TRSTN I
JTAG - Reset
Pull-down to ground if not used
117 TCK I
JTAG - Clock
Pull-up to 3.3V if not used
118 TDO O JTAG - Data Out
119 TDI I
JTAG - Data In
Pull-up to 3.3V if not used
120 TMS I
JTAG - Mode Select
Pull-up to 3.3V if not used
121 IO_VDD - I/O Power supply (+3.3V)
122 RED[4] O Output red video data, CR[0]
123 Core_VDD - Core power supply (+1.8V)
124 Core_vss - Core ground
125 RED[5] O Output red video data, not used
126 RED[6] O Output red video data, not used
127 RED[7] O Output red video data, not used
128 RED[8] O Output red video data, not used
