STR-DN1010
70
DIGITAL VIDEO BOARD (2/5) IC3501 SII9134CTU (HDMI TRANSMITTER)
Pin No. Pin Name I/O Description
1 DE I Data enable signal input from the video controller and HDMI receiver
2 HSYNC I Horizontal sync signal input from the video controller and HDMI receiver
3 VSYNC I Vertical sync signal input from the video controller and HDMI receiver
4 SPDIF I S/PDIF signal input from the HDMI receiver
5 MCLK I Master clock signal input from the HDMI receiver
6 to 9 SD3 to SD0 I PCM audio signal input from the HDMI receiver
10 WS I L/R sampling clock signal input from the HDMI receiver
11 SCK I Bit clock signal input from the HDMI receiver
12 CVCC18 - Power supply terminal (+1.8V)
13 GND - Ground terminal
14 IOVCC33 - Power supply terminal (+3.3V)
15 DCLK I Not used
16 DR0 I Not used
17 DL0 I Not used
18 DR1 I Not used
19 DL1 I Not used
20 DR2 I Not used
21 DL2 I Not used
22 DR3 I Not used
23 DL3 I Not used
24 INT O Interrupt signal output to the HDMI controller
25 RESET# I Reset signal input from the HDMI controller “L”: reset
26 AGND - Ground terminal
27 EXT_SWG - Not used
28 PVCC1 - Power supply terminal (+1.8V)
29 AGND - Ground terminal
30 TXC- O TMDS clock (negative) output to the HDMI OUT connector
31 TXC+ O TMDS clock (positive) output to the HDMI OUT connector
32 AVCC18 - Power supply terminal (+1.8V)
33 TX0- O TMDS data (negative) output to the HDMI OUT connector
34 TX0+ O TMDS data (positive) output to the HDMI OUT connector
35 AGND - Ground terminal
36 TX1- O TMDS data (negative) output to the HDMI OUT connector
37 TX1+ O TMDS data (positive) output to the HDMI OUT connector
38 AVCC18 - Power supply terminal (+1.8V)
39 TX2- O TMDS data (negative) output to the HDMI OUT connector
40 TX2+ O TMDS data (positive) output to the HDMI OUT connector
41 AGND - Ground terminal
42 PVCC2 - Power supply terminal (+1.8V)
43 AGND - Ground terminal
44 AVCC33 - Power supply terminal (+3.3V)
45 DCCPWR5V I Power supply voltage (+5V) input terminal
46 DSCL O I2C clock signal output to the HDMI OUT connector
47 DSDA I/O I2C data bus with the HDMI OUT connector
48 CSCL I I2C clock signal input from the HDMI controller
49 CSDA I/O I2C data bus with the HDMI controller, EEPROM, and HDMI receiver
50 CI2CA - Not used
51 HPD I Hot plug detection signal input from the HDMI OUT connector
52 TMODE - Not used
53 IOVCC33 - Power supply terminal (+3.3V)
54 GND - Ground terminal
55 VPP18 - Power supply terminal (+1.8V)
56 to 63 D35 to D28 I Serial data input from the video controller and HDMI receiver
64 CVCC18 - Power supply terminal (+1.8V)
65 GND - Ground terminal
