STR-DN1010
71
Pin No. Pin Name I/O Description
66 IOVCC33 - Power supply terminal (+3.3V)
67 to 70 D27 to D24 I Serial data input from the HDMI receiver
71 to 75 D23 to D19 I Serial data input from the video controller and HDMI receiver
76 CVCC18 - Power supply terminal (+1.8V)
77 to 79 D18 to D16 I Serial data input from the video controller and HDMI receiver
80 to 83 D15 to D12 I Serial data input from the HDMI receiver
84 to 86 D11 to D9 I Serial data input from the video controller and HDMI receiver
87 GND - Ground terminal
88 IDCK I Output data clock signal input from the HDMI receiver
89 IOVCC33 - Power supply terminal (+3.3V)
90 to 94 D8 to D4 I Serial data input from the video controller and HDMI receiver
95 to 98 D3 to D0 I Serial data input from the HDMI receiver
99 CVCC18 - Power supply terminal (+1.8V)
100 GND - Ground terminal
