Sony STR-DN1010 Service Manual

Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
STR-DN1010
88
< DIODE >
D3201 6-502-398-01 DI SA10QA04
D3202 6-502-398-01 DI SA10QA04
D3502 8-719-049-09 DIODE 1SS367-T3SONY
D3511 6-502-398-01 DI SA10QA04
D3512 8-719-049-09 DIODE 1SS367-T3SONY
D3513 6-502-398-01 DI SA10QA04
D3514 6-502-398-01 DI SA10QA04
D3515 6-502-398-01 DI SA10QA04
D3516 6-502-398-01 DI SA10QA04
< EARTH TERMINAL >
* ET3500 1-780-408-11 TERMINAL, LUG
* ET3504 1-780-408-11 TERMINAL, LUG
< FERRITE BEAD >
FB3000 1-400-862-11 BEAD, FERRITE
FB3201 1-400-862-11 BEAD, FERRITE
FB3202 1-400-862-11 BEAD, FERRITE
FB3203 1-400-862-11 BEAD, FERRITE
FB3204 1-400-862-11 BEAD, FERRITE
* FB3206 1-400-973-21 INDUCTOR (EMI FERRITE)
FB3211 1-216-864-11 SHORT CHIP 0
FB3423 1-216-864-11 SHORT CHIP 0
FB3502 1-414-234-22 INDUCTOR, FERRITE BEAD
FB3503 1-414-234-22 INDUCTOR, FERRITE BEAD
* FB3504 1-400-973-21 INDUCTOR (EMI FERRITE)
FB3505 1-400-862-11 BEAD, FERRITE
FB3510 1-400-862-11 BEAD, FERRITE
FB3512 1-469-532-21 FERRITE, EMI (SMD) (2012)
FB3513 1-400-862-11 BEAD, FERRITE
FB3514 1-400-862-11 BEAD, FERRITE
FB3515 1-216-295-91 SHORT CHIP 0
FB3516 1-216-295-91 SHORT CHIP 0
FB3558 1-469-139-21 FERRITE, EMI (SMD) (2012)
< COIL >
* FL3501 1-457-685-11 COMMON MODE CHOKE COIL
* FL3502 1-457-685-11 COMMON MODE CHOKE COIL
< IC >
IC3000 A-1755-485-A IC R5F3640DDFBR-128 (for SERVICE)
IC3201 6-714-071-01 IC FLI30502AC
IC3202 6-715-196-01 IC ABT1015LQ128
IC3203 6-711-239-01 IC NJM2878F3-18 (TE2)
IC3204 8-759-592-47 IC TC7SZ08FU (TE85R)
IC3205 6-705-673-01 IC TC7PA53FU (TE85L.F)
IC3206 6-707-856-01 IC TC74LCX74FT (EKJ)
IC3207 A-1763-064-A IC SST25VF016B-75-4I-S2AF (for SERVICE)
IC3208 6-712-526-01 IC CAT24C32WI-GT3 (E)
IC3209 6-706-838-01 IC MM1661JHBE
IC3210 6-706-838-01 IC MM1661JHBE
9 IC3500 (Not supplied) IC SII9233ACTU
9 IC3501 (Not supplied) IC SII9134CTU
IC3514 6-707-870-01 IC TC74VHC157FT (EKJ)
IC3515 6-706-838-01 IC MM1661JHBE
IC3516 6-711-116-01 IC NJM2878F3-05 (TE2)
IC3517 6-708-913-01 IC TK73400AU3G0L-C
IC3519 6-714-020-01 IC TK63812AMHGHL-C
IC3521 6-711-116-01 IC NJM2878F3-05 (TE2)
IC3524 6-707-879-01 IC TC74VHC541FT (EKJ)
IC3531 6-709-888-01 IC TC7WHU04FK (T5RSOYF
IC3801 6-709-888-01 IC TC7WHU04FK (T5RSOYF
< COIL >
L3501 1-469-525-91 INDUCTOR 10UH
L3505 1-469-525-91 INDUCTOR 10UH
L3506 1-469-525-91 INDUCTOR 10UH
L3507 1-469-525-91 INDUCTOR 10UH
L3508 1-469-525-91 INDUCTOR 10UH
L3509 1-469-525-91 INDUCTOR 10UH
L3510 1-469-525-91 INDUCTOR 10UH
L3617 1-469-525-91 INDUCTOR 10UH
< RESISTOR>
R3001 1-218-929-11 METAL CHIP 10 5% 1/16W
R3002 1-218-945-11 METAL CHIP 220 5% 1/16W
R3003 1-218-990-81 SHORT CHIP 0
R3004 1-218-965-11 METAL CHIP 10K 5% 1/16W
R3005 1-218-965-11 METAL CHIP 10K 5% 1/16W
R3006 1-218-959-11 METAL CHIP 3.3K 5% 1/16W
R3007 1-218-937-11 METAL CHIP 47 5% 1/16W
R3008 1-218-973-11 METAL CHIP 47K 5% 1/16W
R3009 1-218-957-11 METAL CHIP 2.2K 5% 1/16W
R3010 1-218-937-11 METAL CHIP 47 5% 1/16W
R3011 1-218-957-11 METAL CHIP 2.2K 5% 1/16W
R3012 1-218-937-11 METAL CHIP 47 5% 1/16W
R3013 1-218-933-11 METAL CHIP 22 5% 1/16W
R3014 1-218-933-11 METAL CHIP 22 5% 1/16W
R3017 1-218-965-11 METAL CHIP 10K 5% 1/16W
R3018 1-218-937-11 METAL CHIP 47 5% 1/16W
R3020 1-218-965-11 METAL CHIP 10K 5% 1/16W
R3021 1-218-937-11 METAL CHIP 47 5% 1/16W
R3022 1-218-965-11 METAL CHIP 10K 5% 1/16W
R3026 1-218-965-11 METAL CHIP 10K 5% 1/16W
R3027 1-218-937-11 METAL CHIP 47 5% 1/16W
R3028 1-218-990-81 SHORT CHIP 0
R3029 1-218-965-11 METAL CHIP 10K 5% 1/16W
R3030 1-218-937-11 METAL CHIP 47 5% 1/16W
R3031 1-218-937-11 METAL CHIP 47 5% 1/16W
R3032 1-218-937-11 METAL CHIP 47 5% 1/16W
R3037 1-218-965-11 METAL CHIP 10K 5% 1/16W
R3038 1-218-937-11 METAL CHIP 47 5% 1/16W
R3201 1-208-860-81 METAL CHIP 75 0.5% 1/16W
R3202 1-208-860-81 METAL CHIP 75 0.5% 1/16W
R3203 1-208-871-81 METAL CHIP 220 0.5% 1/16W
R3204 1-208-860-81 METAL CHIP 75 0.5% 1/16W
R3205 1-208-643-11 METAL CHIP 22 0.5% 1/16W
R3206 1-208-643-11 METAL CHIP 22 0.5% 1/16W
R3207 1-208-643-11 METAL CHIP 22 0.5% 1/16W
R3208 1-208-643-11 METAL CHIP 22 0.5% 1/16W
R3209 1-216-295-91 SHORT CHIP 0
R3210 1-218-990-81 SHORT CHIP 0
R3211 1-218-990-81 SHORT CHIP 0
R3214 1-208-957-11 METAL CHIP 820K 0.5% 1/16W
R3215 1-218-933-11 METAL CHIP 22 5% 1/16W
R3216 1-208-957-11 METAL CHIP 820K 0.5% 1/16W
R3217 1-208-957-11 METAL CHIP 820K 0.5% 1/16W
R3218 1-218-933-11 METAL CHIP 22 5% 1/16W
R3219 1-218-933-11 METAL CHIP 22 5% 1/16W
DIGITAL VIDEO
Note: IC3500 and IC3501 cannot exchange with single. When
these parts are damaged, exchange the entire mounted
board.

Sony STR-DN1010 Specifications

General

Impedance	8 Ω
Audio output channels	7.1 channels
HDMI	Yes
Output power	200 W
Dimensions (WxDxH)	430 x 157.5 x 324.5 mm
Supported video modes	1080p
Product color	Black
Connectivity technology	Wired
Headphone outputs	1
Component video (YPbPr/YCbCr) in	3
