Sony STR-DN1010 Service Manual

Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
STR-DN1010
8989
R3220 1-218-933-11 METAL CHIP 22 5% 1/16W
R3221 1-218-933-11 METAL CHIP 22 5% 1/16W
R3222 1-218-941-81 METAL CHIP 100 5% 1/16W
R3223 1-218-935-11 METAL CHIP 33 5% 1/16W
R3224 1-218-935-11 METAL CHIP 33 5% 1/16W
R3225 1-218-965-11 METAL CHIP 10K 5% 1/16W
R3226 1-218-973-11 METAL CHIP 47K 5% 1/16W
R3227 1-218-933-11 METAL CHIP 22 5% 1/16W
R3228 1-218-965-11 METAL CHIP 10K 5% 1/16W
R3229 1-218-935-11 METAL CHIP 33 5% 1/16W
R3230 1-218-935-11 METAL CHIP 33 5% 1/16W
R3231 1-218-961-11 METAL CHIP 4.7K 5% 1/16W
R3232 1-208-957-11 METAL CHIP 820K 0.5% 1/16W
R3233 1-218-961-11 METAL CHIP 4.7K 5% 1/16W
R3234 1-218-961-11 METAL CHIP 4.7K 5% 1/16W
R3235 1-218-935-11 METAL CHIP 33 5% 1/16W
R3236 1-218-935-11 METAL CHIP 33 5% 1/16W
R3238 1-218-965-11 METAL CHIP 10K 5% 1/16W
R3241 1-208-695-11 METAL CHIP 3.3K 0.5% 1/16W
R3242 1-208-695-11 METAL CHIP 3.3K 0.5% 1/16W
R3243 1-208-695-11 METAL CHIP 3.3K 0.5% 1/16W
R3244 1-208-695-11 METAL CHIP 3.3K 0.5% 1/16W
R3245 1-218-965-11 METAL CHIP 10K 5% 1/16W
R3247 1-218-961-11 METAL CHIP 4.7K 5% 1/16W
R3248 1-218-990-81 SHORT CHIP 0
R3249 1-218-933-11 METAL CHIP 22 5% 1/16W
R3250 1-218-990-81 SHORT CHIP 0
R3251 1-218-933-11 METAL CHIP 22 5% 1/16W
R3252 1-218-965-11 METAL CHIP 10K 5% 1/16W
R3253 1-218-965-11 METAL CHIP 10K 5% 1/16W
R3254 1-218-937-11 METAL CHIP 47 5% 1/16W
R3255 1-218-937-11 METAL CHIP 47 5% 1/16W
R3256 1-218-990-81 SHORT CHIP 0
R3257 1-218-937-11 METAL CHIP 47 5% 1/16W
R3258 1-218-938-11 METAL CHIP 56 5% 1/16W
R3259 1-218-938-11 METAL CHIP 56 5% 1/16W
R3260 1-218-938-11 METAL CHIP 56 5% 1/16W
R3261 1-218-938-11 METAL CHIP 56 5% 1/16W
R3262 1-218-938-11 METAL CHIP 56 5% 1/16W
R3264 1-218-963-11 METAL CHIP 6.8K 5% 1/16W
R3266 1-218-990-81 SHORT CHIP 0
R3267 1-218-990-81 SHORT CHIP 0
R3268 1-218-990-81 SHORT CHIP 0
R3269 1-218-990-81 SHORT CHIP 0
R3270 1-218-958-11 METAL CHIP 2.7K 5% 1/16W
R3271 1-218-958-11 METAL CHIP 2.7K 5% 1/16W
R3272 1-218-958-11 METAL CHIP 2.7K 5% 1/16W
R3273 1-218-958-11 METAL CHIP 2.7K 5% 1/16W
R3274 1-218-965-11 METAL CHIP 10K 5% 1/16W
R3275 1-218-958-11 METAL CHIP 2.7K 5% 1/16W
R3276 1-218-958-11 METAL CHIP 2.7K 5% 1/16W
R3277 1-218-965-11 METAL CHIP 10K 5% 1/16W
R3278 1-208-957-11 METAL CHIP 820K 0.5% 1/16W
R3281 1-218-941-81 METAL CHIP 100 5% 1/16W
R3282 1-218-965-11 METAL CHIP 10K 5% 1/16W
R3284 1-218-965-11 METAL CHIP 10K 5% 1/16W
R3285 1-218-929-11 METAL CHIP 10 5% 1/16W
R3286 1-218-929-11 METAL CHIP 10 5% 1/16W
R3287 1-218-929-11 METAL CHIP 10 5% 1/16W
R3288 1-218-949-11 METAL CHIP 470 5% 1/16W
R3289 1-218-949-11 METAL CHIP 470 5% 1/16W
R3290 1-218-949-11 METAL CHIP 470 5% 1/16W
R3291 1-218-949-11 METAL CHIP 470 5% 1/16W
R3292 1-218-941-81 METAL CHIP 100 5% 1/16W
R3296 1-218-933-11 METAL CHIP 22 5% 1/16W
R3297 1-218-953-11 METAL CHIP 1K 5% 1/16W
R3300 1-218-973-11 METAL CHIP 47K 5% 1/16W
R3302 1-218-937-11 METAL CHIP 47 5% 1/16W
R3331 1-218-965-11 METAL CHIP 10K 5% 1/16W
R3404 1-218-990-81 SHORT CHIP 0
R3405 1-218-929-11 METAL CHIP 10 5% 1/16W
R3406 1-218-929-11 METAL CHIP 10 5% 1/16W
R3407 1-218-929-11 METAL CHIP 10 5% 1/16W
R3408 1-218-935-11 METAL CHIP 33 5% 1/16W
R3409 1-218-935-11 METAL CHIP 33 5% 1/16W
R3410 1-218-935-11 METAL CHIP 33 5% 1/16W
R3411 1-218-935-11 METAL CHIP 33 5% 1/16W
R3514 1-218-973-11 METAL CHIP 47K 5% 1/16W
R3521 1-218-941-81 METAL CHIP 100 5% 1/16W
R3522 1-218-941-81 METAL CHIP 100 5% 1/16W
R3530 1-218-933-11 METAL CHIP 22 5% 1/16W
R3531 1-218-933-11 METAL CHIP 22 5% 1/16W
R3536 1-218-933-11 METAL CHIP 22 5% 1/16W
R3540 1-218-933-11 METAL CHIP 22 5% 1/16W
R3544 1-218-929-11 METAL CHIP 10 5% 1/16W
R3545 1-218-941-81 METAL CHIP 100 5% 1/16W
R3546 1-218-989-11 METAL CHIP 1M 5% 1/16W
R3548 1-216-805-11 METAL CHIP 47 5% 1/10W
R3549 1-216-805-11 METAL CHIP 47 5% 1/10W
R3550 1-216-805-11 METAL CHIP 47 5% 1/10W
R3551 1-216-805-11 METAL CHIP 47 5% 1/10W
R3552 1-216-805-11 METAL CHIP 47 5% 1/10W
R3554 1-216-805-11 METAL CHIP 47 5% 1/10W
R3556 1-216-805-11 METAL CHIP 47 5% 1/10W
R3557 1-216-813-11 METAL CHIP 220 5% 1/10W
R3563 1-218-941-81 METAL CHIP 100 5% 1/16W
R3564 1-216-864-11 SHORT CHIP 0
R3565 1-218-929-11 METAL CHIP 10 5% 1/16W
R3566 1-218-929-11 METAL CHIP 10 5% 1/16W
R3567 1-218-929-11 METAL CHIP 10 5% 1/16W
R3568 1-218-937-11 METAL CHIP 47 5% 1/16W
R3569 1-218-950-81 METAL CHIP 560 5% 1/16W
R3570 1-218-937-11 METAL CHIP 47 5% 1/16W
R3571 1-218-937-11 METAL CHIP 47 5% 1/16W
R3572 1-218-937-11 METAL CHIP 47 5% 1/16W
R3573 1-218-937-11 METAL CHIP 47 5% 1/16W
R3574 1-218-937-11 METAL CHIP 47 5% 1/16W
R3575 1-218-937-11 METAL CHIP 47 5% 1/16W
R3576 1-218-929-11 METAL CHIP 10 5% 1/16W
R3577 1-218-929-11 METAL CHIP 10 5% 1/16W
R3578 1-218-961-11 METAL CHIP 4.7K 5% 1/16W
R3579 1-218-973-11 METAL CHIP 47K 5% 1/16W
R3580 1-208-883-81 METAL CHIP 680 0.5% 1/16W
R3581 1-218-941-81 METAL CHIP 100 5% 1/16W
R3582 1-220-876-81 METAL CHIP 18 0.5% 1/16W
R3583 1-218-929-11 METAL CHIP 10 5% 1/16W
R3584 1-218-929-11 METAL CHIP 10 5% 1/16W
R3585 1-218-973-11 METAL CHIP 47K 5% 1/16W
R3593 1-218-965-11 METAL CHIP 10K 5% 1/16W
R3594 1-218-973-11 METAL CHIP 47K 5% 1/16W
