Sony STR-DN1010 Service Manual

Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
STR-DN1010
9797
R637 1-218-847-11 METAL CHIP 1K 0.5% 1/10W
R638 1-218-891-11 METAL CHIP 68K 0.5% 1/10W
R639 1-208-445-41 RES-CHIP 2.2K 2% 1/10W
R640 1-208-826-11 METAL CHIP 68K 0.5% 1/10W
R641 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R642 1-216-844-11 METAL CHIP 82K 5% 1/10W
R643 1-216-818-11 METAL CHIP 560 5% 1/10W
R644 1-249-405-11 CARBON 100 5% 1/4W
R645 1-249-405-11 CARBON 100 5% 1/4W
R646 1-216-214-00 RES-CHIP 4.7K 2% 1/8W
R647 1-240-855-91 CARBON 6.2K 5% 1/4W
R648 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R649 1-216-835-11 METAL CHIP 15K 5% 1/10W
R650 1-216-843-11 METAL CHIP 68K 5% 1/10W
R651 1-249-389-11 CARBON 4.7 5% 1/4W
R652 1-249-393-11 CARBON 10 5% 1/4W
R653 1-216-841-11 METAL CHIP 47K 5% 1/10W
R654 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R655 1-216-844-11 METAL CHIP 82K 5% 1/10W
R656 1-216-818-11 METAL CHIP 560 5% 1/10W
R657 1-249-405-11 CARBON 100 5% 1/4W
R658 1-249-405-11 CARBON 100 5% 1/4W
R659 1-216-214-00 RES-CHIP 4.7K 2% 1/8W
R660 1-240-855-91 CARBON 6.2K 5% 1/4W
R661 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R662 1-216-835-11 METAL CHIP 15K 5% 1/10W
R663 1-216-843-11 METAL CHIP 68K 5% 1/10W
R664 1-249-389-11 CARBON 4.7 5% 1/4W
R665 1-249-393-11 CARBON 10 5% 1/4W
R666 1-216-841-11 METAL CHIP 47K 5% 1/10W
R667 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R668 1-216-844-11 METAL CHIP 82K 5% 1/10W
R669 1-216-818-11 METAL CHIP 560 5% 1/10W
R670 1-249-405-11 CARBON 100 5% 1/4W
R671 1-249-405-11 CARBON 100 5% 1/4W
R672 1-216-214-00 RES-CHIP 4.7K 2% 1/8W
R673 1-240-855-91 CARBON 6.2K 5% 1/4W
R674 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R675 1-216-835-11 METAL CHIP 15K 5% 1/10W
R676 1-216-843-11 METAL CHIP 68K 5% 1/10W
R677 1-249-389-11 CARBON 4.7 5% 1/4W
R678 1-249-393-11 CARBON 10 5% 1/4W
R679 1-216-841-11 METAL CHIP 47K 5% 1/10W
R680 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R681 1-216-844-11 METAL CHIP 82K 5% 1/10W
R682 1-216-818-11 METAL CHIP 560 5% 1/10W
R683 1-249-405-11 CARBON 100 5% 1/4W
R684 1-249-405-11 CARBON 100 5% 1/4W
R685 1-216-214-00 RES-CHIP 4.7K 2% 1/8W
R686 1-240-855-91 CARBON 6.2K 5% 1/4W
R687 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R688 1-216-835-11 METAL CHIP 15K 5% 1/10W
R689 1-216-843-11 METAL CHIP 68K 5% 1/10W
R690 1-249-389-11 CARBON 4.7 5% 1/4W
R691 1-249-393-11 CARBON 10 5% 1/4W
R692 1-216-841-11 METAL CHIP 47K 5% 1/10W
R693 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R694 1-216-844-11 METAL CHIP 82K 5% 1/10W
R695 1-216-818-11 METAL CHIP 560 5% 1/10W
R696 1-249-405-11 CARBON 100 5% 1/4W
R697 1-249-405-11 CARBON 100 5% 1/4W
R698 1-216-214-00 RES-CHIP 4.7K 2% 1/8W
R699 1-240-855-91 CARBON 6.2K 5% 1/4W
R700 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R701 1-216-835-11 METAL CHIP 15K 5% 1/10W
R702 1-216-843-11 METAL CHIP 68K 5% 1/10W
R703 1-249-389-11 CARBON 4.7 5% 1/4W
R704 1-249-393-11 CARBON 10 5% 1/4W
R705 1-216-841-11 METAL CHIP 47K 5% 1/10W
R706 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R707 1-216-844-11 METAL CHIP 82K 5% 1/10W
R708 1-216-818-11 METAL CHIP 560 5% 1/10W
R709 1-249-405-11 CARBON 100 5% 1/4W
R710 1-249-405-11 CARBON 100 5% 1/4W
R711 1-216-214-00 RES-CHIP 4.7K 2% 1/8W
R712 1-240-855-91 CARBON 6.2K 5% 1/4W
R713 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R714 1-216-835-11 METAL CHIP 15K 5% 1/10W
R715 1-216-843-11 METAL CHIP 68K 5% 1/10W
R716 1-249-389-11 CARBON 4.7 5% 1/4W
R717 1-249-393-11 CARBON 10 5% 1/4W
R718 1-216-841-11 METAL CHIP 47K 5% 1/10W
R719 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R720 1-216-844-11 METAL CHIP 82K 5% 1/10W
R721 1-216-818-11 METAL CHIP 560 5% 1/10W
R722 1-249-405-11 CARBON 100 5% 1/4W
R723 1-249-405-11 CARBON 100 5% 1/4W
R724 1-216-214-00 RES-CHIP 4.7K 2% 1/8W
R725 1-240-855-91 CARBON 6.2K 5% 1/4W
R726 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R727 1-216-835-11 METAL CHIP 15K 5% 1/10W
R728 1-216-843-11 METAL CHIP 68K 5% 1/10W
R729 1-249-389-11 CARBON 4.7 5% 1/4W
R730 1-249-393-11 CARBON 10 5% 1/4W
R731 1-216-841-11 METAL CHIP 47K 5% 1/10W
R732 1-216-841-11 METAL CHIP 47K 5% 1/10W
R733 1-216-841-11 METAL CHIP 47K 5% 1/10W
R734 1-216-841-11 METAL CHIP 47K 5% 1/10W
R735 1-216-841-11 METAL CHIP 47K 5% 1/10W
R736 1-216-841-11 METAL CHIP 47K 5% 1/10W
R737 1-216-841-11 METAL CHIP 47K 5% 1/10W
R738 1-216-841-11 METAL CHIP 47K 5% 1/10W
R739 1-216-845-11 METAL CHIP 100K 5% 1/10W
R740 1-216-845-11 METAL CHIP 100K 5% 1/10W
R741 1-216-845-11 METAL CHIP 100K 5% 1/10W
R742 1-216-845-11 METAL CHIP 100K 5% 1/10W
R743 1-216-845-11 METAL CHIP 100K 5% 1/10W
R744 1-216-845-11 METAL CHIP 100K 5% 1/10W
R745 1-216-845-11 METAL CHIP 100K 5% 1/10W
R746 1-216-069-00 METAL CHIP 6.8K 5% 1/10W
R747 1-216-081-00 METAL CHIP 22K 5% 1/10W
R748 1-216-081-00 METAL CHIP 22K 5% 1/10W
R755 1-247-758-11 CARBON 3.3K 5% 1/2W
(UK, AUS, ECE)
R756 1-247-758-11 CARBON 3.3K 5% 1/2W
(UK, AUS, ECE)
R757 1-247-758-11 CARBON 3.3K 5% 1/2W
(UK, AUS, ECE)
R758 1-247-758-11 CARBON 3.3K 5% 1/2W
(UK, AUS, ECE)
MAIN

Sony STR-DN1010 Specifications

General

Impedance	8 Ω
Audio output channels	7.1 channels
HDMI	Yes
Output power	200 W
Dimensions (WxDxH)	430 x 157.5 x 324.5 mm
Supported video modes	1080p
Product color	Black
Connectivity technology	Wired
Headphone outputs	1
Component video (YPbPr/YCbCr) in	3
