Sony STR-DN1010 Service Manual

Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
STR-DN1010
98
R759 1-247-758-11 CARBON 3.3K 5% 1/2W
(UK, AUS, ECE)
R760 1-247-758-11 CARBON 3.3K 5% 1/2W
(UK, AUS, ECE)
R761 1-247-758-11 CARBON 3.3K 5% 1/2W
(UK, AUS, ECE)
R762 1-216-377-11 METAL OXIDE 4.7 5% 2W
(UK, AUS, ECE)
R763 1-216-377-11 METAL OXIDE 4.7 5% 2W
(UK, AUS, ECE)
R764 1-216-789-11 METAL CHIP 2.2 5% 1/10W
< RELAY >
RY406 1-755-593-11 RELAY
RY422 1-755-307-21 RELAY
RY423 1-755-307-21 RELAY
RY424 1-755-307-21 RELAY
RY425 1-755-307-21 RELAY
RY441 1-755-267-11 RELAY
RY451 1-755-307-21 RELAY
< TERMINAL >
TB504 1-780-745-11 TERMINAL BOARD (SP) (2P)
(SPEAKERS SURROUND BACK/FRONT HIGH/
BI-AMP/FRONT B)
TB505 1-780-746-11 TERMINAL BOARD (SP) (4P)
(SPEAKERS SURROUND BACK/FRONT HIGH/
BI-AMP/FRONT B/CENTER)
TB506 1-780-747-11 TERMINAL BOARD (SP) (8P)
(SPEAKERS SURROUND/FRONT A)
************************************************************
POWER KEY BOARD
****************
< CONNECTOR >
* CNP102 1-564-506-11 PLUG, CONNECTOR 3P
< SWITCH >
S114 1-771-410-21 SWITCH, TACTILE (I/
1
)
************************************************************
SAIR BOARD
**********
< CAPACITOR >
C863 1-126-964-11 ELECT 10uF 20% 50V
C864 1-126-964-11 ELECT 10uF 20% 50V
< CONNECTOR >
CN861 1-770-411-11 CONNECTOR, BOARD TO BOARD 20P
CN862 1-821-744-21 CONNECTOR, CARD EDGE
< RESISTOR >
R862 1-216-864-11 SHORT CHIP 0
R863 1-216-864-11 SHORT CHIP 0
R864 1-216-864-11 SHORT CHIP 0
R866 1-216-833-11 METAL CHIP 10K 5% 1/10W
R867 1-216-833-11 METAL CHIP 10K 5% 1/10W
R868 1-216-833-11 METAL CHIP 10K 5% 1/10W
R869 1-216-864-11 SHORT CHIP 0
R870 1-216-864-11 SHORT CHIP 0
R871 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R872 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R873 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R874 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
************************************************************
A-1755-476-A STANDBY DCDC BOARD, COMPLETE
*****************************
7-685-646-79 SCREW +BVTP 3X8 TYPE2 IT-3
< CAPACITOR >
C900 1-126-941-11 ELECT 470uF 20% 25V
C901 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C911 1-126-942-61 ELECT 1000uF 20% 25V
C912 1-111-235-61 ELECT 10000uF 20% 25V
C913 1-137-958-91 MYLAR 0.22uF 5% 100V
C914 1-137-958-91 MYLAR 0.22uF 5% 100V
C915 1-137-980-91 CERAMIC CHIP 0.47uF 10% 50V
C916 1-126-947-11 ELECT 47uF 20% 35V
C918 1-125-891-11 CERAMIC CHIP 0.47uF 10% 10V
C919 1-125-891-11 CERAMIC CHIP 0.47uF 10% 10V
C920 1-126-964-11 ELECT 10uF 20% 50V
C921 1-126-943-11 ELECT 2200uF 20% 25V
C922 1-126-943-11 ELECT 2200uF 20% 25V
C923 1-136-497-81 FILM 0.1uF 5% 50V
C950 1-128-950-21 ELECT 1000uF 20% 16V
C951 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C952 1-128-959-21 ELECT 1000uF 20% 35V
C960 1-128-951-21 ELECT 2200uF 20% 16V
C961 1-100-597-91 CERAMIC CHIP 0.1uF 10% 25V
C962 1-128-955-21 ELECT 2200uF 20% 25V
C963 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C964 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C965 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C966 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
< CONNECTOR >
* CN905 1-564-508-11 PLUG, CONNECTOR 5P
* CNP901 1-565-792-11 PIN, CONNECTOR (3.96mm PITCH) 2P
* 0 CNP906 1-793-660-11 PIN, CONNECTOR (PC BOARD) 3P
* CNP907 1-564-507-11 PLUG, CONNECTOR 4P
< DIODE >
D901 8-719-053-18 DIODE 1SR154-400TE-25
D902 8-719-053-18 DIODE 1SR154-400TE-25
D903 8-719-053-18 DIODE 1SR154-400TE-25
D904 8-719-053-18 DIODE 1SR154-400TE-25
D905 6-500-335-01 DIODE MC2838-T112-1
D907 6-501-817-01 DIODE MA2J1110GLS0
D908 8-719-061-07 DIODE D5SBA60-F
D910 8-719-069-56 DI UDZSUSTE-176.2B
D950 6-502-218-01 DI RB060M-30TR
D960 8-719-312-08 DIODE FMB-G16L
D961 8-719-053-18 DIODE 1SR154-400TE-25
< FUSE >
0 F901 1-523-086-11 FUSE 3.15A 250V
0 F902 1-523-086-11 FUSE 3.15A 250V
POWER KEY SAIR STANDBY DCDCMAIN

Sony STR-DN1010 Specifications

General

Impedance	8 Ω
Audio output channels	7.1 channels
HDMI	Yes
Output power	200 W
Dimensions (WxDxH)	430 x 157.5 x 324.5 mm
Supported video modes	1080p
Product color	Black
Connectivity technology	Wired
Headphone outputs	1
Component video (YPbPr/YCbCr) in	3
