AM tuner section
Tuning range
Antenna (aerial) Loop antenna (aerial)
Intermediate frequency
450 kHz
Video section
Inputs/Outputs
Video: 1 Vp-p, 75 ohms
COMPONENT VIDEO:
Y: 1 Vp-p, 75 ohms
P
B: 0.7 Vp-p, 75 ohms
P
R: 0.7 Vp-p, 75 ohms
80 MHz HD Pass Through
HDMI Video
Input/Output (HDMI Repeater block)
Area Tuning scale
10 kHz step 9 kHz step
USA, Canada 530 kHz –
1,710 kHz
531 kHz –
1,710 kHz
Europe, Australia – 531 kHz –
1,602 kHz
Format 2D
3D
Frame packing
Side-by-Side
(Half)
Over-Under
(Top-and-Bottom)
1920 × 1080p @ 59.94/60 Hz a – aa
1920 × 1080p @ 50 Hz a – aa
1920 × 1080p @ 29.97/30 Hz aa a a
1920 × 1080p @ 23.98/24 Hz aa a a
1920 × 1080i @ 59.94/60 Hz aa a a
1920 × 1080i @ 50 Hz aa a a
1280 × 720p @ 59.94/60 Hz aa a a
1280 × 720p @ 50 Hz aa a a
1280 × 720p @ 29.97/30 Hz aa a a
1280 × 720p @ 23.98/24 Hz aa a a
720 × 480p @ 59.94/60 Hz a –– –
720 × 576p @ 50 Hz a –– –
640 × 480p @ 59.94/60 Hz a –– –
