46
STR-K680/K780
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
R137 1-249-419-11 CARBON 1.5K 5% 1/4W
R138 1-249-421-11 CARBON 2.2K 5% 1/4W
R139 1-247-847-91 CARBON 4.7K 5% 1/4W
R150 1-249-440-11 CARBON 82K 5% 1/4W
R153 1-247-807-31 CARBON 100 5% 1/4W
R172 1-247-807-31 CARBON 100 5% 1/4W
R173 1-247-807-31 CARBON 100 5% 1/4W
R174 1-247-807-31 CARBON 100 5% 1/4W
R175 1-249-393-11 CARBON 10 5% 1/4W
R198 1-249-381-11 CARBON 1 5% 1/4W
(K680)
R198 1-249-385-11 CARBON 2.2 5% 1/4W
(K780)
R199 1-249-381-11 CARBON 1 5% 1/4W
(K680)
R199 1-249-385-11 CARBON 2.2 5% 1/4W
(K780)
< VARIABLE RESISTOR >
RV102 1-418-725-41 ENCODER, ROTARY (12 TYPE)
(MASTER VOLUME)
< SWITCH >
S100 1-771-410-21 SWITCH, TACTILE (INPUT MODE)
S101 1-771-410-21 SWITCH, TACTILE (>)
S102 1-771-410-21 SWITCH, TACTILE (–)
S103 1-771-410-21 SWITCH, TACTILE (+)
S104 1-771-410-21 SWITCH, TACTILE (<)
S105 1-771-410-21 SWITCH, TACTILE (FM)
S106 1-771-410-21 SWITCH, TACTILE (AM)
S107 1-771-410-21 SWITCH, TACTILE (MAIN MENU)
S108 1-771-410-21 SWITCH, TACTILE (ENTER)
S110 1-771-410-21 SWITCH, TACTILE (MUSIC)
S111 1-771-410-21 SWITCH, TACTILE (MOVIE)
S112 1-771-410-21 SWITCH, TACTILE (A. F. D.)
S113 1-771-410-21 SWITCH, TACTILE (2CH)
S116 1-771-410-21 SWITCH, TACTILE (SA-CD/CD)
S137 1-771-410-21 SWITCH, TACTILE (VIDEO 1)
S138 1-771-410-21 SWITCH, TACTILE (VIDEO 2)
S139 1-771-410-21 SWITCH, TACTILE (DVD)
*************************************************************
HEADPHONE BOARD
*****************
< CONNECTOR >
CNP701 1-691-766-11 PLUG (MICRO CONNECTOR) 4P
< JACK >
J700 1-815-314-21 JACK (PHONES)
*************************************************************
A-1157-611-A MAIN BOARD, COMPLETE (E51)
A-1157-659-A MAIN BOARD, COMPLETE (MX)
A-1157-667-A MAIN BOARD, COMPLETE (AR)
A-1157-674-A MAIN BOARD, COMPLETE (K780)
*********************
7-685-646-79 SCREW +BVTP 3X8 TYPE2 IT-3
< CAPACITOR >
C400 1-127-888-11 CERAMIC 0.1uF 10% 50V
(K780)
C402 1-126-964-11 ELECT 10uF 20% 50V
C403 1-162-294-31 CERAMIC 0.001uF 10% 50V
C404 1-162-294-31 CERAMIC 0.001uF 10% 50V
C421 1-126-963-11 ELECT 4.7uF 20% 50V
C422 1-126-963-11 ELECT 4.7uF 20% 50V
C423 1-126-963-11 ELECT 4.7uF 20% 50V
C424 1-126-963-11 ELECT 4.7uF 20% 50V
C425 1-126-963-11 ELECT 4.7uF 20% 50V
C426 1-126-963-11 ELECT 4.7uF 20% 50V
C431 1-126-961-11 ELECT 2.2uF 20% 50V
C432 1-126-961-11 ELECT 2.2uF 20% 50V
C433 1-126-961-11 ELECT 2.2uF 20% 50V
C434 1-126-961-11 ELECT 2.2uF 20% 50V
C435 1-126-961-11 ELECT 2.2uF 20% 50V
C436 1-126-961-11 ELECT 2.2uF 20% 50V
C446 1-126-963-11 ELECT 4.7uF 20% 50V
C452 1-126-964-11 ELECT 10uF 20% 50V
C471 1-104-658-91 ELECT 100uF 20% 10V
C472 1-127-888-11 CERAMIC 0.1uF 10% 50V
C482 1-127-888-11 CERAMIC 0.1uF 10% 50V
C484 1-127-888-11 CERAMIC 0.1uF 10% 50V
C500 1-128-579-11 ELECT 2.2uF 20% 100V
C501 1-126-963-11 ELECT 4.7uF 20% 50V
C502 1-128-809-11 CERAMIC 100PF 5% 50V
C503 1-128-809-11 CERAMIC 100PF 5% 50V
C504 1-102-233-00 CERAMIC 33PF 10% 500V
C506 1-107-583-11 CERAMIC 3PF 0.25PF 500V
C507 1-104-658-91 ELECT 100uF 20% 10V
C508 1-126-947-11 ELECT 47uF 20% 35V
C511 1-162-815-11 CERAMIC 47PF 5% 500V
C512 1-162-815-11 CERAMIC 47PF 5% 500V
C513 1-128-813-11 CERAMIC 220PF 5% 50V
C514 1-127-876-11 CERAMIC 0.01uF 10% 50V
C515 1-126-964-11 ELECT 10uF 20% 50V
C516 1-136-157-00 FILM 0.022uF 5% 50V
C529 1-127-876-11 CERAMIC 0.01uF 10% 50V
C549 1-127-876-11 CERAMIC 0.01uF 10% 50V
C551 1-126-963-11 ELECT 4.7uF 20% 50V
C552 1-128-809-11 CERAMIC 100PF 5% 50V
C553 1-128-809-11 CERAMIC 100PF 5% 50V
C554 1-102-233-00 CERAMIC 33PF 10% 500V
C556 1-107-583-11 CERAMIC 3PF 0.25PF 500V
C557 1-104-658-91 ELECT 100uF 20% 10V
C558 1-126-947-11 ELECT 47uF 20% 35V
C561 1-162-815-11 CERAMIC 47PF 5% 500V
C562 1-162-815-11 CERAMIC 47PF 5% 500V
C563 1-128-813-11 CERAMIC 220PF 5% 50V
C564 1-127-876-11 CERAMIC 0.01uF 10% 50V
C565 1-126-964-11 ELECT 10uF 20% 50V
C566 1-136-157-00 FILM 0.022uF 5% 50V
C590 1-136-171-00 FILM 0.33uF 5% 50V
(K680)
C592 1-136-175-00 FILM 0.68uF 5% 50V
(K680)
HEADPHONE MAINDISPLAY
