52
STR-K680/K780
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
VIDEO BOARD (K780)
***********
< CAPACITOR >
C201 1-128-805-11 CERAMIC 47PF 5% 50V
C206 1-126-964-11 ELECT 10uF 20% 50V
C207 1-126-964-11 ELECT 10uF 20% 50V
C208 1-126-964-11 ELECT 10uF 20% 50V
C210 1-126-964-11 ELECT 10uF 20% 50V
C213 1-126-934-11 ELECT 220uF 20% 16V
C214 1-164-159-11 CERAMIC 0.1uF 50V
C215 1-164-159-11 CERAMIC 0.1uF 50V
C248 1-128-825-11 CERAMIC 2200PF 5% 50V
C250 1-128-825-11 CERAMIC 2200PF 5% 50V
C251 1-126-964-11 ELECT 10uF 20% 50V
C252 1-126-964-11 ELECT 10uF 20% 50V
C253 1-126-964-11 ELECT 10uF 20% 50V
C254 1-126-964-11 ELECT 10uF 20% 50V
C255 1-126-964-11 ELECT 10uF 20% 50V
C256 1-126-964-11 ELECT 10uF 20% 50V
C257 1-127-888-11 CERAMIC 0.1uF 10% 50V
C258 1-126-947-11 ELECT 47uF 20% 35V
C259 1-127-888-11 CERAMIC 0.1uF 10% 50V
C260 1-126-947-11 ELECT 47uF 20% 35V
C809 1-126-934-11 ELECT 220uF 20% 16V
C825 1-164-159-11 CERAMIC 0.1uF 50V
C826 1-164-159-11 CERAMIC 0.1uF 50V
< CONNECTOR >
CNP156 1-691-765-11 PLUG (MICRO CONNECTOR) 3P
CNS250 1-569-315-11 SOCKET, CONNECTOR 5P
< IC >
IC203 8-759-333-84 IC NJM2279D
IC251 6-707-363-01 IC NJM2586AL
IC804 8-759-245-79 IC TA79005S
IC807 8-759-231-53 IC TA7805S
< JACK >
J201 1-815-043-11 JACK, PIN 2P
(VIDEO IN/VIDEO 1, VIDEO OUT/MONITOR)
J203 1-815-043-11 JACK, PIN 2P
(VIDEO IN/DVD, VIIDEO IN/VIDEO 2)
J251 1-816-592-11 JACK, PIN 9P (COMPONENT VIDEO)
< RESISTOR >
R201 1-247-804-11 CARBON 75 5% 1/4W
R218 1-247-804-11 CARBON 75 5% 1/4W
R220 1-247-804-11 CARBON 75 5% 1/4W
R221 1-247-804-11 CARBON 75 5% 1/4W
R250 1-247-804-11 CARBON 75 5% 1/4W
R251 1-247-804-11 CARBON 75 5% 1/4W
R252 1-247-804-11 CARBON 75 5% 1/4W
R253 1-247-831-91 CARBON 1K 5% 1/4W
R254 1-247-831-91 CARBON 1K 5% 1/4W
R255 1-247-831-91 CARBON 1K 5% 1/4W
R256 1-247-804-11 CARBON 75 5% 1/4W
R257 1-247-804-11 CARBON 75 5% 1/4W
R258 1-247-804-11 CARBON 75 5% 1/4W
R259 1-247-804-11 CARBON 75 5% 1/4W
R260 1-247-804-11 CARBON 75 5% 1/4W
R261 1-247-804-11 CARBON 75 5% 1/4W
R262 1-247-863-91 CARBON 22K 5% 1/4W
*************************************************************
MISCELLANEOUS
**************
8 1-829-004-11 WIRE (FLAT TYPE) (19 CORE)
0 59 1-696-847-11 CORD, POWER (AUS)
0 59 1-777-071-82 CORD, POWER (E51, AEP, UK, RU, SP, SP6)
0 59 1-783-941-11 CORD, POWER (AR)
0 59 1-829-627-11 POWER-SUPPLY CORD (MX)
61 1-828-963-11 WIRE (FLAT TYPE) (11 CORE)
(EXCEPT AEP, UK, RU)
61 1-828-980-11 WIRE (FLAT TYPE) (15 CORE) (AEP, UK, RU)
62 1-828-936-11 WIRE (FLAT TYPE) (5 CORE) (K780)
0 F901 1-532-203-00 FUSE, TIME-LAG (T2A/250V)(E51)
0 F901 1-532-350-00 FUSE, TIME-LAG (T4A/250V)(MX)
0 F901 1-532-464-33 FUSE (T2.5AL/250V)(EXCEPT E51, MX)
Q503 6-702-390-01 IC MN2488-OPY-MK
Q504 6-702-391-01 IC MP1620-OPY-MK
Q553 6-702-390-01 IC MN2488-OPY-MK
Q554 6-702-391-01 IC MP1620-OPY-MK
Q603 6-702-390-01 IC MN2488-OPY-MK
Q604 6-702-391-01 IC MP1620-OPY-MK
Q653 6-702-390-01 IC MN2488-OPY-MK
Q654 6-702-391-01 IC MP1620-OPY-MK
Q703 6-702-390-01 IC MN2488-OPY-MK
Q704 6-702-391-01 IC MP1620-OPY-MK
Q753 6-702-390-01 IC MN2488-OPY-MK (K680)
Q754 6-702-391-01 IC MP1620-OPY-MK (K680)
0 T901 1-443-916-11 POWER TRANSFORMER
(AEP, UK, RU, AUS)
0 T901 1-443-918-11 POWER TRANSFORMER (SP, SP6, AR)
0 T901 1-443-919-11 POWER TRANSFORMER (E51)
0 T901 1-443-920-11 POWER TRANSFORMER (MX)
TN1 1-693-675-21 TUNER (K680)
TN1 1-693-676-11 TUNER (AEP, UK, RU)
TN1 1-693-678-11 TUNER (SP, SP6, AUS)
VIDEO
Ver. 1.3
