Sony STR-K685 - Digital Display

45
STR-K685
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
DISPLAY
R1570 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1571 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1572 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1573 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1574 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1635 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1636 1-216-833-11 METAL CHIP 10K 5% 1/10W
R1943 1-216-841-11 METAL CHIP 47K 5% 1/10W
R1946 1-216-809-11 METAL CHIP 100 5% 1/10W
R1947 1-216-801-11 METAL CHIP 22 5% 1/10W
R1948 1-216-809-11 METAL CHIP 100 5% 1/10W
< NETWORK RESISTOR >
RB1500 1-233-576-11 RES, CHIP NETWORK 100 (3216)
RB1501 1-233-576-11 RES, CHIP NETWORK 100 (3216)
RB1502 1-233-576-11 RES, CHIP NETWORK 100 (3216)
RB1503 1-233-576-11 RES, CHIP NETWORK 100 (3216)
RB1504 1-233-576-11 RES, CHIP NETWORK 100 (3216)
RB1506 1-233-576-11 RES, CHIP NETWORK 100 (3216)
RB1507 1-233-576-11 RES, CHIP NETWORK 100 (3216)
RB1508 1-233-576-11 RES, CHIP NETWORK 100 (3216)
< VIBRATOR >
X1101 1-813-448-21 PIEZOELECTRIC OSCILLATOR (24MHz)
X1301 1-795-126-21 VIBRATOR, CRYSTAL (12.288MHz)
X1502 1-813-276-21 QUARTZ CRYSTAL (13.9MHz)
*************************************************************
A-1221-904-A DISPLAY BOARD, COMPLETE (E51)
A-1249-605-A DISPLAY BOARD, COMPLETE (MX)
A-1257-067-A DISPLAY BOARD, COMPLETE (SP, SP6, AR, TH)
************************
< CAPACITOR >
C100 1-127-888-11 CERAMIC 0.1uF 10% 50V
C101 1-127-888-11 CERAMIC 0.1uF 10% 50V
C106 1-127-868-11 CERAMIC 2200PF 10% 50V
C107 1-127-868-11 CERAMIC 2200PF 10% 50V
C110 1-162-286-31 CERAMIC 220PF 10% 50V
C111 1-162-286-31 CERAMIC 220PF 10% 50V
C112 1-162-286-31 CERAMIC 220PF 10% 50V
C144 1-127-888-11 CERAMIC 0.1uF 10% 50V
C145 1-127-888-11 CERAMIC 0.1uF 10% 50V
C146 1-126-964-11 ELECT 10uF 20% 50V
C147 1-162-286-31 CERAMIC 220PF 10% 50V
C148 1-162-286-31 CERAMIC 220PF 10% 50V
C149 1-162-286-31 CERAMIC 220PF 10% 50V
C150 1-127-888-11 CERAMIC 0.1uF 10% 50V
C151 1-127-888-11 CERAMIC 0.1uF 10% 50V
C161 1-126-964-11 ELECT 10uF 20% 50V
(EXCEPT MX)
< CONNECTOR >
CNP102 1-564-505-11 PLUG, CONNECTOR 2P
CNS102 1-784-778-11 CONNECTOR, FFC 17P
< FLUORESCENT INDICATOR TUBE >
FL101 1-519-927-11 VACUUM FLOURESCENT DISPLAY
< IC >
IC100 8-759-643-83 IC uPD16315GB-3BS
IC101 8-759-243-51 IC TC74ACT08P
IC102 6-600-174-01 IC RPM7240-H4
< RESISTOR >
R103 1-249-409-11 CARBON 220 5% 1/4W
R115 1-247-807-31 CARBON 100 5% 1/4W
R116 1-247-807-31 CARBON 100 5% 1/4W
R117 1-247-807-31 CARBON 100 5% 1/4W
R118 1-249-440-11 CARBON 82K 5% 1/4W
R119 1-247-807-31 CARBON 100 5% 1/4W
0 R121 1-249-393-11 CARBON 10 5% 1/4W F
0 R198 1-249-387-81 CARBON 3.3 5% 1/4W F
(E51, MX)
0 R198 1-249-390-11 CARBON 5.6 5% 1/4W F
(SP, SP6, AR, TH)
0 R199 1-249-387-81 CARBON 3.3 5% 1/4W F
(E51, MX)
0 R199 1-249-390-11 CARBON 5.6 5% 1/4W F
(SP, SP6, AR, TH)
< VARIABLE RESISTOR >
RV101 1-418-817-21 ENCODER, ROTARY
RV102 1-418-725-41 ENCODER, ROTARY (12 TYPE)
< SWITCH >
S103 1-771-410-21 SWITCH, TACTILE (AUTO CAL)
S104 1-771-410-21 SWITCH, TACTILE (DISPLAY)
*************************************************************
HEADPHONE BOARD
*****************
< CONNECTOR >
* CNP790 1-564-507-11 PLUG, CONNECTOR 4P
< JACK >
J790 1-815-314-21 JACK (PHONES)
*************************************************************
A-1221-893-A MAIN BOARD, COMPLETE (SP, SP6, TH)
A-1221-900-A MAIN BOARD, COMPLETE (E51)
A-1221-912-A MAIN BOARD, COMPLETE (AR)
A-1249-599-A MAIN BOARD, COMPLETE (MX)
********************
7-685-646-79 SCREW +BVTP 3X8 TYPE2 IT-3
< CAPACITOR >
C402 1-126-964-11 ELECT 10uF 20% 50V
C403 1-162-294-31 CERAMIC 0.001uF 10% 50V
C404 1-162-294-31 CERAMIC 0.001uF 10% 50V
C421 1-126-963-11 ELECT 4.7uF 20% 50V
C422 1-126-963-11 ELECT 4.7uF 20% 50V
C423 1-126-963-11 ELECT 4.7uF 20% 50V
C424 1-126-963-11 ELECT 4.7uF 20% 50V
C425 1-126-963-11 ELECT 4.7uF 20% 50V
C426 1-126-963-11 ELECT 4.7uF 20% 50V
C431 1-126-964-11 ELECT 10uF 20% 50V
DIGITAL
HEADPHONE MAIN
Ver. 1.2
