STR-KS370
SECTION 7
ELECTRICAL PARTS LIST
A-1746-174-A DISPLAY BOARD, COMPLETE
***********************
4-161-929-01 HOLDER, FL
< CAPACITOR >
C700 1-104-957-11 ELECT 47uF 20% 25V
C701 1-163-037-11 CERAMIC CHIP 0.022uF 10% 50V
C702 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C703 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C704 1-126-793-11 ELECT 33uF 20% 35V
C705 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C706 1-126-793-11 ELECT 33uF 20% 35V
C707 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C708 1-126-795-11 ELECT 10uF 20% 50V
C709 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C713 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C715 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C716 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C717 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C718 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C719 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C720 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C721 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C722 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C723 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C724 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C728 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C729 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
< CONNECTOR >
CNS701 1-779-281-11 CONNECTOR, FFC (LIF (NON-ZIF)) 13P
< DIODE >
D726 6-500-848-01 DIODE MC2840-T112-1
D727 6-500-848-01 DIODE MC2840-T112-1
D728 6-501-736-01 DIODE MAZ8062G0LS0
D729 8-719-057-29 DIODE SML78423C-TP15
< FLUORESCENT INDICATOR TUBE >
FL700 1-483-111-11 INDICATOR TUBE, FLUORESCENT
< IC >
IC700 6-713-497-01 IC HT16515
< COIL >
L700 1-400-305-11 INDUCTOR 47uH
L702 1-410-671-31 INDUCTOR 47uH
< TRANSISTOR >
Q700 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q701 6-550-065-01 TRANSISTOR CPH5504-TL-E
Q702 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
< RESISTOR >
R700 1-216-805-11 METAL CHIP 47 5% 1/10W
R701 1-216-828-11 METAL CHIP 3.9K 5% 1/10W
R702 1-216-805-11 METAL CHIP 47 5% 1/10W
R703 1-216-839-11 METAL CHIP 33K 5% 1/10W
R705 1-216-845-11 METAL CHIP 100K 5% 1/10W
R706 1-216-809-11 METAL CHIP 100 5% 1/10W
R707 1-216-809-11 METAL CHIP 100 5% 1/10W
R708 1-216-809-11 METAL CHIP 100 5% 1/10W
R711 1-216-809-11 METAL CHIP 100 5% 1/10W
R712 1-216-809-11 METAL CHIP 100 5% 1/10W
R713 1-216-809-11 METAL CHIP 100 5% 1/10W
R714 1-216-809-11 METAL CHIP 100 5% 1/10W
< TRANSFORMER >
0 T700 1-443-645-11 TRANSFORMER, DC CONVERTER
************************************************************
A-1745-656-A HDMI PC BOARD, COMPLETE (for service)
******************************
< CAPACITOR >
C3000 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3001 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3003 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3004 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3005 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C3006 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
DISPLAY
When indicating parts by reference num-
ber, please include the board name.
Note:
• Due to standardization, replacements in
the parts list may be different from the
parts specifi ed in the diagrams or the com-
ponents used on the set.
• -XX and -X mean standardized parts, so
they may have some difference from the
original one.
• Items marked “*” are not stocked since
they are seldom required for routine ser-
vice. Some delay should be anticipated
when ordering these items.
• RESISTORS
All resistors are in ohms.
METAL: Metal-fi lm resistor.
METAL OXIDE: Metal oxide-fi lm resistor.
F: nonfl ammable
• CAPACITORS
uF: μF
• COILS
uH: μH
• SEMICONDUCTORS
In each case, u: μ, for example:
uA. . : μA. . , uPA. . , μPA. . ,
uPB. . : μPB. . , uPC. . , μPC. . ,
uPD. . : μPD. .
The components identifi ed by mark 0
or dotted line with mark 0 are critical for
safety.
Replace only with part number specifi ed.
The components identifi ed by mark 9 con-
tain confi dential information.
Strictly follow the instructions whenever the
components are repaired and/or replaced.
HDMI PC
To Next Page
