Preparations
Preparing the receiver
Outline dimensional drawing
Top
Front Side
174 mm (6 7/8 in)
430 mm (17 in) 378 mm (15 in)
410 mm (16 1/4 in)
10 mm (13/32 in)
Attaching/removing the front cover
The front cover can be completely removed from the receiver.
Remove the front cover by inserting
your fingers under the cover.
To Next Page
