Sony TA-FA3ES - Page 20

TA-FA3ES
Ref. No. Part No. Description Remark
* 1-657-270-11 VOL 16 BOARD
Jepopeonobns
< CAPACITOR >
€305 1-128-551-11 ELECT 22uF 20% = 35V
€405 = 1-128-551-11 ELECT 22uF 20% = 35V
< CONNECTOR >
CNP401 1-568-317-11 SOCKET, CONNECTOR 6P
CNP402 1-568-317-11 SOCKET, CONNECTOR 6P
< VARIABLE RESISTOR >
RV304 1-223-937-11 RES, VAR, CARBON 120K/120K (ATTENUATOR)
2 IO OIG I IO IO II IOI III AO IO III OR IORI IO AO OK
MISCELLANEOUS
FOR OR ob Rok ok
119 1-506-113-00 SHORT PLUG
A\CNP10 = 1-574-805-31 CORD, POWER
ATi 1-429-093-11 TRANSFORMER, POWER
BEA OR CIO IORI IO OR II IO IR AOR TOR IORI IORI IORI IORI AOR AOK
ACCESSORIES & PACKING MATERIALS
SIO Io doo ito tek ak tok tokk totok
1-693-108-11 REMOTE COMMANDER (RM-S702)
2-181-754-01 COVER, BATTERY (FOR RM-S702)
3-798-956-11 MANUAL, INSTRUCTION
(ENGLISH, FRENCH, SPANISH, PORTUGUESE) (AEP)
3-798-956-21 MANUAL, INSTRUCTION
(GERMAN, DUTCH, SWEDISH, ITALIAN)
* 3-919-601-01 CUSHION
* 3-919-604-41 INDIVIDUAL CARTON
The components identified by
mark A\ or dotted line with mark
A\ are critical for safety.
Replace only with part number
specified.
