Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
27
TA-S9D
< CONNECTOR >
CN1002 1-778-982-11 CONNECTOR, BOARD TO BOARD 13P
CN1003 1-770-725-11 CONNECTOR, BOARD TO BOARD 4P
< DIODE >
D1001 8-719-911-19 DIODE 1SS133T-72
D1002 8-719-911-19 DIODE 1SS133T-72
D1051 8-719-911-19 DIODE 1SS133T-72
D1061 8-719-911-19 DIODE 1SS133T-72
D1062 8-719-911-19 DIODE 1SS133T-72
D1081 8-719-911-19 DIODE 1SS133T-72
< IC >
IC1001 8-749-017-19 IC STK443-050
< TRANSISTOR >
Q1001 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
Q1051 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
Q1061 8-729-119-76 TRANSISTOR 2SA1175TP-HFE
Q1063 8-729-900-36 TRANSISTOR BA1F4M-TP
Q1081 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
Q1092 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
Q1093 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
< RESISTOR >
R1001 1-249-417-11 CARBON 1K 5% 1/4W
R1002 1-249-438-11 CARBON 56K 5% 1/4W
R1003 1-249-415-11 CARBON 680 5% 1/4W
(EXCEPT TH)
R1003 1-249-417-11 CARBON 1K 5% 1/4W
(TH)
R1004 1-249-438-11 CARBON 56K 5% 1/4W
0 R1005 1-233-352-41 ENCAPSULATED COMPONENT 0.22 2W
R1006 1-249-417-11 CARBON 1K 5% 1/4W
R1007 1-249-431-11 CARBON 15K 5% 1/4W
R1008 1-249-441-11 CARBON 100K 5% 1/4W
R1009 1-260-076-11 CARBON 10 5% 1/2W
R1010 1-249-437-11 CARBON 47K 5% 1/4W
0 R1031 1-212-881-11 FUSIBLE 100 5% 1/4W F
0 R1032 1-212-881-11 FUSIBLE 100 5% 1/4W F
0 R1033 1-202-972-61 FUSIBLE 1 5% 1/4W F
R1047 1-249-429-11 CARBON 10K 5% 1/4W
R1051 1-249-417-11 CARBON 1K 5% 1/4W
R1052 1-249-438-11 CARBON 56K 5% 1/4W
R1053 1-249-415-11 CARBON 680 5% 1/4W
(EXCEPT TH)
R1053 1-249-417-11 CARBON 1K 5% 1/4W
(TH)
R1054 1-249-438-11 CARBON 56K 5% 1/4W
0 R1055 1-233-352-41 ENCAPSULATED COMPONENT 0.22 2W
R1056 1-249-417-11 CARBON 1K 5% 1/4W
R1057 1-249-431-11 CARBON 15K 5% 1/4W
R1058 1-249-441-11 CARBON 100K 5% 1/4W
R1059 1-260-076-11 CARBON 10 5% 1/2W
R1060 1-249-438-11 CARBON 56K 5% 1/4W
0 R1061 1-215-888-00 METAL OXIDE 220 5% 2W F
0 R1062 1-215-888-00 METAL OXIDE 220 5% 2W F
R1063 1-249-429-11 CARBON 10K 5% 1/4W
R1065 1-249-433-11 CARBON 22K 5% 1/4W
R1081 1-249-417-11 CARBON 1K 5% 1/4W
R1082 1-249-438-11 CARBON 56K 5% 1/4W
R1083 1-247-834-11 CARBON 1.3K 5% 1/4W
R1084 1-249-438-11 CARBON 56K 5% 1/4W
0 R1085 1-233-352-41 ENCAPSULATED COMPONENT 0.22 2W
R1086 1-249-417-11 CARBON 1K 5% 1/4W
R1087 1-249-431-11 CARBON 15K 5% 1/4W
R1088 1-249-441-11 CARBON 100K 5% 1/4W
R1089 1-260-076-11 CARBON 10 5% 1/2W
R1090 1-249-439-11 CARBON 68K 5% 1/4W
R1092 1-249-441-11 CARBON 100K 5% 1/4W
R1093 1-249-441-11 CARBON 100K 5% 1/4W
R1094 1-249-439-11 CARBON 68K 5% 1/4W
R1095 1-249-433-11 CARBON 22K 5% 1/4W
< RELAY >
RY1061 1-515-920-11 RELAY (24V)
RY1062 1-515-920-11 RELAY (24V)
< THERMISTOR (POSITIVE) >
THP092 1-807-796-11 THERMISTOR
**************************************************************
MISCELLANEOUS
**************
1 1-773-178-11 WIRE (FLAT TYPE) (23 CORE) (AEP, UK)
1 1-773-210-11 WIRE (FLAT TYPE) (25 CORE)
(EXCEPT AEP, UK)
0 6 1-526-794-11 OUTLET, AC (AEP, UK, EA, SP, AUS)
0 6 1-526-882-00 OUTLET, AC (E, TH, MX)
0 6 1-815-114-11 OUTLET, AC (KR)
0 109 1-769-079-21 CORD, POWER (KR)
0 109 1-777-071-81 CORD, POWER (AEP, E, EA, SP)
0 109 1-783-203-11 CORD, POWER (AUS)
0 109 1-790-226-11 CORD, POWER (UK)
0 109 1-791-901-11 CORD, POWER (TH, MX)
110 1-500-386-11 FILTER, CLAMP (FERRITE CORE)
M1 1-763-072-11 FAN, D. C.
0 T911 1-435-934-11 TRANSFORMER, POWER (AEP, UK)
0 T911 1-435-935-11 TRANSFORMER, POWER (EXCEPT AEP, UK)
************************************************************
**************
HARDWARE LIST
**************
#1 7-685-646-79 SCREW +BVTP 3X8 TYPE2 N-S
#2 7-685-650-79 SCREW +BVTP 3X16 TYPE2 IT-3
#3 7-685-872-09 SCREW +BVTT 3X8 (S)
#4 7-685-871-01 SCREW +BVTT 3X6 (S)
************************************************************
ACCESSORIES
************
0 1-569-008-21 ADAPTOR, CONVERSION (E, EA, SP)
The components identified by mark 0 or dotted
line with mark 0 are critical for safety.
Replace only with part number specified.
SURROUND AMP
