Sony TC-S3 Service Manual

TC-S3
6
• This set can be disassembled in the order shown below.
3-1. DISASSEMBLY FLOW
SECTION 3
DISASSEMBLY
Note: Follow the disassembly procedure in the numerical order given.
3-2. COVER
3-2. COVER
(Page 6)
3-3. MAIN BOARD
(Page 7)
3-4. FRONT PANEL SECTION
(Page 7)
3-6. LEAF SW BOARD, HEAD (A) BOARD, HEAD (B) BOARD
(Page 8)
3-5. TAPE MECHANISM DECK
(TCM-230AWR41/230MWR41)
(Page 8)
SET
2 two screws
(case 3 TP2)
3
3
2 two screws
(case 3 TP2)
1 three screws
(BVTP3
× 8)
4 Remove the cover in the
direction of arrow
A .
A
