TC-S3
7
3-3. MAIN BOARD
3-4. FRONT PANEL SECTION
2
connector
(CN1)
5
MAIN board
1
wire (flat type) (17 core)
(CN311)
2
three connectors
(CN309, 310, 314)
3
three screws
(BVTP3
×
8)
3
screw
(BVTP3
×
8)
4
PC board holder
2
connector
(CN2)
7
front panel section
2
connector
(CN1)
3
screw
(BVTP3
×
8)
2
connector
(CN314)
1
wire (flat type) (17 core)
(CN311)
4
lug
6
two claws
2
connector
(CN2)
6
three claws
5
three screws
(BVTP3
×
8)
