– 10 –
PINCH LEVER (N)/(R) ASSY
MAGNETIC HEAD (H901)
1 claw
2 Remove the pinch lever (R) assy
in the dereciton of the arrow.
4 Remove the pinch lever (N) ass
in the direction of the arrow.
3 claw
1 two screws
(M1.4 x 7.2)
2 Remove the magnetic head (H901
in the direction of the arrow.
