– 9 –
HOLDER (F) ASSY
BELT, MOTOR (M601)
8 head flexible board
(CN301)
9 Remove the holder (F) assy
in the direction of the arrow.
1 two screws
(M1.4 × 1.4)
3 lever (B), lock
2 shaft
7 bracket (cassette) assy
5 lever (S), lock
4 screw (M1.4
6 shaft
1 belt (F2)
3 motor, DC
(M601)
2 screw
(M1.5
2 screw
(M1.5)
• See page 4 for Rotation system.
