Sony TRINITRON BVM-D9H5U - Page 100

9-10
BVM-D9H1U/D9H5U/D9H1E/D9H5E/D9H1A/D9H5A
Ref.No. Part No. Description RemarkRef.No. Part No. Description Remark
R3938 1-216-073-00 RES,CHIP 10K 5% 1/10W
R3939 1-216-097-91 RES,CHIP 100K 5% 1/10W
R3940 1-216-073-00 RES,CHIP 10K 5% 1/10W
R3941 1-216-049-91 RES,CHIP 1K 5% 1/10W
R3942 1-216-081-00 RES,CHIP 22K 5% 1/10W
R3943 1-216-055-00 RES,CHIP 1.8K 5% 1/10W
R3944 1-216-049-91 RES,CHIP 1K 5% 1/10W
R3945 1-216-079-00 RES,CHIP 18K 5% 1/10W
R3946 1-216-059-00 RES,CHIP 2.7K 5% 1/10W
R3947 1-216-089-91 RES,CHIP 47K 5% 1/10W
R3948 1-216-295-91 SHORT 0
****************************************************************
* A-1136-013-A BX COMPL
***********
<CAPACITOR>
C010 1-128-526-11 ELECT 100µF 20% 16V
C011 1-163-038-91 CERAMIC CHIP0.1µF 25V
C012 1-128-526-11 ELECT 100µF 20% 16V
C013 1-163-038-91 CERAMIC CHIP0.1µF 25V
C014 1-128-526-11 ELECT 100µF 20% 16V
C015 1-163-038-91 CERAMIC CHIP0.1µF 25V
C016 1-163-038-91 CERAMIC CHIP0.1µF 25V
C017 1-163-038-91 CERAMIC CHIP0.1µF 25V
C018 1-163-038-91 CERAMIC CHIP0.1µF 25V
C019 1-163-038-91 CERAMIC CHIP0.1µF 25V
C020 1-163-038-91 CERAMIC CHIP0.1µF 25V
C021 1-163-038-91 CERAMIC CHIP0.1µF 25V
C022 1-163-038-91 CERAMIC CHIP0.1µF 25V
C050 1-128-526-11 ELECT 100µF 20% 16V
C051 1-163-038-91 CERAMIC CHIP0.1µF 25V
C052 1-128-526-11 ELECT 100µF 20% 16V
C053 1-163-038-91 CERAMIC CHIP0.1µF 25V
C054 1-128-526-11 ELECT 100µF 20% 16V
C055 1-163-038-91 CERAMIC CHIP0.1µF 25V
C056 1-163-038-91 CERAMIC CHIP0.1µF 25V
C057 1-163-038-91 CERAMIC CHIP0.1µF 25V
C058 1-163-038-91 CERAMIC CHIP0.1µF 25V
C059 1-163-038-91 CERAMIC CHIP0.1µF 25V
C060 1-163-038-91 CERAMIC CHIP0.1µF 25V
C061 1-163-038-91 CERAMIC CHIP0.1µF 25V
C062 1-163-038-91 CERAMIC CHIP0.1µF 25V
C101 1-163-227-11 CERAMIC CHIP10PF 0.5PF 50V
C102 1-163-235-11 CERAMIC CHIP22PF 5% 50V
C103 1-107-701-11 ELECT 47µF 20% 16V
C104 1-107-725-11 CERAMIC CHIP0.1µF 10% 16V
C106 1-163-021-91 CERAMIC CHIP0.01µF 10% 50V
C201 1-163-227-11 CERAMIC CHIP10PF 0.5PF 50V
C202 1-163-235-11 CERAMIC CHIP22PF 5% 50V
C203 1-107-701-11 ELECT 47µF 20% 16V
C204 1-107-725-11 CERAMIC CHIP0.1µF 10% 16V
C206 1-163-021-91 CERAMIC CHIP0.01µF 10% 50V
C301 1-163-227-11 CERAMIC CHIP10PF 0.5PF 50V
C302 1-163-235-11 CERAMIC CHIP22PF 5% 50V
C303 1-107-701-11 ELECT 47µF 20% 16V
C304 1-107-725-11 CERAMIC CHIP0.1µF 10% 16V
C306 1-163-021-91 CERAMIC CHIP0.01µF 10% 50V
C401 1-163-091-00 CERAMIC CHIP8PF 0.25PF 50V
C402 1-163-235-11 CERAMIC CHIP22PF 5% 50V
C403 1-107-701-11 ELECT 47µF 20% 16V
C404 1-107-725-11 CERAMIC CHIP0.1µF 10% 16V
C501 1-128-526-11 ELECT 100µF 20% 16V
C502 1-163-038-91 CERAMIC CHIP0.1µF 25V
C503 1-163-038-91 CERAMIC CHIP0.1µF 25V
<CONNECTOR>
CN001 * 1-774-523-11 PIN, CONNECTOR (PC BOARD) 64P
<DIODE>
D101 8-719-073-01 DIODE MA111-(K8).S0
D102 8-719-073-01 DIODE MA111-(K8).S0
D201 8-719-073-01 DIODE MA111-(K8).S0
D202 8-719-073-01 DIODE MA111-(K8).S0
D301 8-719-073-01 DIODE MA111-(K8).S0
D302 8-719-073-01 DIODE MA111-(K8).S0
D401 8-719-073-01 DIODE MA111-(K8).S0
D402 8-719-073-01 DIODE MA111-(K8).S0
D501 8-719-158-19 DIODE RD6.2SB
<FILTER>
FL501 1-239-183-11 FILTER, EMI
FL502 1-239-480-11 FILTER, EMI
FL503 1-239-480-11 FILTER, EMI
<IC>
IC010 8-759-460-74 IC BA05FP-E2
IC050 8-759-539-89 IC LM2990SX-5.0
IC501 8-759-594-41 IC MB89613R-651
IC502 8-759-186-44 IC TC74VHC125F
IC503 8-759-156-54 IC X25040SI
<TRANSISTOR>
Q101 8-729-112-65 TRANSISTOR 2SA1462-Y33
Q102 8-729-027-38 TRANSISTOR DTA144EKA-T146
Q103 8-729-107-31 TRANSISTOR 2SC3545-T43
Q201 8-729-112-65 TRANSISTOR 2SA1462-Y33
Q202 8-729-027-38 TRANSISTOR DTA144EKA-T146
Q203 8-729-107-31 TRANSISTOR 2SC3545-T43
Q301 8-729-112-65 TRANSISTOR 2SA1462-Y33
Q302 8-729-027-38 TRANSISTOR DTA144EKA-T146
Q303 8-729-107-31 TRANSISTOR 2SC3545-T43
Q401 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q402 1-801-806-11 TRANSISTOR DTC144EKA-T146
Q403 8-729-026-49 TRANSISTOR 2SA1037AK-T146-R
Q404 8-729-027-38 TRANSISTOR DTA144EKA-T146
Q501 1-801-806-11 TRANSISTOR DTC144EKA-T146
<RESISTOR>
R101 1-214-837-11 METAL 75 1% 1/2W
R102 1-216-089-91 RES,CHIP 47K 5% 1/10W
R103 1-216-025-91 RES,CHIP 100 5% 1/10W
R104 1-216-057-00 RES,CHIP 2.2K 5% 1/10W
R105 1-216-097-91 RES,CHIP 100K 5% 1/10W
R106 1-216-009-91 RES,CHIP 22 5% 1/10W
R107 1-216-025-91 RES,CHIP 100 5% 1/10W
R108 1-216-097-91 RES,CHIP 100K 5% 1/10W
R109 1-216-013-00 RES,CHIP 33 5% 1/10W
R201 1-214-837-11 METAL 75 1% 1/2W
R202 1-216-089-91 RES,CHIP 47K 5% 1/10W
R203 1-216-025-91 RES,CHIP 100 5% 1/10W
R204 1-216-057-00 RES,CHIP 2.2K 5% 1/10W
R205 1-216-097-91 RES,CHIP 100K 5% 1/10W
R206 1-216-009-91 RES,CHIP 22 5% 1/10W
BXB2
