9-11
BVM-D9H1U/D9H5U/D9H1E/D9H5E/D9H1A/D9H5A
Ref.No. Part No. Description RemarkRef.No. Part No. Description Remark
R207 1-216-025-91 RES,CHIP 100 5% 1/10W
R208 1-216-097-91 RES,CHIP 100K 5% 1/10W
R209 1-216-013-00 RES,CHIP 33 5% 1/10W
R301 1-214-837-11 METAL 75 1% 1/2W
R302 1-216-089-91 RES,CHIP 47K 5% 1/10W
R303 1-216-025-91 RES,CHIP 100 5% 1/10W
R304 1-216-057-00 RES,CHIP 2.2K 5% 1/10W
R305 1-216-097-91 RES,CHIP 100K 5% 1/10W
R306 1-216-009-91 RES,CHIP 22 5% 1/10W
R307 1-216-025-91 RES,CHIP 100 5% 1/10W
R308 1-216-097-91 RES,CHIP 100K 5% 1/10W
R309 1-216-013-00 RES,CHIP 33 5% 1/10W
R401 1-214-837-11 METAL 75 1% 1/2W
R402 1-216-089-91 RES,CHIP 47K 5% 1/10W
R403 1-216-049-91 RES,CHIP 1K 5% 1/10W
R404 1-216-097-91 RES,CHIP 100K 5% 1/10W
R405 1-216-057-00 RES,CHIP 2.2K 5% 1/10W
R406 1-216-009-91 RES,CHIP 22 5% 1/10W
R407 1-216-025-91 RES,CHIP 100 5% 1/10W
R408 1-216-097-91 RES,CHIP 100K 5% 1/10W
R409 1-216-013-00 RES,CHIP 33 5% 1/10W
R410 1-216-097-91 RES,CHIP 100K 5% 1/10W
R501 1-216-097-91 RES,CHIP 100K 5% 1/10W
R502 1-216-025-91 RES,CHIP 100 5% 1/10W
R503 1-216-025-91 RES,CHIP 100 5% 1/10W
R504 1-216-097-91 RES,CHIP 100K 5% 1/10W
R505 1-216-025-91 RES,CHIP 100 5% 1/10W
R506 1-216-097-91 RES,CHIP 100K 5% 1/10W
R507 1-216-025-91 RES,CHIP 100 5% 1/10W
R508 1-216-097-91 RES,CHIP 100K 5% 1/10W
R509 1-216-097-91 RES,CHIP 100K 5% 1/10W
R510 1-216-097-91 RES,CHIP 100K 5% 1/10W
R511 1-216-097-91 RES,CHIP 100K 5% 1/10W
R512 1-216-097-91 RES,CHIP 100K 5% 1/10W
R513 1-216-097-91 RES,CHIP 100K 5% 1/10W
R514 1-216-097-91 RES,CHIP 100K 5% 1/10W
R515 1-216-097-91 RES,CHIP 100K 5% 1/10W
R516 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R517 1-216-097-91 RES,CHIP 100K 5% 1/10W
R518 1-216-097-91 RES,CHIP 100K 5% 1/10W
<TERMINAL BOARD>
TB001 1-694-601-11 TERMINAL BOARD ASSY, I/O
<TEST PIN>
TP001 * 1-537-864-11 PIN, POST
TP010 * 1-537-864-11 PIN, POST
<CRYSTAL>
X501 1-578-689-21 VIBRATOR (8 MHz)
****************************************************************
* A-1331-957-A C MOUNT
**********
* 4-376-132-11 COVER(REAR LID), CV VOL
* 4-376-133-11 COVER(MAIN), CV VOL
<CAPACITOR>
C701 1-162-114-00 CERAMIC 0.0047µF 2KV
C702 1-104-665-11 ELECT 100µF 20% 25V
C703 1-162-114-00 CERAMIC 0.0047µF 2KV
C710 1-161-830-00 CERAMIC 0.0047µF 500V
<CONNECTOR>
CN701 * 1-564-509-11 PLUG, CONNECTOR 6P
CN702 * 1-508-784-00 PIN, CONNECTOR (5MM PITCH) 1P
CN703 * 1-564-509-11 PLUG, CONNECTOR 6P
<COMPOSITION CIRCUIT BLOCK>
CP701 1-453-105-11 CR PACK, HIGH-VOLTAGE
<DIODE>
D701 8-719-911-19 DIODE 1SS119-25
<JACK>
J701 1-251-244-11 SOCKET, CRT
<COIL>
L701 1-408-608-31 INDUCTOR 27µH
L702 1-408-601-31 INDUCTOR 6.8µH
L703 1-408-601-31 INDUCTOR 6.8µH
L704 1-408-601-31 INDUCTOR 6.8µH
<TRANSISTOR>
Q701 8-729-020-07 TRANSISTOR 2SC4686A(LBSONY)
<RESISTOR>
R701 1-219-747-91 CARBON 2.2K 5% 1/2W
R702 1-219-747-91 CARBON 2.2K 5% 1/2W
R703 1-219-747-91 CARBON 2.2K 5% 1/2W
R704 1-219-752-11 CARBON 100K 5% 1/2W
R706 1-219-753-11 CARBON 220K 5% 1/2W
R707 1-219-752-11 CARBON 100K 5% 1/2W
R708 1-249-429-11 CARBON 10K 5% 1/4W
R709 1-249-417-11 CARBON 1K 5% 1/4W
<VARIABLE RESISTOR>
RV701 !1-230-164-00 RES, ADJ, METAL GLAZE 55M
****************************************************************
* A-1335-118-A D COMPL
**********
4-048-257-01 HOLDER (C), TR
4-381-907-01 INSULATOR (A)
4-382-854-11 SCREW(M3X10), P, SW (+)
<CAPACITOR>
C1600 1-107-914-11 ELECT 1000µF 20% 25V
C1601 1-128-526-11 ELECT 100µF 20% 25V
C1602 1-163-031-11 CERAMIC CHIP0.01µF 50V
C1603 1-126-096-11 ELECT 10µF 20% 35V
C1604 1-124-589-11 ELECT 47µF 20% 16V
DBX C
