Sony TRINITRON BVM-D9H5U - Page 106

9-16
BVM-D9H1U/D9H5U/D9H1E/D9H5E/D9H1A/D9H5A
Ref.No. Part No. Description RemarkRef.No. Part No. Description Remark
R2620 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R2625 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R2626 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R2627 1-216-009-91 RES,CHIP 22 5% 1/10W
R2628 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R2629 1-249-377-11 CARBON 0.47 5% 1/4W F
R2630 1-249-377-11 CARBON 0.47 5% 1/4W F
R3500 1-216-675-91 METAL CHIP 10K 0.50% 1/10W
R3501 1-216-053-00 RES,CHIP 1.5K 5% 1/10W
R3502 1-216-673-11 METAL CHIP 8.2K 0.50% 1/10W
R3503 1-216-695-11 METAL CHIP 68K 0.50% 1/10W
R3504 1-218-754-11 METAL CHIP 120K 0.50% 1/10W
R3505 1-249-431-11 CARBON 15K 5% 1/4W
R3506 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R3507 1-216-073-00 RES,CHIP 10K 5% 1/10W
R3508 1-216-073-00 RES,CHIP 10K 5% 1/10W
R3509 1-216-049-91 RES,CHIP 1K 5% 1/10W
R3510 1-216-025-91 RES,CHIP 100 5% 1/10W
R3511 1-216-025-91 RES,CHIP 100 5% 1/10W
R3512 1-216-685-11 METAL CHIP 27K 0.50% 1/10W
R3513 1-216-049-91 RES,CHIP 1K 5% 1/10W
R3514 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R3515 1-216-025-91 RES,CHIP 100 5% 1/10W
R3516 1-216-073-00 RES,CHIP 10K 5% 1/10W
R3517 1-216-073-00 RES,CHIP 10K 5% 1/10W
R3518 1-216-073-00 RES,CHIP 10K 5% 1/10W
R3519 1-216-059-00 RES,CHIP 2.7K 5% 1/10W
R3520 1-216-073-00 RES,CHIP 10K 5% 1/10W
R3521 1-216-113-00 RES,CHIP 470K 5% 1/10W
R3522 1-216-073-00 RES,CHIP 10K 5% 1/10W
R3525 1-216-025-91 RES,CHIP 100 5% 1/10W
R3526 1-216-025-91 RES,CHIP 100 5% 1/10W
R3527 1-216-113-00 RES,CHIP 470K 5% 1/10W
R3528 1-216-049-91 RES,CHIP 1K 5% 1/10W
R3529 1-216-697-91 METAL CHIP 82K 0.50% 1/10W
R3530 1-216-679-11 METAL CHIP 15K 0.50% 1/10W
R3531 1-216-049-91 RES,CHIP 1K 5% 1/10W
R3532 1-216-089-91 RES,CHIP 47K 5% 1/10W
R3533 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R3534 1-216-049-91 RES,CHIP 1K 5% 1/10W
R3535 1-216-057-00 RES,CHIP 2.2K 5% 1/10W
R3545 1-216-057-00 RES,CHIP 2.2K 5% 1/10W
R3546 1-216-081-00 RES,CHIP 22K 5% 1/10W
R3547 1-216-091-00 RES,CHIP 56K 5% 1/10W
R3548 1-216-049-91 RES,CHIP 1K 5% 1/10W
R3550 1-216-093-91 RES,CHIP 68K 5% 1/10W
R3551 1-216-453-00 METAL OXIDE 270 5% 2W F
R3552 1-216-475-11 METAL OXIDE 120 5% 3W F
R3553 1-216-346-00 METAL OXIDE 0.56 5% 1W F
R3554 1-215-861-00 METAL OXIDE 47 5% 1W F
R3556 1-216-107-00 RES,CHIP 270K 5% 1/10W
R3557 1-216-073-00 RES,CHIP 10K 5% 1/10W
R3558 1-216-061-00 RES,CHIP 3.3K 5% 1/10W
R3560 1-216-073-00 RES,CHIP 10K 5% 1/10W
R3601 1-216-667-11 METAL CHIP 4.7K 0.50% 1/10W
R3602 1-216-667-11 METAL CHIP 4.7K 0.50% 1/10W
R3603 1-216-099-00 RES,CHIP 120K 5% 1/10W
R3604 1-216-073-00 RES,CHIP 10K 5% 1/10W
R3605 1-216-093-91 RES,CHIP 68K 5% 1/10W
R3606 1-216-667-11 METAL CHIP 4.7K 0.50% 1/10W
R3607 1-216-685-11 METAL CHIP 27K 0.50% 1/10W
R3608 1-216-689-11 METAL CHIP 39K 0.50% 1/10W
R3609 1-216-655-11 METAL CHIP 1.5K 0.50% 1/10W
R3610 1-216-667-11 METAL CHIP 4.7K 0.50% 1/10W
R3611 1-216-667-11 METAL CHIP 4.7K 0.50% 1/10W
R3612 1-216-073-00 RES,CHIP 10K 5% 1/10W
R3613 1-216-691-11 METAL CHIP 47K 0.50% 1/10W
R3614 1-216-667-11 METAL CHIP 4.7K 0.50% 1/10W
R3615 1-216-662-11 METAL CHIP 3K 0.50% 1/10W
R3616 1-216-089-91 RES,CHIP 47K 5% 1/10W
R3617 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R3618 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R3619 1-216-009-91 RES,CHIP 22 5% 1/10W
R3620 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R3621 1-216-009-91 RES,CHIP 22 5% 1/10W
R3622 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R3627 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R3628 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R3629 1-216-009-91 RES,CHIP 22 5% 1/10W
R3630 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R3631 1-249-425-11 CARBON 4.7K 5% 1/4W F
R3632 1-249-413-11 CARBON 470 5% 1/4W F
R3633 1-249-413-11 CARBON 470 5% 1/4W F
R3634 1-249-377-11 CARBON 0.47 5% 1/4W F
R3635 1-249-377-11 CARBON 0.47 5% 1/4W F
R3636 1-249-393-11 CARBON 10 5% 1/4W F
R3637 1-249-381-11 CARBON 1 5% 1/4W F
R3638 1-249-381-11 CARBON 1 5% 1/4W F
<RELAY>
RY1601 1-755-018-11 RELAY
RY2501 1-755-198-11 RELAY, AC POWER
<TRANSFORMER>
T2501 1-419-437-11 CHOKE
T2502 1-431-443-11 TRANSFORMER, FERRITE (HST)
T2503 1-433-978-11 TRANSFORMER, HORIZONTAL DRIVE
T2504 1-419-438-11 CHOKE
T3601 1-435-157-11 TRANSFORMER, DC-DC CONVERTER
****************************************************************
* A-1316-460-A G COMPL
**********
4-382-854-01 SCREW(M3X8), P, SW (+)
<CAPACITOR>
C601 ! 1-113-900-11 CERAMIC 470PF 10% 250V
C602 ! 1-104-708-11 MYLAR 0.47µF 20% 250V
C603 ! 1-104-706-11 MYLAR 0.22µF 20% 250V
C604 ! 1-113-926-11 CERAMIC 0.0047µF 250V
C605 ! 1-113-900-11 CERAMIC 470PF 10% 250V
C606 ! 1-113-926-11 CERAMIC 0.0047µF 250V
C611 1-107-907-11 ELECT 22µF 20% 50V
C613 1-107-905-11 ELECT 4.7µF 20% 50V
C614 1-107-910-11 ELECT 100µF 20% 50V
C615 1-131-913-11 ELECT 150µF 20% 450V
C616 1-130-495-00 MYLAR 0.1µF 5% 50V
C618 1-131-876-91 CAPACITOR 000000000 0 0
C620 1-107-910-11 ELECT 100µF 20% 50V
C621 1-107-906-11 ELECT 10µF 20% 50V
C622 1-107-909-11 ELECT 47µF 20% 50V
C623 1-127-825-11 FILM 0.0033µF 3% 1KV
C629 1-163-251-11 CERAMIC CHIP100PF 5% 50V
C630 1-137-479-71 MYLAR 1µF 10% 400V
C631 1-115-340-11 CERAMIC CHIP0.22µF 10% 25V
C632 1-107-910-11 ELECT 100µF 20% 50V
D G
