9-17
BVM-D9H1U/D9H5U/D9H1E/D9H5E/D9H1A/D9H5A
Ref.No. Part No. Description RemarkRef.No. Part No. Description Remark
C637 1-107-910-11 ELECT 100µF 20% 50V
C644 1-127-825-11 FILM 0.0033µF 3% 1KV
C651 1-163-021-91 CERAMIC CHIP0.01µF 10% 50V
C690 1-111-074-11 ELECT 0.0039F 20% 25V
C691 1-111-074-11 ELECT 0.0039F 20% 25V
C693 1-126-942-61 ELECT 1000µF 20% 25V
<CONNECTOR>
CN601 * 1-691-960-11 PIN, CONNECTOR (PC BOARD) 3P
CN690 * 1-580-843-11 PIN, CONNECTOR (POWER)
CN691 1-695-915-11 TAB (CONTACT)
<DIODE>
D601 8-719-510-53 DIODE D4SB60L
D602 8-719-304-63 DIODE RM11C
D604 8-719-989-76 DIODE SC802-04
D605 8-719-989-21 DIODE SC311-6-TE12RA
D606 8-719-989-21 DIODE SC311-6-TE12RA
D607 8-719-989-21 DIODE SC311-6-TE12RA
D620 8-719-063-73 DIODE D1NL20U-TR
D661 8-719-158-53 DIODE RD13SB2
D662 8-719-063-73 DIODE D1NL20U-TR
D663 8-719-063-73 DIODE D1NL20U-TR
D668 8-719-063-73 DIODE D1NL20U-TR
D669 8-719-110-67 DIODE RD27ESB2
D690 8-719-988-30 DIODE D30SC4M
<FUSE>
F601 ! 1-576-231-11 FUSE (H.B.C.) 4A/250V
<FUSE HOLDER>
FH1 1-533-223-11 CLIP, FUSE
FH2 1-533-223-11 CLIP, FUSE
<IC>
IC603 8-749-013-78 IC MCR5102
IC666 8-749-015-89 IC MZ1530
IC690 8-749-920-44 IC SE-012N
<COIL>
L601 1-406-977-21 INDUCTOR 100µH
L690 1-469-563-11 INDUCTOR 5.6µH
<PHOTO COUPLER>
PH601 8-749-010-64 PHOTO COUPLER PC123F2
<RESISTOR>
R601 ! 1-220-825-11 CARBON 330K 5% 1/2W
R604 1-215-424-00 METAL 1.3K 1% 1/4W
R605 1-202-933-61 FUSIBLE 0.1 10% 1/2W
R608 1-216-346-00 METAL OXIDE 0.56 5% 1W F
R610 1-216-675-91 METAL CHIP 10K 0.50% 1/10W
R615 1-249-413-11 CARBON 470 5% 1/4W
R621 ! 1-202-727-00 SOLID 4.7M 20% 1/2W
R622 ! 1-202-727-00 SOLID 4.7M 20% 1/2W
R644 1-215-485-00 METAL 470K 1% 1/4W
R645 1-215-481-91 METAL 330K 1% 1/4W
R653 1-215-485-00 METAL 470K 1% 1/4W
R657 1-216-677-11 METAL CHIP 12K 0.50% 1/10W
R658 1-216-651-11 METAL CHIP 1K 0.50% 1/10W
R668 ! 1-242-803-11 CEMENTED 1.5 5% 7W
R669 ! 1-242-803-11 CEMENTED 1.5 5% 7W
R670 1-217-192-21 METAL 0.22 10% 2W
R671 1-217-192-21 METAL 0.22 10% 2W
R672 1-215-926-00 METAL OXIDE 33K 5% 3W F
R673 1-215-926-00 METAL OXIDE 33K 5% 3W F
R674 1-249-377-11 CARBON 0.47 5% 1/4W F
R675 1-216-073-00 RES,CHIP 10K 5% 1/10W
R677 1-216-346-00 METAL OXIDE 0.56 5% 1W F
R678 1-260-135-11 CARBON 1M 5% 1/2W
R679 1-260-135-11 CARBON 1M 5% 1/2W
R680 1-260-135-11 CARBON 1M 5% 1/2W
R681 1-260-135-11 CARBON 1M 5% 1/2W
R688 1-215-926-00 METAL OXIDE 33K 5% 3W F
R690 1-249-410-11 CARBON 270 5% 1/4W F
R691 1-216-057-00 RES,CHIP 2.2K 5% 1/10W
R692 1-216-049-91 RES,CHIP 1K 5% 1/10W
R693 1-249-401-11 CARBON 47 5% 1/4W F
<TRANSFORMER>
T601 ! 1-435-155-11 TRANSFORMER, LINE FILTER
T602 1-435-154-11 TRANSFORMER, FERRITE (PFT)
T604 1-435-153-11 TRANSFORMER, CONVERTER (PIT)
<VARISTOR>
VDR602! 1-801-073-31 VARISTOR TNR14V471K660
****************************************************************
* A-1372-675-A HA MOUNT (D9H5 )
*******************
<CAPACITOR>
C220 1-163-031-11 CERAMIC CHIP0.01µF 50V
C221 1-163-031-11 CERAMIC CHIP0.01µF 50V
C222 1-163-031-11 CERAMIC CHIP0.01µF 50V
C223 1-163-031-11 CERAMIC CHIP0.01µF 50V
C224 1-163-031-11 CERAMIC CHIP0.01µF 50V
C225 1-163-031-11 CERAMIC CHIP0.01µF 50V
C226 1-163-031-11 CERAMIC CHIP0.01µF 50V
C227 1-163-031-11 CERAMIC CHIP0.01µF 50V
C228 1-163-031-11 CERAMIC CHIP0.01µF 50V
C229 1-163-031-11 CERAMIC CHIP0.01µF 50V
C230 1-163-031-11 CERAMIC CHIP0.01µF 50V
C231 1-126-206-11 ELECT CHIP 100µF 20% 6.3V
C232 1-126-206-11 ELECT CHIP 100µF 20% 6.3V
C233 1-126-206-11 ELECT CHIP 100µF 20% 6.3V
C234 1-163-031-11 CERAMIC CHIP0.01µF 50V
<CONNECTOR>
CN201 1-785-728-21 PIN (PC BOARD), CONNECTOR 7P
CN202 * 1-770-470-21 PIN, CONNECTOR (PC BOARD) 6P
CN203 1-779-993-11 PIN, CONNECTOR (PWB) 5P
<DIODE>
D201 8-719-073-01 DIODE MA111-(K8).S0
D202 8-719-073-01 DIODE MA111-(K8).S0
G HA
