9-18
BVM-D9H1U/D9H5U/D9H1E/D9H5E/D9H1A/D9H5A
Ref.No. Part No. Description RemarkRef.No. Part No. Description Remark
D203 8-719-073-01 DIODE MA111-(K8).S0
D204 8-719-073-01 DIODE MA111-(K8).S0
D205 8-719-073-01 DIODE MA111-(K8).S0
D206 8-719-073-01 DIODE MA111-(K8).S0
D207 8-719-073-01 DIODE MA111-(K8).S0
D208 8-719-073-01 DIODE MA111-(K8).S0
D209 8-719-073-01 DIODE MA111-(K8).S0
D210 8-719-073-01 DIODE MA111-(K8).S0
D211 8-719-073-01 DIODE MA111-(K8).S0
D212 8-719-073-01 DIODE MA111-(K8).S0
D213 8-719-073-01 DIODE MA111-(K8).S0
D219 8-719-073-01 DIODE MA111-(K8).S0
D220 8-719-073-01 DIODE MA111-(K8).S0
D221 8-719-073-01 DIODE MA111-(K8).S0
D222 8-719-073-01 DIODE MA111-(K8).S0
D223 8-719-054-22 DIODE SML-020MLTT87
D224 8-719-054-22 DIODE SML-020MLTT87
D225 8-719-054-22 DIODE SML-020MLTT87
D226 8-719-054-22 DIODE SML-020MLTT87
D227 8-719-158-19 DIODE RD6.2SB
D232 8-719-073-01 DIODE MA111-(K8).S0
D233 8-719-073-01 DIODE MA111-(K8).S0
D234 8-719-073-01 DIODE MA111-(K8).S0
D235 8-719-073-01 DIODE MA111-(K8).S0
D242 8-719-073-01 DIODE MA111-(K8).S0
D243 8-719-073-01 DIODE MA111-(K8).S0
D244 8-719-073-01 DIODE MA111-(K8).S0
D245 8-719-073-01 DIODE MA111-(K8).S0
D246 8-719-073-01 DIODE MA111-(K8).S0
D247 8-719-073-01 DIODE MA111-(K8).S0
<IC>
IC201 8-759-342-19 IC NJU3716M-T2
IC202 8-759-342-19 IC NJU3716M-T2
IC203 8-759-342-19 IC NJU3716M-T2
IC204 8-759-342-19 IC NJU3716M-T2
<TRANSISTOR>
Q201 1-801-806-11 TRANSISTOR DTC144EKA-T146
Q202 8-729-921-12 TRANSISTOR 2SD1834
Q203 8-729-921-12 TRANSISTOR 2SD1834
Q204 1-801-806-11 TRANSISTOR DTC144EKA-T146
Q205 8-729-921-12 TRANSISTOR 2SD1834
Q206 8-729-921-12 TRANSISTOR 2SD1834
<RESISTOR>
R201 1-216-051-00 RES,CHIP 1.2K 5% 1/10W
R202 1-216-051-00 RES,CHIP 1.2K 5% 1/10W
R203 1-216-051-00 RES,CHIP 1.2K 5% 1/10W
R204 1-216-051-00 RES,CHIP 1.2K 5% 1/10W
R205 1-216-097-91 RES,CHIP 100K 5% 1/10W
R206 1-216-049-91 RES,CHIP 1K 5% 1/10W
R207 1-216-049-91 RES,CHIP 1K 5% 1/10W
R208 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R209 1-216-049-91 RES,CHIP 1K 5% 1/10W
R210 1-216-097-91 RES,CHIP 100K 5% 1/10W
R211 1-216-085-00 RES,CHIP 33K 5% 1/10W
R212 1-216-095-00 RES,CHIP 82K 5% 1/10W
R213 1-216-085-00 RES,CHIP 33K 5% 1/10W
R214 1-216-095-00 RES,CHIP 82K 5% 1/10W
R215 1-216-089-91 RES,CHIP 47K 5% 1/10W
R216 1-216-089-91 RES,CHIP 47K 5% 1/10W
R217 1-216-089-91 RES,CHIP 47K 5% 1/10W
R218 1-216-089-91 RES,CHIP 47K 5% 1/10W
R219 1-216-089-91 RES,CHIP 47K 5% 1/10W
R220 1-216-089-91 RES,CHIP 47K 5% 1/10W
R221 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R222 1-216-049-91 RES,CHIP 1K 5% 1/10W
R223 1-216-049-91 RES,CHIP 1K 5% 1/10W
R224 1-216-049-91 RES,CHIP 1K 5% 1/10W
R225 1-216-097-91 RES,CHIP 100K 5% 1/10W
R226 1-216-035-00 RES,CHIP 270 5% 1/10W
R227 1-216-035-00 RES,CHIP 270 5% 1/10W
R228 1-216-095-00 RES,CHIP 82K 5% 1/10W
R229 1-216-095-00 RES,CHIP 82K 5% 1/10W
R230 1-216-035-00 RES,CHIP 270 5% 1/10W
R231 1-216-035-00 RES,CHIP 270 5% 1/10W
R232 1-216-085-00 RES,CHIP 33K 5% 1/10W
R233 1-216-085-00 RES,CHIP 33K 5% 1/10W
R234 1-216-097-91 RES,CHIP 100K 5% 1/10W
R235 1-216-035-00 RES,CHIP 270 5% 1/10W
R236 1-216-035-00 RES,CHIP 270 5% 1/10W
R237 1-216-035-00 RES,CHIP 270 5% 1/10W
R238 1-216-035-00 RES,CHIP 270 5% 1/10W
R239 1-216-035-00 RES,CHIP 270 5% 1/10W
R240 1-216-035-00 RES,CHIP 270 5% 1/10W
<SWITCH>
S201 1-692-037-31 SWITCH, KEY BOARD (POWER)
S202 1-692-037-31 SWITCH, KEY BOARD (DEGAUSS)
S203 1-692-037-31 SWITCH, KEY BOARD (NUM-1)
S204 1-692-037-31 SWITCH, KEY BOARD (NUM-2)
S205 1-692-037-31 SWITCH, KEY BOARD (NUM-3)
S206 1-692-037-31 SWITCH, KEY BOARD ((DEL)
S207 1-692-037-31 SWITCH, KEY BOARD (NUM-4)
S208 1-692-037-31 SWITCH, KEY BOARD (NUM-5)
S209 1-692-037-31 SWITCH, KEY BOARD (NUM-6)
S210 1-692-037-31 SWITCH, KEY BOARD (NUM-0)
S211 1-692-037-31 SWITCH, KEY BOARD (NUM-7)
S212 1-692-037-31 SWITCH, KEY BOARD (NUM-8)
S213 1-692-037-31 SWITCH, KEY BOARD (NUM-9)
S214 1-692-037-31 SWITCH, KEY BOARD (MENU)
S215 1-692-037-31 SWITCH, KEY BOARD (ENTER)
S216 1-62-037-31 SWITCH, KEY BOARD (UP)
S217 1-692-037-31 SWITCH, KEY BOARD (DOWN)
S218 1-771-804-11 SWITCH, TACTILE (COMB
S219 1-771-804-11 SWITCH, TACTILE (F1)
S220 1-771-804-11 SWITCH, TACTILE (F2)
S221 1-771-804-11 SWITCH, TACTILE (ADDRESS)
S222 1-771-804-11 SWITCH, TACTILE (SHIFT)
S223 1-771-804-11 SWITCH, TACTILE (U/S)
S224 1-771-804-11 SWITCH, TACTILE (H DLAY)
S225 1-771-804-11 SWITCH, TACTILE (V DLAY)
S226 1-771-804-11 SWITCH, TACTILE (MONO)
S227 1-771-804-11 SWITCH, TACTILE (APT)SW
****************************************************************
* A-1372-676-A HB MOUNT (D9H5)
******************
<CAPACITOR>
C1200 1-163-031-11 CERAMIC CHIP0.01µF 50V
C1201 1-163-031-11 CERAMIC CHIP0.01µF 50V
C1202 1-163-031-11 CERAMIC CHIP0.01µF 50V
C1203 1-163-031-11 CERAMIC CHIP0.01µF 50V
C1204 1-163-031-11 CERAMIC CHIP0.01µF 50V
HA HB
