Sony TRINITRON BVM-D9H5U - Page 109

9-19
BVM-D9H1U/D9H5U/D9H1E/D9H5E/D9H1A/D9H5A
Ref.No. Part No. Description RemarkRef.No. Part No. Description Remark
C1205 1-163-031-11 CERAMIC CHIP0.01µF 50V
C1206 1-163-031-11 CERAMIC CHIP0.01µF 50V
C1207 1-163-031-11 CERAMIC CHIP0.01µF 50V
<CONNECTOR>
CN1200 * 1-564-719-11 PIN, CONNECTOR (SMALL TYPE) 3P
CN1201 * 1-564-726-11 PIN, CONNECTOR (SMALL TYPE)10P
CN1203 1-564-721-11 PIN, CONNECTOR (SMALL TYPE) 5P
<DIODE>
D1200 8-719-158-19 DIODE RD6.2SB
D1201 8-719-073-01 DIODE MA111-(K8).S0
D1202 8-719-073-01 DIODE MA111-(K8).S0
D1203 8-719-073-01 DIODE MA111-(K8).S0
D1204 8-719-073-01 DIODE MA111-(K8).S0
<CHIP CONDUCTOR>
JR1200 1-216-295-91 SHORT 0
<RESISTOR>
R1200 1-216-081-00 RES,CHIP 22K 5% 1/10W
R1201 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R1202 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R1203 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R1204 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R1205 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R1206 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R1207 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R1208 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
<VARIABLE RESISTOR>
RV1200 1-223-504-21 RES, VAR, CARBON 20K
<SWITCH>
S1200 1-418-651-11 ENCODER, ROTARY (PHASE)
S1201 1-418-651-11 ENCODER, ROTARY (CHROMA)
S1202 1-418-651-11 ENCODER, ROTARY (BRIGHT)
S1203 1-418-651-11 ENCODER, ROTARY (CONTRAST)SW
****************************************************************
* A-1375-186-A HC COMPL (D9H5)
******************
1-540-044-11 SOCKET, IC
4-382-854-01 SCREW(M3X8), P, SW (+)
<CAPACITOR>
C1 1-163-227-11 CERAMIC CHIP10PF 0.5PF 50V
C2 1-163-227-11 CERAMIC CHIP10PF 0.5PF 50V
C4 1-163-031-11 CERAMIC CHIP0.01µF 50V
C50 1-163-031-11 CERAMIC CHIP0.01µF 50V
C52 1-163-031-11 CERAMIC CHIP0.01µF 50V
C53 1-163-031-11 CERAMIC CHIP0.01µF 50V
C54 1-163-031-11 CERAMIC CHIP0.01µF 50V
C55 1-163-031-11 CERAMIC CHIP0.01µF 50V
C56 1-126-941-11 ELECT 470µF 20% 25V
C57 1-126-786-11 ELECT 47µF 20% 16V
C60 1-163-031-11 CERAMIC CHIP0.01µF 50V
C61 1-163-031-11 CERAMIC CHIP0.01µF 50V
C62 1-163-031-11 CERAMIC CHIP0.01µF 50V
C63 1-163-031-11 CERAMIC CHIP0.01µF 50V
C64 1-163-031-11 CERAMIC CHIP0.01µF 50V
C65 1-163-031-11 CERAMIC CHIP0.01µF 50V
C67 1-163-031-11 CERAMIC CHIP0.01µF 50V
C68 1-163-031-11 CERAMIC CHIP0.01µF 50V
C81 1-126-206-11 ELECT CHIP 100µF 20% 6.3V
C82 1-124-635-00 ELECT 220µF 20% 6.3V
C83 1-126-206-11 ELECT CHIP 100µF 20% 6.3V
C84 1-126-206-11 ELECT CHIP 100µF 20% 6.3V
C85 1-126-206-11 ELECT CHIP 100µF 20% 6.3V
C86 1-126-206-11 ELECT CHIP 100µF 20% 6.3V
C87 1-126-206-11 ELECT CHIP 100µF 20% 6.3V
C89 1-126-206-11 ELECT CHIP 100µF 20% 6.3V
<CONNECTOR>
CN2 * 1-564-711-11 PIN, CONNECTOR (SMALL TYPE) 9P
CN3 * 1-564-712-11 PIN, CONNECTOR (SMALL TYPE)10P
CN4 * 1-564-708-11 PIN, CONNECTOR (SMALL TYPE) 6P
CN5 * 1-564-708-11 PIN, CONNECTOR (SMALL TYPE) 6P
CN6 * 1-564-508-11 PLUG, CONNECTOR 5P
<DIODE>
D1 8-719-158-19 DIODE RD6.2SB
D2 8-719-158-19 DIODE RD6.2SB
D3 8-719-158-19 DIODE RD6.2SB
D4 8-719-158-19 DIODE RD6.2SB
D5 8-719-158-19 DIODE RD6.2SB
D6 8-719-158-19 DIODE RD6.2SB
D7 8-719-158-19 DIODE RD6.2SB
D8 8-719-158-19 DIODE RD6.2SB
<FILTER>
FL1 1-239-183-11 FILTER, EMI
FL2 1-239-183-11 FILTER, EMI
FL3 1-239-183-11 FILTER, EMI
FL4 1-239-183-11 FILTER, EMI
FL5 1-236-071-11 ENCAPSULATED COMPONENT
FL6 1-236-071-11 ENCAPSULATED COMPONENT
FL7 1-239-183-11 FILTER, EMI
FL8 1-239-183-11 FILTER, EMI
FL9 1-239-183-11 FILTER, EMI
FL10 1-239-183-11 FILTER, EMI
FL11 1-236-071-11 ENCAPSULATED COMPONENT
FL12 1-239-183-11 FILTER, EMI
FL13 1-239-183-11 FILTER, EMI
FL14 1-239-183-11 FILTER, EMI
FL15 1-239-183-11 FILTER, EMI
FL16 1-236-071-11 ENCAPSULATED COMPONENT
<IC>
IC2 8-759-991-19 IC PST529CMT
IC3 8-759-186-47 IC TC74VHC138F
IC9 8-759-186-30 IC TC74VHC14F
IC10 8-759-186-30 IC TC74VHC14F
IC11 8-759-175-27 IC TC74VHC574F
IC12 8-759-174-16 IC TC74VHC244F
IC13 8-759-289-43 IC LTC490CS8
IC14 8-759-394-36 IC BA09T
HB HC
