9-20
BVM-D9H1U/D9H5U/D9H1E/D9H5E/D9H1A/D9H5A
Ref.No. Part No. Description RemarkRef.No. Part No. Description Remark
<COIL>
L2 1-412-537-31 INDUCTOR 100µH
L4 1-412-544-15 INDUCTOR 390µH
<RESISTOR>
R1 1-216-073-00 RES,CHIP 10K 5% 1/10W
R2 1-216-295-91 SHORT 0
R3 1-216-073-00 RES,CHIP 10K 5% 1/10W
R4 1-216-073-00 RES,CHIP 10K 5% 1/10W
R5 1-216-073-00 RES,CHIP 10K 5% 1/10W
R6 1-216-073-00 RES,CHIP 10K 5% 1/10W
R7 1-216-097-91 RES,CHIP 100K 5% 1/10W
R12 1-216-073-00 RES,CHIP 10K 5% 1/10W
R13 1-216-073-00 RES,CHIP 10K 5% 1/10W
R14 1-216-049-91 RES,CHIP 1K 5% 1/10W
R15 1-216-049-91 RES,CHIP 1K 5% 1/10W
R16 1-216-073-00 RES,CHIP 10K 5% 1/10W
R19 1-216-073-00 RES,CHIP 10K 5% 1/10W
R20 1-216-073-00 RES,CHIP 10K 5% 1/10W
R21 1-216-049-91 RES,CHIP 1K 5% 1/10W
R22 1-216-049-91 RES,CHIP 1K 5% 1/10W
R23 1-216-049-91 RES,CHIP 1K 5% 1/10W
R24 1-216-049-91 RES,CHIP 1K 5% 1/10W
R25 1-216-049-91 RES,CHIP 1K 5% 1/10W
R26 1-216-049-91 RES,CHIP 1K 5% 1/10W
R27 1-216-049-91 RES,CHIP 1K 5% 1/10W
R28 1-216-049-91 RES,CHIP 1K 5% 1/10W
R41 1-216-073-00 RES,CHIP 10K 5% 1/10W
R42 1-216-073-00 RES,CHIP 10K 5% 1/10W
R43 1-216-073-00 RES,CHIP 10K 5% 1/10W
R44 1-216-073-00 RES,CHIP 10K 5% 1/10W
R60 1-216-089-91 RES,CHIP 47K 5% 1/10W
R61 1-216-089-91 RES,CHIP 47K 5% 1/10W
R62 1-216-089-91 RES,CHIP 47K 5% 1/10W
R63 1-216-089-91 RES,CHIP 47K 5% 1/10W
R64 1-216-089-91 RES,CHIP 47K 5% 1/10W
R65 1-216-089-91 RES,CHIP 47K 5% 1/10W
R66 1-216-089-91 RES,CHIP 47K 5% 1/10W
R67 1-216-089-91 RES,CHIP 47K 5% 1/10W
R68 1-216-097-91 RES,CHIP 100K 5% 1/10W
R70 1-216-097-91 RES,CHIP 100K 5% 1/10W
R71 1-216-097-91 RES,CHIP 100K 5% 1/10W
R72 1-216-097-91 RES,CHIP 100K 5% 1/10W
R73 1-216-097-91 RES,CHIP 100K 5% 1/10W
R74 1-216-097-91 RES,CHIP 100K 5% 1/10W
R75 1-216-097-91 RES,CHIP 100K 5% 1/10W
R76 1-216-097-91 RES,CHIP 100K 5% 1/10W
R77 1-216-097-91 RES,CHIP 100K 5% 1/10W
R78 1-216-097-91 RES,CHIP 100K 5% 1/10W
R79 1-216-097-91 RES,CHIP 100K 5% 1/10W
R80 1-216-097-91 RES,CHIP 100K 5% 1/10W
R81 1-216-097-91 RES,CHIP 100K 5% 1/10W
R82 1-216-097-91 RES,CHIP 100K 5% 1/10W
R83 1-216-097-91 RES,CHIP 100K 5% 1/10W
R84 1-216-097-91 RES,CHIP 100K 5% 1/10W
R85 1-216-097-91 RES,CHIP 100K 5% 1/10W
R86 1-216-097-91 RES,CHIP 100K 5% 1/10W
R87 1-216-097-91 RES,CHIP 100K 5% 1/10W
R88 1-216-097-91 RES,CHIP 100K 5% 1/10W
R89 1-216-097-91 RES,CHIP 100K 5% 1/10W
R90 1-216-097-91 RES,CHIP 100K 5% 1/10W
R91 1-216-097-91 RES,CHIP 100K 5% 1/10W
R92 1-216-097-91 RES,CHIP 100K 5% 1/10W
R93 1-216-097-91 RES,CHIP 100K 5% 1/10W
R94 1-216-097-91 RES,CHIP 100K 5% 1/10W
<CRYSTAL>
X1 1-767-892-21 VIBRATOR, CRYSTAL (20 MHz)
****************************************************************
* A-1372-677-A HD MOUNT (D9H5)
******************
<CAPACITOR>
C3200 1-126-791-11 ELECT 10µF 20% 16V
C3201 1-126-791-11 ELECT 10µF 20% 16V
C3202 1-126-791-11 ELECT 10µF 20% 16V
C3203 1-163-031-11 CERAMIC CHIP0.01µF 50V
C3204 1-126-786-11 ELECT 47µF 20% 16V
C3205 1-163-031-11 CERAMIC CHIP0.01µF 50V
C3206 1-163-031-11 CERAMIC CHIP0.01µF 50V
C3207 1-126-786-11 ELECT 47µF 20% 16V
C3209 1-126-791-11 ELECT 10µF 20% 16V
C3210 1-115-868-11 ELECT 0.22µF 20% 50V
C3211 1-163-017-00 CERAMIC CHIP0.0047µF 10% 50V
C3212 1-126-791-11 ELECT 10µF 20% 16V
C3213 1-126-791-11 ELECT 10µF 20% 16V
C3214 1-137-397-11 MYLAR 0.047µF 5% 100V
C3215 1-128-499-11 ELECT 220µF 20% 16V
C3216 1-126-786-11 ELECT 47µF 20% 16V
C3217 1-128-499-11 ELECT 220µF 20% 16V
C3218 1-126-791-11 ELECT 10µF 20% 16V
C3219 1-163-031-11 CERAMIC CHIP0.01µF 50V
<CONNECTOR>
CN3200 * 1-564-518-11 PLUG, CONNECTOR 3P
CN3202 * 1-564-517-11 PLUG, CONNECTOR 2P
CN3203 * 1-564-526-11 PLUG, CONNECTOR 11P
<FERRITE BEAD>
FB3200 1-410-396-41 FERRITE 0.45µH
<FILTER>
FL3200 1-239-384-11 FILTER, EMI
FL3201 1-239-384-11 FILTER, EMI
FL3202 1-239-384-11 FILTER, EMI
<IC>
IC3200 8-759-009-06 IC MC14052BF
IC3201 8-759-420-04 IC AN5265
<JACK>
J3200 1-793-632-11 JACK, PIN (LINE A)
J3201 1-793-632-11 JACK, PIN (LINE B)
J3202 1-793-632-11 JACK, PIN (LINE C)
<JACKCHIP CONDUCTOR>
JR3201 1-216-295-91 SHORT 0
<TRANSISTOR>
Q3200 8-729-026-50 TRANSISTOR 2SA1037AK-T146-QR
Q3201 8-729-026-50 TRANSISTOR 2SA1037AK-T146-QR
HC HD
