9-21
BVM-D9H1U/D9H5U/D9H1E/D9H5E/D9H1A/D9H5A
Ref.No. Part No. Description RemarkRef.No. Part No. Description Remark
Q3202 8-729-026-50 TRANSISTOR 2SA1037AK-T146-QR
Q3203 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q3205 1-801-806-11 TRANSISTOR DTC144EKA-T146
Q3206 1-801-806-11 TRANSISTOR DTC144EKA-T146
Q3207 8-729-026-49 TRANSISTOR 2SA1037AK-T146-R
<RESISTOR>
R3200 1-249-440-11 CARBON 82K 5% 1/4W
R3201 1-249-440-11 CARBON 82K 5% 1/4W
R3202 1-249-440-11 CARBON 82K 5% 1/4W
R3203 1-216-097-91 RES,CHIP 100K 5% 1/10W
R3204 1-216-097-91 RES,CHIP 100K 5% 1/10W
R3205 1-216-097-91 RES,CHIP 100K 5% 1/10W
R3206 1-216-105-91 RES,CHIP 220K 5% 1/10W
R3207 1-216-115-00 RES,CHIP 560K 5% 1/10W
R3208 1-216-105-91 RES,CHIP 220K 5% 1/10W
R3209 1-216-115-00 RES,CHIP 560K 5% 1/10W
R3210 1-216-105-91 RES,CHIP 220K 5% 1/10W
R3211 1-216-115-00 RES,CHIP 560K 5% 1/10W
R3212 1-216-077-91 RES,CHIP 15K 5% 1/10W
R3213 1-216-077-91 RES,CHIP 15K 5% 1/10W
R3214 1-216-077-91 RES,CHIP 15K 5% 1/10W
R3215 1-216-025-91 RES,CHIP 100 5% 1/10W
R3216 1-216-025-91 RES,CHIP 100 5% 1/10W
R3217 1-216-025-91 RES,CHIP 100 5% 1/10W
R3218 1-216-025-91 RES,CHIP 100 5% 1/10W
R3219 1-216-025-91 RES,CHIP 100 5% 1/10W
R3220 1-216-025-91 RES,CHIP 100 5% 1/10W
R3221 1-216-077-91 RES,CHIP 15K 5% 1/10W
R3222 1-216-025-91 RES,CHIP 100 5% 1/10W
R3226 1-216-091-00 RES,CHIP 56K 5% 1/10W
R3228 1-249-389-11 CARBON 4.7 5% 1/4W
R3229 1-249-424-11 CARBON 3.9K 5% 1/4W
R3230 1-249-415-11 CARBON 680 5% 1/4W
R3231 1-216-085-00 RES,CHIP 33K 5% 1/10W
R3232 1-216-081-00 RES,CHIP 22K 5% 1/10W
R3233 1-249-393-11 CARBON 10 5% 1/4W F
R3234 1-249-389-11 CARBON 4.7 5% 1/4W F
R3235 1-216-073-00 RES,CHIP 10K 5% 1/10W
R3236 1-216-073-00 RES,CHIP 10K 5% 1/10W
R3237 1-216-081-00 RES,CHIP 22K 5% 1/10W
R3238 1-216-077-91 RES,CHIP 15K 5% 1/10W
R3239 1-216-025-91 RES,CHIP 100 5% 1/10W
****************************************************************
* A-1306-574-A MA COMPL (D9H1)
*******************
* A-1306-581-A MA COMPL (D9H5)
*******************
1-540-222-11 SOCKET, IC (PCC PACKAGE) 84P
1-550-104-11 HOLDER, BATTERY
BATTERY, LITHIUM CR2025
<CAPACITOR>
C101 1-163-031-11 CERAMIC CHIP0.01µF 50V
C102 1-126-392-11 ELECT CHIP 100µF 20% 6.3V
C103 1-126-392-11 ELECT CHIP 100µF 20% 6.3V
C104 1-163-031-11 CERAMIC CHIP0.01µF 50V
C105 1-163-235-11 CERAMIC CHIP22PF 5% 50V
C106 1-163-227-11 CERAMIC CHIP10PF 0.5PF 50V
C108 1-126-392-11 ELECT CHIP 100µF 20% 6.3V
C109 1-126-392-11 ELECT CHIP 100µF 20% 6.3V
C110 1-163-031-11 CERAMIC CHIP0.01µF 50V
C111 1-126-392-11 ELECT CHIP 100µF 20% 6.3V
C112 1-126-392-11 ELECT CHIP 100µF 20% 6.3V
C113 1-163-031-11 CERAMIC CHIP0.01µF 50V
C114 1-163-031-11 CERAMIC CHIP0.01µF 50V
C115 1-163-031-11 CERAMIC CHIP0.01µF 50V
C116 1-126-392-11 ELECT CHIP 100µF 20% 6.3V
C117 1-163-031-11 CERAMIC CHIP0.01µF 50V
C118 1-126-392-11 ELECT CHIP 100µF 20% 6.3V
C119 1-163-031-11 CERAMIC CHIP0.01µF 50V
C120 1-163-031-11 CERAMIC CHIP0.01µF 50V
C121 1-126-392-11 ELECT CHIP 100µF 20% 6.3V
C122 1-126-392-11 ELECT CHIP 100µF 20% 6.3V
C123 1-163-031-11 CERAMIC CHIP0.01µF 50V
C124 1-163-031-11 CERAMIC CHIP0.01µF 50V
C125 1-126-392-11 ELECT CHIP 100µF 20% 6.3V
C126 1-163-031-11 CERAMIC CHIP0.01µF 50V
C127 1-163-031-11 CERAMIC CHIP0.01µF 50V
C128 1-126-392-11 ELECT CHIP 100µF 20% 6.3V
C129 1-126-392-11 ELECT CHIP 100µF 20% 6.3V
C130 1-163-031-11 CERAMIC CHIP0.01µF 50V
C131 1-163-031-11 CERAMIC CHIP0.01µF 50V
C132 1-126-392-11 ELECT CHIP 100µF 20% 6.3V
C133 1-126-392-11 ELECT CHIP 100µF 20% 6.3V
C134 1-163-031-11 CERAMIC CHIP0.01µF 50V
C135 1-163-031-11 CERAMIC CHIP0.01µF 50V
C136 1-126-392-11 ELECT CHIP 100µF 20% 6.3V
C137 1-163-031-11 CERAMIC CHIP0.01µF 50V
C139 1-163-031-11 CERAMIC CHIP0.01µF 50V
C140 1-163-031-11 CERAMIC CHIP0.01µF 50V
C141 1-163-031-11 CERAMIC CHIP0.01µF 50V
C142 1-163-031-11 CERAMIC CHIP0.01µF 50V
C144 1-163-031-11 CERAMIC CHIP0.01µF 50V
C145 1-163-031-11 CERAMIC CHIP0.01µF 50V
C147 1-163-031-11 CERAMIC CHIP0.01µF 50V
C148 1-163-031-11 CERAMIC CHIP0.01µF 50V
C149 1-126-392-11 ELECT CHIP 100µF 20% 6.3V
C150 1-163-031-11 CERAMIC CHIP0.01µF 50V
C151 1-163-031-11 CERAMIC CHIP0.01µF 50V
C153 1-163-031-11 CERAMIC CHIP0.01µF 50V
C154 1-163-031-11 CERAMIC CHIP0.01µF 50V
C159 1-126-392-11 ELECT CHIP 100µF 20% 6.3V
C160 1-163-031-11 CERAMIC CHIP0.01µF 50V
C161 1-163-031-11 CERAMIC CHIP0.01µF 50V
C162 1-163-031-11 CERAMIC CHIP0.01µF 50V
C163 1-126-392-11 ELECT CHIP 100µF 20% 6.3V
C164 1-163-031-11 CERAMIC CHIP0.01µF 50V
C165 1-126-400-11 ELECT CHIP 22µF 20% 35V
C166 1-126-392-11 ELECT CHIP 100µF 20% 6.3V
C168 1-126-392-11 ELECT CHIP 100µF 20% 6.3V
C169 1-163-031-11 CERAMIC CHIP0.01µF 50V
C171 1-163-031-11 CERAMIC CHIP0.01µF 50V
C172 1-126-392-11 ELECT CHIP 100µF 20% 6.3V
<CONNECTOR>
CN101 * 1-564-525-11 PLUG, CONNECTOR 10P
CN102 * 1-793-722-11 PIN, CONNECTOR (PC BOARD) 50P
CN103 * 1-564-522-11 PLUG, CONNECTOR 7P
CN104 * 1-564-526-11 PLUG, CONNECTOR 11P (D9H5)
CN105 * 1-564-524-11 PLUG, CONNECTOR 9P (D9H5)
<DIODE>
D101 8-719-158-19 DIODE RD6.2SB
D102 8-719-158-19 DIODE RD6.2SB
HD MA
