9-22
BVM-D9H1U/D9H5U/D9H1E/D9H5E/D9H1A/D9H5A
Ref.No. Part No. Description RemarkRef.No. Part No. Description Remark
D103 8-719-158-19 DIODE RD6.2SB
D104 8-719-158-19 DIODE RD6.2SB
D105 8-719-158-19 DIODE RD6.2SB (D9H5)
D107 8-719-158-19 DIODE RD6.2SB (D9H5)
D109 8-719-158-19 DIODE RD6.2SB
<FILTER>
FL103 1-239-183-11 FILTER, EMI
FL104 1-239-183-11 FILTER, EMI
FL105 1-239-183-11 FILTER, EMI
FL107 1-239-183-11 FILTER, EMI
FL108 1-239-183-11 FILTER, EMI
FL109 1-239-183-11 FILTER, EMI
FL110 1-239-183-11 FILTER, EMI
FL111 1-239-183-11 FILTER, EMI
FL112 1-239-183-11 FILTER, EMI
FL113 1-239-183-11 FILTER, EMI
FL114 1-236-071-11 ENCAPSULATED COMPONENT
FL115 1-236-071-11 ENCAPSULATED COMPONENT
FL116 1-239-183-11 FILTER, EMI (D9H5)
FL117 1-236-071-11 ENCAPSULATED COMPONENT
FL118 1-239-183-11 FILTER, EMI (D9H5)
FL120 1-239-183-11 FILTER, EMI
FL121 1-239-183-11 FILTER, EMI (D9H5)
FL123 1-239-183-11 FILTER, EMI
<IC>
IC101 8-759-186-44 IC TC74VHC125F
IC102 8-759-082-59 IC TC7W32FU
IC103 8-759-925-75 IC SN74HC05ANS
IC104 8-759-239-98 IC TC74HC30AF
IC106 8-759-644-13 IC HD6435368AX06M
IC107 8-759-081-44 IC TC74VHC04F
IC108 8-759-553-93 IC MBM29F400BC-90PF
IC109 8-759-186-47 IC TC74VHC138F
IC110 8-759-346-07 IC MM1026BFB
IC111 8-759-497-29 IC LC35256DM-70-TLM
IC113 8-759-575-91 IC MAX490ECSA
<CHIP CONDUCTOR>
JR101 1-216-295-91 SHORT 0
JR103 1-216-097-91 RES,CHIP 100K 5% 1/10W
<COIL>
L101 1-412-537-31 INDUCTOR 100µH
<TRANSISTOR>
Q102 8-729-027-38 TRANSISTOR DTA144EKA-T146
Q103 1-801-806-11 TRANSISTOR DTC144EKA-T146
Q104 1-801-806-11 TRANSISTOR DTC144EKA-T146
Q105 8-729-903-46 TRANSISTOR 2SB1132-P
Q106 8-729-903-46 TRANSISTOR 2SB1132-P
<RESISTOR>
R101 1-216-097-91 RES,CHIP 100K 5% 1/10W
R102 1-216-097-91 RES,CHIP 100K 5% 1/10W
R103 1-216-025-91 RES,CHIP 100 5% 1/10W
R104 1-216-025-91 RES,CHIP 100 5% 1/10W
R105 1-216-097-91 RES,CHIP 100K 5% 1/10W
R106 1-216-097-91 RES,CHIP 100K 5% 1/10W
R107 1-216-097-91 RES,CHIP 100K 5% 1/10W
R108 1-216-097-91 RES,CHIP 100K 5% 1/10W
R109 1-216-097-91 RES,CHIP 100K 5% 1/10W
R110 1-216-097-91 RES,CHIP 100K 5% 1/10W
R111 1-216-097-91 RES,CHIP 100K 5% 1/10W
R112 1-216-097-91 RES,CHIP 100K 5% 1/10W
R113 1-216-025-91 RES,CHIP 100 5% 1/10W
R114 1-216-295-91 SHORT 0 (D9H5)
R115 1-216-025-91 RES,CHIP 100 5% 1/10W
R116 1-216-025-91 RES,CHIP 100 5% 1/10W
R117 1-216-025-91 RES,CHIP 100 5% 1/10W
R118 1-216-097-91 RES,CHIP 100K 5% 1/10W
R119 1-216-097-91 RES,CHIP 100K 5% 1/10W
R120 1-216-025-91 RES,CHIP 100 5% 1/10W
R121 1-216-097-91 RES,CHIP 100K 5% 1/10W
R122 1-216-025-91 RES,CHIP 100 5% 1/10W
R123 1-216-121-91 RES,CHIP 1M 5% 1/10W
R124 1-216-025-91 RES,CHIP 100 5% 1/10W
R125 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R126 1-216-025-91 RES,CHIP 100 5% 1/10W
R127 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R128 1-216-097-91 RES,CHIP 100K 5% 1/10W
R129 1-216-097-91 RES,CHIP 100K 5% 1/10W
R130 1-216-049-91 RES,CHIP 1K 5% 1/10W
R131 1-216-049-91 RES,CHIP 1K 5% 1/10W
R132 1-216-097-91 RES,CHIP 100K 5% 1/10W
R133 1-216-049-91 RES,CHIP 1K 5% 1/10W
R134 1-216-049-91 RES,CHIP 1K 5% 1/10W
R135 1-216-073-00 RES,CHIP 10K 5% 1/10W
R136 1-216-073-00 RES,CHIP 10K 5% 1/10W
R137 1-216-073-00 RES,CHIP 10K 5% 1/10W
R138 1-216-097-91 RES,CHIP 100K 5% 1/10W
R139 1-216-049-91 RES,CHIP 1K 5% 1/10W
R140 1-216-097-91 RES,CHIP 100K 5% 1/10W
R141 1-216-049-91 RES,CHIP 1K 5% 1/10W
R142 1-216-097-91 RES,CHIP 100K 5% 1/10W
R143 1-216-049-91 RES,CHIP 1K 5% 1/10W
R144 1-216-097-91 RES,CHIP 100K 5% 1/10W
R145 1-216-049-91 RES,CHIP 1K 5% 1/10W
R146 1-216-097-91 RES,CHIP 100K 5% 1/10W
R147 1-216-049-91 RES,CHIP 1K 5% 1/10W
R148 1-216-097-91 RES,CHIP 100K 5% 1/10W
R150 1-216-097-91 RES,CHIP 100K 5% 1/10W
R151 1-216-097-91 RES,CHIP 100K 5% 1/10W
R152 1-216-073-00 RES,CHIP 10K 5% 1/10W
R153 1-216-073-00 RES,CHIP 10K 5% 1/10W
R154 1-216-097-91 RES,CHIP 100K 5% 1/10W
R155 1-216-097-91 RES,CHIP 100K 5% 1/10W
R156 1-216-097-91 RES,CHIP 100K 5% 1/10W
R157 1-216-097-91 RES,CHIP 100K 5% 1/10W
R158 1-216-073-00 RES,CHIP 10K 5% 1/10W
R159 1-216-049-91 RES,CHIP 1K 5% 1/10W
R160 1-216-073-00 RES,CHIP 10K 5% 1/10W
R161 1-216-097-91 RES,CHIP 100K 5% 1/10W
R162 1-216-097-91 RES,CHIP 100K 5% 1/10W
R163 1-216-097-91 RES,CHIP 100K 5% 1/10W
R164 1-216-097-91 RES,CHIP 100K 5% 1/10W
R165 1-216-097-91 RES,CHIP 100K 5% 1/10W
R166 1-216-025-91 RES,CHIP 100 5% 1/10W
R167 1-216-097-91 RES,CHIP 100K 5% 1/10W
R168 1-216-025-91 RES,CHIP 100 5% 1/10W
R169 1-216-097-91 RES,CHIP 100K 5% 1/10W
R170 1-216-025-91 RES,CHIP 100 5% 1/10W
R171 1-216-025-91 RES,CHIP 100 5% 1/10W
