9-23
BVM-D9H1U/D9H5U/D9H1E/D9H5E/D9H1A/D9H5A
Ref.No. Part No. Description RemarkRef.No. Part No. Description Remark
R173 1-216-025-91 RES,CHIP 100 5% 1/10W
R174 1-216-025-91 RES,CHIP 100 5% 1/10W
R177 1-216-025-91 RES,CHIP 100 5% 1/10W
R178 1-216-053-00 RES,CHIP 1.5K 5% 1/10W
R179 1-216-047-91 RES,CHIP 820 5% 1/10W
R180 1-216-073-00 RES,CHIP 10K 5% 1/10W
R181 1-216-025-91 RES,CHIP 100 5% 1/10W
R182 1-216-025-91 RES,CHIP 100 5% 1/10W
R183 1-216-073-00 RES,CHIP 10K 5% 1/10W
R184 1-216-025-91 RES,CHIP 100 5% 1/10W
R185 1-216-025-91 RES,CHIP 100 5% 1/10W
R186 1-216-025-91 RES,CHIP 100 5% 1/10W
R187 1-216-025-91 RES,CHIP 100 5% 1/10W
R188 1-216-025-91 RES,CHIP 100 5% 1/10W
R189 1-216-025-91 RES,CHIP 100 5% 1/10W
R190 1-216-053-00 RES,CHIP 1.5K 5% 1/10W
R191 1-216-053-00 RES,CHIP 1.5K 5% 1/10W
R192 1-216-097-91 RES,CHIP 100K 5% 1/10W
R193 1-216-053-00 RES,CHIP 1.5K 5% 1/10W
R194 1-216-053-00 RES,CHIP 1.5K 5% 1/10W
R195 1-216-053-00 RES,CHIP 1.5K 5% 1/10W
R196 1-216-073-00 RES,CHIP 10K 5% 1/10W
R197 1-216-073-00 RES,CHIP 10K 5% 1/10W
R198 1-216-097-91 RES,CHIP 100K 5% 1/10W
<THERMISTOR>
THP101 1-771-075-21 THERMISTOR, POSITIVE
THP102 1-771-075-21 THERMISTOR, POSITIVE
<TEST PIN>
TP110 * 1-537-864-11 PIN, POST
TP111 * 1-537-864-11 PIN, POST
TP112 * 1-537-864-11 PIN, POST
TP113 * 1-537-864-11 PIN, POST
TP114 * 1-537-864-11 PIN, POST
<CRYSTAL>
X101 1-767-892-21 VIBRATOR, CRYSTAL (20 MHz)
****************************************************************
* A-1306-575-A MB COMPL (D9H1)
******************
* A-1306-576-A MB COMPL (D9H5)
*****************
7-432-114-11 SCREW LOCK
<CAPACITOR>
C1100 1-126-206-11 ELECT CHIP 100µF 20% 6.3V
C1101 1-165-319-11 CERAMIC CHIP0.1µF 50V
C1102 1-126-206-11 ELECT CHIP 100µF 20% 6.3V
C1103 1-165-319-11 CERAMIC CHIP0.1µF 50V
C1104 1-163-031-11 CERAMIC CHIP0.01µF 50V
C1105 1-163-031-11 CERAMIC CHIP0.01µF 50V
C1106 1-126-206-11 ELECT CHIP 100µF 20% 6.3V
C1107 1-126-206-11 ELECT CHIP 100µF 20% 6.3V
C1108 1-163-233-11 CERAMIC CHIP18PF 5% 50V
C1109 1-163-031-11 CERAMIC CHIP0.01µF 50V
C1110 1-163-231-11 CERAMIC CHIP15PF 5% 50V
C1111 1-126-206-11 ELECT CHIP 100µF 20% 6.3V
C1112 1-163-031-11 CERAMIC CHIP0.01µF 50V
C1114 1-163-031-11 CERAMIC CHIP0.01µF 50V
C1115 1-126-206-11 ELECT CHIP 100µF 20% 6.3V
C1116 1-163-031-11 CERAMIC CHIP0.01µF 50V
C1117 1-126-206-11 ELECT CHIP 100µF 20% 6.3V
C1118 1-163-021-91 CERAMIC CHIP0.01µF 10% 50V
C1119 1-107-682-11 CERAMIC CHIP1µF 10% 16V
C1120 1-163-031-11 CERAMIC CHIP0.01µF 50V
C1121 1-126-206-11 ELECT CHIP 100µF 20% 6.3V
C1122 1-165-319-11 CERAMIC CHIP0.1µF 50V
C1123 1-163-031-11 CERAMIC CHIP0.01µF 50V
C1124 1-165-319-11 CERAMIC CHIP0.1µF 50V
C1125 1-126-206-11 ELECT CHIP 100µF 20% 6.3V
C1126 1-165-319-11 CERAMIC CHIP0.1µF 50V
C1127 1-126-206-11 ELECT CHIP 100µF 20% 6.3V
C1128 1-165-319-11 CERAMIC CHIP0.1µF 50V
C1129 1-126-206-11 ELECT CHIP 100µF 20% 6.3V
C1130 1-126-206-11 ELECT CHIP 100µF 20% 6.3V
C1131 1-163-031-11 CERAMIC CHIP0.01µF 50V
C1132 1-165-319-11 CERAMIC CHIP0.1µF 50V
C1133 1-165-319-11 CERAMIC CHIP0.1µF 50V
C1134 1-165-319-11 CERAMIC CHIP0.1µF 50V
C1135 1-163-021-91 CERAMIC CHIP0.01µF 10% 50V
C1136 1-107-682-11 CERAMIC CHIP1µF 10% 16V
C1137 1-165-319-11 CERAMIC CHIP0.1µF 50V
C1138 1-165-319-11 CERAMIC CHIP0.1µF 50V
C1139 1-165-319-11 CERAMIC CHIP0.1µF 50V
C1140 1-165-319-11 CERAMIC CHIP0.1µF 50V
C1141 1-163-031-11 CERAMIC CHIP0.01µF 50V
C1142 1-126-206-11 ELECT CHIP 100µF 20% 6.3V
C1143 1-163-031-11 CERAMIC CHIP0.01µF 50V
C1144 1-163-031-11 CERAMIC CHIP0.01µF 50V
C1145 1-126-206-11 ELECT CHIP 100µF 20% 6.3V
C1146 1-163-031-11 CERAMIC CHIP0.01µF 50V
C1147 1-163-031-11 CERAMIC CHIP0.01µF 50V
C1148 1-163-031-11 CERAMIC CHIP0.01µF 50V
C1149 1-163-031-11 CERAMIC CHIP0.01µF 50V
C1150 1-126-206-11 ELECT CHIP 100µF 20% 6.3V
C1151 1-163-031-11 CERAMIC CHIP0.01µF 50V
C1152 1-163-031-11 CERAMIC CHIP0.01µF 50V
C1153 1-163-031-11 CERAMIC CHIP0.01µF 50V
C1154 1-163-031-11 CERAMIC CHIP0.01µF 50V
C1156 1-163-031-11 CERAMIC CHIP0.01µF 50V
C1157 1-126-206-11 ELECT CHIP 100µF 20% 6.3V
C1158 1-163-031-11 CERAMIC CHIP0.01µF 50V
C1159 1-126-206-11 ELECT CHIP 100µF 20% 6.3V
C1160 1-163-021-91 CERAMIC CHIP0.01µF 10% 50V
C1161 1-163-021-91 CERAMIC CHIP0.01µF 10% 50V
C1162 1-164-690-91 CERAMIC CHIP0.0022µF 5% 50V
C1180 1-163-243-11 CERAMIC CHIP47PF 5% 50V
<CONNECTOR>
CN1100 * 1-564-524-11 PLUG, CONNECTOR 9P
CN1101 * 1-564-527-11 PLUG, CONNECTOR 12P
CN1102 * 1-793-722-11 PIN, CONNECTOR (PC BOARD) 50P
CN1103 1-695-581-21 CONNECTOR, D SUB
CN1104 1-695-581-21 CONNECTOR, D SUB
CN1105 * 1-564-524-11 PLUG, CONNECTOR 9P
CN1106 * 1-564-522-11 PLUG, CONNECTOR 7P
CN1107 1-695-581-21 CONNECTOR, D SUB
CN1109 1-793-721-11 JACK, MODULAR
<DIODE>
D1100 8-719-158-19 DIODE RD6.2SB
D1101 8-719-158-19 DIODE RD6.2SB
D1102 8-719-158-19 DIODE RD6.2SB
MA MB
