Sony TRINITRON BVM-D9H5U - Page 115

9-25
BVM-D9H1U/D9H5U/D9H1E/D9H5E/D9H1A/D9H5A
Ref.No. Part No. Description RemarkRef.No. Part No. Description Remark
R1183 1-216-049-91 RES,CHIP 1K 5% 1/10W
R1184 1-216-049-91 RES,CHIP 1K 5% 1/10W
R1185 1-216-049-91 RES,CHIP 1K 5% 1/10W
R1186 1-216-295-91 SHORT 0 (D9H5)
R1187 1-216-295-91 SHORT 0 (D9H5)
R1188 1-216-295-91 SHORT 0 (D9H5)
R1189 1-216-295-91 SHORT 0 (D9H5)
<RELAY>
RY1101 1-515-716-11 RELAY (TQ2-5V) (D9H1)
RY1102 1-515-716-11 RELAY (TQ2-5V) (D9H1)
<SWITCH>
S1101 1-771-815-11 SWITCH, LEVER
S1102 1-762-712-11 SWITCH, SLIDE (D9H1)
<THERMISTOR>
TH1100 1-533-817-21 THERMISTOR
<TEST PIN>
TP1100 * 1-537-864-11 PIN, POST
TP1101 * 1-537-864-11 PIN, POST
TP1102 * 1-537-864-11 PIN, POST
TP1103 * 1-537-864-11 PIN, POST
TP1104 * 1-537-864-11 PIN, POST
TP1106 * 1-537-864-11 PIN, POST
TP1107 * 1-537-864-11 PIN, POST
TP1108 * 1-537-864-11 PIN, POST
TP1109 * 1-537-864-11 PIN, POST
TP1110 * 1-537-864-11 PIN, POST
TP1111 * 1-537-864-11 PIN, POST
TP1112 * 1-537-864-11 PIN, POST
TP1113 * 1-537-864-11 PIN, POST
<CRYSTAL>
X1100 1-767-280-21 VIBRATOR, CRYSTAL (3.6864 MHz)
****************************************************************
* A-1195-156-A P COMPL
*********
! 4-051-742-01 SHEET, INSULATE
4-382-854-01 SCREW (M3X8), P, SW (+)
4-382-854-11 SCREW (M3X10), P, SW (+)
7-682-647-09 SCREW +PS 3X6
<CAPACITOR>
C501 1-107-907-11 ELECT 22µF 20% 25V
C502 1-163-038-91 CERAMIC CHIP0.1µF 25V
C503 1-107-888-11 ELECT 47µF 20% 25V
C504 1-164-343-11 CERAMIC CHIP0.056µF 10% 25V
C505 1-107-906-11 ELECT 10µF 20% 50V
C506 1-163-031-11 CERAMIC CHIP0.01µF 50V
C508 1-163-031-11 CERAMIC CHIP0.01µF 50V
C509 1-163-021-91 CERAMIC CHIP0.01µF 10% 50V
C510 1-107-909-11 ELECT 47µF 20% 16V
C511 1-163-133-00 CERAMIC CHIP470PF 5% 50V
C512 1-107-902-11 ELECT 1µF 20% 50V
C513 1-163-121-00 CERAMIC CHIP150PF 5% 50V
C514 1-163-005-11 CERAMIC CHIP470PF 10% 50V
C515 1-107-903-11 ELECT 2.2µF 20% 50V
C516 1-165-319-11 CERAMIC CHIP0.1µF 50V
C517 1-107-823-11 CERAMIC CHIP0.47µF 10% 16V
C518 1-164-004-11 CERAMIC CHIP0.1µF 10% 25V
C519 1-164-343-11 CERAMIC CHIP0.056µF 10% 25V
C520 1-163-031-11 CERAMIC CHIP0.01µF 50V
C521 1-163-241-11 CERAMIC CHIP39PF 5% 50V
C522 1-165-319-11 CERAMIC CHIP0.1µF 50V
C523 1-126-964-11 ELECT 10µF 20% 50V
C524 1-163-121-00 CERAMIC CHIP150PF 5% 50V
C525 1-115-339-11 CERAMIC CHIP0.1µF 10% 50V
C526 1-163-031-11 CERAMIC CHIP0.01µF 50V
C527 1-107-906-11 ELECT 10µF 20% 50V
C528 1-104-664-11 ELECT 47µF 20% 25V
C529 1-163-133-00 CERAMIC CHIP470PF 5% 50V
C530 1-165-319-11 CERAMIC CHIP0.1µF 50V
C531 1-164-004-11 CERAMIC CHIP0.1µF 10% 25V
C532 1-107-955-11 ELECT 100µF 20% 200V
C533 1-107-906-11 ELECT 10µF 20% 50V
C534 1-162-318-11 CERAMIC 0.001µF 10% 500V
C535 1-107-995-11 ELECT 100µF 160V
C536 1-107-364-11 MYLAR 0.01µF 10% 200V
C537 1-163-031-11 CERAMIC CHIP0.01µF 50V
C538 1-126-963-11 ELECT 4.7µF 20% 50V
C539 1-117-644-11 FILM 10000PF 3% 1.2KV
C540 1-107-746-51 ELECT 10µF 20% 200V
C541 1-107-746-51 ELECT 10µF 20% 200V
C542 1-137-591-91 FILM 0.0082µF 5% 800V
C543 1-104-664-11 ELECT 47µF 20% 25V
C544 1-108-385-91 MYLAR 0.047µH 10% 100V
C545 1-115-522-11 FILM 1µF 5% 250V
C546 1-165-319-11 CERAMIC CHIP0.1µF 50V
C547 1-163-031-11 CERAMIC CHIP0.01µF 50V
C548 1-163-038-91 CERAMIC CHIP0.1µF 25V
C549 1-163-031-11 CERAMIC CHIP0.01µF 50V
C550 1-163-031-11 CERAMIC CHIP0.01µF 50V
C551 1-163-031-11 CERAMIC CHIP0.01µF 50V
C552 1-107-954-91 ELECT 47µF 20% 200V
C553 1-102-228-00 CERAMIC 470PF 10% 500V
C554 1-126-968-11 ELECT 100µF 20% 50V
C555 1-162-318-11 CERAMIC 0.001µF 10% 500V
C556 1-162-318-11 CERAMIC 0.001µF 10% 500V
C557 1-111-116-11 ELECT 100µF 20% 50V
C558 1-126-964-11 ELECT 10µF 20% 50V
C559 1-163-263-11 CERAMIC CHIP330PF 5% 50V
C560 1-130-471-00 MYLAR 0.001µF 5% 50V
C561 1-163-031-11 CERAMIC CHIP0.01µF 50V
C562 1-104-664-11 ELECT 47µF 20% 25V
C563 1-115-732-11 ELECT 330µF 20% 6.3V
C564 1-137-150-11 MYLAR 0.01µF 10% 100V
C565 1-137-150-11 MYLAR 0.01µF 10% 100V
C566 1-163-031-11 CERAMIC CHIP0.01µF 50V
C567 1-163-031-11 CERAMIC CHIP0.01µF 50V
C568 1-115-789-11 ELECT 0.001F 20% 25V
C569 1-163-031-11 CERAMIC CHIP0.01µF 50V
C570 1-163-031-11 CERAMIC CHIP0.01µF 50V
C571 1-163-021-91 CERAMIC CHIP0.01µF 10% 50V
C572 1-107-902-11 ELECT 1µF 20% 50V
C574 1-163-809-11 CERAMIC CHIP0.047µF 10% 25V
C575 1-107-823-11 CERAMIC CHIP0.47µF 10% 16V
C576 1-136-161-00 MYLAR 0.047µF 5% 50V
C577 1-136-165-00 MYLAR 0.1µF 5% 50V
C578 1-107-902-11 ELECT 1µF 20% 50V
C579 1-107-909-11 ELECT 47µF 20% 16V
C581 1-128-526-11 ELECT 100µF 20% 16V
MB P
