Sony TRINITRON BVM-D9H5U - Page 116

9-26
BVM-D9H1U/D9H5U/D9H1E/D9H5E/D9H1A/D9H5A
Ref.No. Part No. Description RemarkRef.No. Part No. Description Remark
C583 1-107-995-11 ELECT 100µF 160V
C584 1-107-889-11 ELECT 220µF 20% 25V
C585 1-104-653-11 ELECT 220µF 20% 16V
C587 1-163-021-91 CERAMIC CHIP0.01µF 10% 50V
C588 1-163-021-91 CERAMIC CHIP0.01µF 10% 50V
C589 1-163-021-91 CERAMIC CHIP0.01µF 10% 50V
C590 1-163-021-91 CERAMIC CHIP0.01µF 10% 50V
C592 1-107-888-91 ELECT 47µF 20% 25V
<CONNECTOR>
CN501 * 1-564-712-11 PIN, CONNECTOR (SMALL TYPE)10P
CN502 * 1-564-508-11 PLUG, CONNECTOR 5P
CN503 * 1-691-960-11 PIN, CONNECTOR (PC BOARD) 3P
CN505 * 1-564-509-11 PLUG, CONNECTOR 6P
CN506 * 1-564-711-11 PIN, CONNECTOR (SMALL TYPE) 9P
<DIODE>
D501 8-719-073-01 DIODE MA111-(K8).S0
D502 8-719-073-01 DIODE MA111-(K8).S0
D503 8-719-158-49 DIODE RD12SB2
D504 8-719-073-01 DIODE MA111-(K8).S0
D505 8-719-158-49 DIODE RD12SB2
D506 8-719-158-49 DIODE RD12SB2
D507 8-719-158-40 DIODE RD10SB1
D508 8-719-073-01 DIODE MA111-(K8).S0
D509 8-719-989-21 DIODE SC311-6-TE12RA
D510 8-719-073-01 DIODE MA111-(K8).S0
D511 8-719-107-15 DIODE RD18M-T1B2
D512 8-719-073-01 DIODE MA111-(K8).S0
D513 8-719-073-01 DIODE MA111-(K8).S0
D514 8-719-073-01 DIODE MA111-(K8).S0
D515 8-719-989-21 DIODE SC311-6-TE12RA
D516 8-719-073-01 DIODE MA111-(K8).S0
D517 8-719-073-01 DIODE MA111-(K8).S0
D518 8-719-073-01 DIODE MA111-(K8).S0
D519 8-719-073-01 DIODE MA111-(K8).S0
D520 8-719-029-04 DIODE D5L60
D521 8-719-073-01 DIODE MA111-(K8).S0
D522 8-719-073-01 DIODE MA111-(K8).S0
D523 8-719-110-67 DIODE RD27ESB2
D524 8-719-110-67 DIODE RD27ESB2
D525 8-719-302-43 DIODE EL1Z
D526 8-719-302-43 DIODE EL1Z
D527 8-719-302-43 DIODE EL1Z
D528 8-719-073-01 DIODE MA111-(K8).S0
D529 8-719-073-01 DIODE MA111-(K8).S0
D530 8-719-210-43 DIODE EC10QS-06
D531 8-719-110-67 DIODE RD27ESB2
D532 8-719-037-53 DIODE RD27SB-T1
D533 8-719-073-01 DIODE MA111-(K8).S0
D534 8-719-073-01 DIODE MA111-(K8).S0
D535 8-719-158-57 DIODE RD15SB2
D536 8-719-073-01 DIODE MA111-(K8).S0
D537 8-719-110-02 DIODE RD7.5ESB1
D538 8-719-033-53 DIODE RD6.8SB2-T1
D539 8-719-073-01 DIODE MA111-(K8).S0
<IC>
IC501 8-759-209-69 IC TC4S11F
IC502 8-759-158-82 IC CXA1544M-T6
IC503 8-759-914-04 IC TL494CNS
IC504 ! 8-759-198-31 IC UPC1093J-1-T
IC505 8-759-209-69 IC TC4S11F
IC506 8-759-185-47 IC IR2112
IC507 8-759-198-31 IC UPC1093J-1-T
IC508 8-759-502-80 IC LM358M
IC509 8-759-502-84 IC LM393M
IC510 8-759-337-67 IC NJM2360AM(TE2)
IC511 8-759-502-80 IC LM358M
<COIL>
L504 1-406-663-21 INDUCTOR 47µH
L505 1-419-346-11 COIL, CHOKE
L507 1-406-661-11 INDUCTOR 22µH
L508 1-408-623-21 INDUCTOR 470µH
<NEON LAMP>
NL501 1-519-526-11 LAMP, NEON
NL502 1-519-526-11 LAMP, NEON
<TRANSISTOR>
Q502 8-729-027-23 TRANSISTOR DTA114EKA-T146
Q503 1-801-806-11 TRANSISTOR DTC144EKA-T146
Q504 1-801-806-11 TRANSISTOR DTC144EKA-T146
Q505 8-729-027-38 TRANSISTOR DTA144EKA-T146
Q506 8-729-019-85 TRANSISTOR 2SC3392-5-TB
Q507 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q508 8-729-026-49 TRANSISTOR 2SA1037AK-T146-R
Q509 8-729-824-24 TRANSISTOR 2SA1338-5-TB
Q510 8-729-019-85 TRANSISTOR 2SC3392-5-TB
Q511 8-729-019-85 TRANSISTOR 2SC3392-5-TB
Q512 8-729-026-49 TRANSISTOR 2SA1037AK-T146-R
Q513 8-729-824-24 TRANSISTOR 2SA1338-5-TB
Q514 8-729-019-85 TRANSISTOR 2SC3392-5-TB
Q515 8-729-050-47 TRANSISTOR 2SK3110
Q516 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q517 8-729-926-77 TRANSISTOR IRFI640
Q518 8-729-926-77 TRANSISTOR IRFI640
Q519 8-729-026-49 TRANSISTOR 2SA1037AK-T146-R
Q520 8-729-050-71 TRANSISTOR IRFPE50LF20
Q521 8-729-027-38 TRANSISTOR DTA144EKA-T146
Q522 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q523 8-729-026-49 TRANSISTOR 2SA1037AK-T146-R
Q524 1-801-806-11 TRANSISTOR DTC144EKA-T146
Q525 8-729-033-25 TRANSISTOR DTC114GKA
Q526 8-729-026-49 TRANSISTOR 2SA1037AK-T146-R
Q527 8-729-032-54 TRANSISTOR IRFI840LF38
Q528 1-801-806-11 TRANSISTOR DTC144EKA-T146
Q529 8-729-027-38 TRANSISTOR DTA144EKA-T146
Q530 1-801-806-11 TRANSISTOR DTC144EKA-T146
<RESISTOR>
R503 1-216-075-00 RES,CHIP 12K 5% 1/10W
R504 1-216-025-91 RES,CHIP 100 5% 1/10W
R505 1-216-077-91 RES,CHIP 15K 5% 1/10W
R506 1-216-081-00 RES,CHIP 22K 5% 1/10W
R507 1-216-659-11 METAL CHIP 2.2K 0.50% 1/10W
R508 1-216-685-11 METAL CHIP 27K 0.50% 1/10W
R509 1-216-017-91 RES,CHIP 47 5% 1/10W
R510 1-216-053-00 RES,CHIP 1.5K 5% 1/10W
R511 1-249-381-11 CARBON 1 5% 1/4W F
R512 1-216-097-91 RES,CHIP 100K 5% 1/10W
R513 1-216-009-91 RES,CHIP 22 5% 1/10W
R514 1-216-101-00 RES,CHIP 150K 5% 1/10W
R515 1-216-025-91 RES,CHIP 100 5% 1/10W
P
