3-12
BVM-D9H1U/D9H5U/D9H1E/D9H5E/D9H1A/D9H5A
3.3 White Balance Adjustment (2)
1. Connect the 480/60i (525) 20 IRE WINDOW color
difference signal to the ANALOG Y/G input connec-
tor.
2. Select STD using the COLOR TEMP menu of the
INPUT CONFIG menu.
3. Select MAINTENANCE menu of the SYSTEM
CONFIG menu.
4. Select the VIDEO menu.
5. Increase the CHROMA control to its maximum.
6. Adjust white balance by adjusting the PR/R. BLACK
and PB/B. BLACK menus of the VIDEO menu.
x = 0.283
y = 0.297
3.4 White Balance Adjustment (3)
1. Connect the 1080/60i (1125) 20 IRE WINDOW color
difference signal to the ANALOG Y/G input connec-
tor.
2. Select STD using the COLOR TEMP menu of the
INPUT CONFIG menu.
3. Select MAINTENANCE menu of the SYSTEM
CONFIG menu.
4. Select the VIDEO menu.
5. Increase the CHROMA control to its maximum.
6. Adjust white balance by adjusting the PR/R. BLACK
and PB/B. BLACK menus of the VIDEO menu.
x = 0.283
y = 0.297
3.5 White Balance Adjustment (4)
1. Turn off the main POWER switch.
2. Insert the BKM-142HD into the SLOT 2.
3. Connect the HD-SDI 20 IRE WINDOW signal to the
BKM-142HD.
4. Turn on the main POWER switch.
5. Select HD-SDI using the FORMAT menu of the
INPUT CONFIG menu.
6. Select MAINTENANCE menu of the SYSTEM
CONFIG menu.
7. Select the VIDEO menu.
8. Increase the CHROMA control to its maximum.
9. Adjust white balance by adjusting the PR/R. BLACK
and PB/B. BLACK menus of the VIDEO menu.
x = 0.283
y = 0.297
15. Connect the 1080/60i 100 IRE WINDOW signal to the
ANALOG Y/G input connector.
16. Adjust SUB CONTRAST so that luminance becomes
120 cd/m
2
.
17. Press the SHIFT OFF button [to turn off the LED
(orange) on top of the SHIFT button].
Press the UNDER SCAN button ( ) to its ON
position to select the under scan mode. [The green
LED turns on.]
18. Adjust SUB CONTRAST so that luminance becomes
120 cd/m
2
.
19. Press the UNDER SCAN button ( ) to its OFF
position to select the normal mode. [The green LED
turns off.]
20. Connect the 480/60p (525P) 100IRE WINDOW signal
to the to ANALOG Y/G input connector.
21. Press the SHIFT ON button [to turn on the LED
(orange) on top of the SHIFT button]. Press the 16:9
OFF button [to turn off the LED (orange)] to select the
4:3 mode.
22. Press the SHIFT OFF button [to turn off the LED
(orange) on top of the SHIFT button].
Press the UNDER SCAN button ( ) to its OFF
position to select the normal mode. [The green LED
turns off.]
23. Adjust SUB CONTRAST so that luminance becomes
120 cd/m
2
.
24. Press the UNDER SCAN button ( ) to its OFF
position to select the normal mode. [The green LED
turns off.]
25. Adjust SUB CONTRAST so that luminance becomes
120 cd/m
2
.
26. Press the UNDER SCAN button ( ) to its OFF
position to select the normal mode. [The green LED
turns off.]
