Sony Trinitron CPD-E220 - Page 42

REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK
The components identified by mark ¡
are critical for safety.
Replace only with part number specified.
Les composants identifiés par une
marque
¡ sont critiques pour la sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
CPD-E220/E215E/E220E
7-8
(d)
R914 METAL FILM 33.2 1/4W 4257043329
R915 METAL FILM 30.1K 1/4W 4257043012
R918 RES-CHIP 10K
1/10W 4010110352
R919 1-247-847-91
CARBON (SMALL) 4.7K 1/4W 4050547255
R920 RES-CHIP 10K
1/10W 4010110352
R921 RES-CHIP 1K 1/10W 4010110252
R922 RES-CHIP 10K
1/10W 4010110352
R923 RES-CHIP 10K
1/10W 4010110352
R924 RES-CHIP 1K
1/10W 4010110252
R925 1-247-855-91
CARBON (SMALL) 10K 1/4W 4050510355
R926 RES-CHIP 100 1/10W 4010110152
R927 RES-CHIP 4.7K
1/10W 4010147252
R928 RES-CHIP 10K
1/10W 4010110352
R929 RES-CHIP 10K 1/8W 4010810352
R930 RES-CHIP 10K 1/8W 4010810352
R931 RES-CHIP 10K 1/8W 4010810352
R932 1-247-791-91
CARBON (SMALL) 22 1/4W 4050522055
R933 1-247-791-91
CARBON (SMALL) 22 1/4W 4050522055
R934
CARBON (SMALL) 47 1/4W 4050547055
R935 RES-CHIP 10K 1/8W 4010810352
R936 RES-CHIP 1M
1/10W 4010110552
R937 RES-CHIP 47
1/10W 4010147052
R938 RES-CHIP 10K 1/8W 4010810352
R939 RES-CHIP 10K 1/8W 4010810352
R940 RES-CHIP 10K
1/10W 4010110352
R941 RES-CHIP 100 1/8W 4010810152
R942 RES-CHIP 100 1/8W 4010810152
R943 1-247-807-91
CARBON (SMALL) 100 1/4W 4050510155
R944 RES-CHIP 470 1/8W 4010847152
R945 RES-CHIP 47 1/10W 4010147052
R946 RES-CHIP 100 1/8W 4010810152
R948 RES-CHIP 1.4
1/10W 4010114202
R949 RES-CHIP 51K
1/10W 4010151352
R950 RES-CHIP 510K
1/10W 4010151452
R951 RES-CHIP 28K
1/10W 4010128302
R952 RES-CHIP 47
1/10W 4010147052
R954 RES-CHIP 10K
1/10W 4010110202
R955 1-247-855-91
CARBON (SMALL) 10K 1/4W 4050510355
R5001 METAL OXIDE 100 2W 4172010156
R5003 1-247-855-91 CARBON (SMALL) 10K 1/4W 4050510355
R5102 RES-CHIP 120K
1/10W 4010113352
R5103 RES-CHIP 10K
1/10W 4010110352
R5104
CARBON (SMALL) 10K 1/2W 4050110355
R5106 1-247-823-91
CARBON (SMALL) 470 1/4W 4050547155
R5107 1-247-855-91
CARBON (SMALL) 10K 1/4W 4050510355
R5108 RES-CHIP 18K
1/10W 4010118302
R5109 RES-CHIP 1M
1/10W 4010110552
R5110 RES-CHIP 470
1/10W 4010147152
R5111 RES-CHIP 20K
1/10W 4010120352
R5112 RES-CHIP 6.8K
1/10W 4010168252
R5113 RES-CHIP 51K
1/10W 4010151352
R5114 RES-CHIP 120K
1/10W 4010112452
R5115
CARBON (SMALL) 100K 1/2W 4050110455
R5116
CARBON (SMALL) 100K 1/2W 4050110455
R5117 1-247-807-91
CARBON (SMALL) 100 1/4W 4050510155
R5118 RES-CHIP 10K
1/10W 4010110352
R5119 1-247-847-91
CARBON (SMALL) 4.7K 1/4W 4050547255
R5120 RES-CHIP 26.7K
1/10W 419A126722
R5121 1-247-855-91
CARBON (SMALL) 10K 1/4W 4050510355
R5122 RES-CHIP 60.4K
1/10W 419A160422
R5123 RES-CHIP 10K
1/10W 4010110202
R5124 1-247-807-91 CARBON (SMALL) 100 1/4W 4050510155
R5125
CARBON (SMALL) 430 1/4W 4050543155
R5126 RES-CHIP 1.47K
1/10W 419A114712
R5127
CARBON (SMALL) 20 1/2W 4050120055
R5128
CARBON (SMALL) 36 1/2W 4050136055
R5129 RES-CHIP 1K 1/10W 4010110252
R5130 RES-CHIP 10K
1/10W 4010110352
R5131 RES-CHIP 820K 1/8W 4010882452
R5132 RES-CHIP 47K 1/10W 4010147352
R5134
METAL OXIDE FILM 4.7 1W 4171247956
<RELAY>
RY501 1-755-423-11 RELAY 4420412016
RY601 01-775-031-11 RELAY 4420612014
<SWITCH>
S602 1-771-757-11 SWITCH, POWER PUSH 4410204018
SW901 1-771-930-11 SWITCH, KEY BOARD (RESET) 4410604034
<SPARK GAP>
SG501 1-519-422-21 GAP, SPARK 5106152204
<TRANSFORMER>
T501 0 1-453-358-11 TRANSFORMER, FLYBACK 7050307C2U
T502 TRANSFORMER, DRIVER 7050207C2U
T503 7050907C2U
T504 1-435-844-11 TRANSFORMER, FOCUS 7050507C2U
T601 0 1-435-853-11 PFC X’FORMER 7051309D00
[E220E]
T603 0 TRANSFORMER, POWER 7050107C2U
<THERMISTOR>
TH60101-803-533-11 THERMISTOR 710501003B
TH60201-803-963-11 THERMISTOR 7106070027
<VARIABLE RESISTOR>
VR5010
RES, ADJ, CERMET 50K (HV ADJ) 5.22E+11
<CRYSTAL>
X901 1-781-719-11 VIBRATOR, CRYSTAL (24MHz) 7152400010
******************************************************************************************
