REF.NO. PART NO. DESCRIPTION REMARK REF.NO. PART NO. DESCRIPTION REMARK
The components identified by mark
¡
are critical for safety.
Replace only with part number specified.
Les composants identifiés par une
marque
¡
sont critiques pour la sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
CPD-E220/E215E/E220E
7-1
NOTE:
The components identified by mark ¡
are critical for safety.
Replace only with part number specified.
When indicating parts by reference
number, please include the board name.
REF.NO. PART NO. DESCRIPTION REMARK
SECTION 7
ELECTRICAL PARTS LIST
REF.NO. PART NO. DESCRIPTION REMARK
Les composants identifiés par une
marque ¡ sont critiques pour la
sécurité. Ne les remplacer que par une
pièce portant le numéro spécifié.
• All variable and adjustable resistors have
characteristic curve B, unless otherwise
noted.
(a)
RESISTORS
• All resistors are in ohms
• F : nonflammable
• Items marked " * " are not stocked since
they are seldom required for routine
service. Some delay should be anticipated
when ordering these items.
CPD-E220/E215E/E220E
A BOARD, COMPLETE
***************************
4-382-854-11 SCREW (M3X10), P, SW (+) (IC002)
<CAPACITOR>
C001 1-126-964-91 ELECT 10µF 50V 5156100T50
C002 1-126-934-11 ELECT 220µF 16V 5156221S16
C004 1-164-489-91 CERAMIC 0.22µF 16V 7144224106
C005 1-135-397-11 ELECT 47µF 16V 515X470T16
C006 1-115-339-91 CERAMIC 0.1µF 50V 7146104456
C008 1-136-497-11
METALIZED FILM
0.1µF 50V 5134104452
C009 1-104-660-91 ELECT 47µF 16V 5156470T16
C010 1-115-339-91 CERAMIC 0.1µF 50V 7146104456
C011 1-128-582-91 ELECT 10µF 100V 5156100T01
C012 0.1µF 100V 5116104111
C013 1-115-339-91 CERAMIC 0.1µF 50V 7146104456
C014 CERAMIC 1000pF 2KV 51011021C3
C015 1-107-823-11 CERAMIC 0.47µF 16V 7144474106
C016 1-163-009-11 CERAMIC 0.001µF 50V 7144102256
C017 0.1µF 100V 5116104111
C019 0.1µF 100V 5116104111
C022 1-163-131-00 CERAMIC 390pF 50V 7183391556
C023 1-135-393-11 ELECT 100µF 10V 5156101T10
C025 1-115-339-91 CERAMIC 0.1µF 50V 7146104456
C026 1-163-013-11 CERAMIC 2200pF 50V 7144222156
C028 1-163-263-11 CERAMIC 330pF 50V 7183331556
C029 1-102-074-11 CERAMIC 0.001µF 50V 5101102152
C030 1-135-393-11 ELECT 100µF 10V 5156101T10
C032 1-135-398-11 ELECT 1µF 50V 5156109T50
C033 CERAMIC 4700pF 50V 7144472156
C034 1-115-339-91 CERAMIC 0.1µF 50V 7146104456
C035 1-135-393-11 ELECT 100µF 10V 5156101T10
C037 1-164-489-91 CERAMIC 0.22µF 16V 7144224106
C038 1-104-660-91 ELECT 47µF 16V 5156470T16
C039 1-126-933-11 ELECT 100µF 16V 5156101T16
C040 0.01µF 100V 5116103511
C042 CERAMIC 33pF 50V 5121330552
C043 1-135-404-11 ELECT 4.7µF 35V 5162479T35
C044 1-137-399-91 PETP FILM 0.1µF 100V 5116104111
C045 CERAMIC 0.01µF 1.5KV5104103463
C101 33pF 50V 7183330556
C102 1-126-964-91 ELECT 10µF 50V 5156100T50
C103 1-115-339-91 CERAMIC 0.1µF 50V 7146104456
C104 1-115-339-91 CERAMIC 0.1µF 50V 7146104456
C106 1-135-383-11
METALIZED FILM
0.1µF 100V 5075104501
C107 1-136-497-11
METALIZED FILM
0.1µF 50V 5134104452
C201 33pF 50V 7183330556
C202 1-126-964-91 ELECT 10µF 50V 5156100T50
C203 1-115-339-91 CERAMIC 0.1µF 50V 7146104456
C204 1-115-339-91 CERAMIC 0.1µF 50V 7146104456
C206 1-135-383-11
METALIZED FILM
0.1µF 100V 5075104501
C207 1-136-497-11
METALIZED FILM
0.1µF 50V 5134104452
C301 33pF 50V 7183330556
C302 1-126-964-91 ELECT 10µF 50V 5156100T50
C303 1-115-339-91 CERAMIC 0.1µF 50V 7146104456
C304 1-115-339-91 CERAMIC 0.1µF 50V 7146104456
C306 1-135-383-11
METALIZED FILM
0.1µF 100V 5075104501
C307 1-136-497-11
METALIZED FILM
0.1µF 50V 5134104452
<CONNECTOR>
CN301 1-564-510-51 PLUG, CONNECTOR 6P 4490600330
CN302 1-564-510-51 PLUG, CONNECTOR 9P 4490900330
CN303* 1-564-510-51 PLUG, CONNECTOR 7P 4490700330
CN304* 1-564-507-51 PLUG, CONNECTOR 4P 4490400330
CN307 1-695-915-11 TAB (CONTACT) 1P
CN309 1-506-108-41
PIN, CONNECTOR (TERMINAL PIN)
3340236016
CN310 1-695-915-11 TAB (CONTACT) 1P
CN311 1P
CN312 1P
<DIODE>
D001 8-719-911-19 DIODE 1SS119-25 4120511900
D002 8-719-070-90 DIODE 1N4148 412014148T
D003 8-719-109-85 ZENER DIODE RD5.1ESB2 41205005C2
D004 8-719-921-20 DIODE 1SS119-25TD 4120511900
D017 8-719-074-13 DIODE BYV26C 413010426C
D101 8-719-070-90 DIODE 1N4148 412014148T
D102 8-719-070-90 DIODE 1N4148 412014148T
D103 8-719-970-82 DIODE HSS82 4130190820
D104 8-719-970-82 DIODE HSS82 4130190820
D105 8-719-970-82 DIODE HSS82 4130190820
D201 8-719-911-19 DIODE 1SS119-25 4120511900
D202 8-719-911-19 DIODE 1SS119-25 4120511900
